Summary of Contents for EasyRoller EasyRoller
- Page 1 User`s manual...
- Page 2 The unique story of EasyRoller EasyRoller is the rst non metal wheelchair on the market. It is the best choice for institutions where the use of metal inside the wheelchair is not allowed or not desireable. EasyRoller is made of enviromentaly friendly recyclable plastic, unique and will make the user feel comfortable.
-
Page 3: Table Of Contents
CONTENTS: Introduction General information Warranty Environment and disposal High and low temperatures Product information Measurements Basic description Spesi cations Use / functions Parking brakes Footrest Pool Spare parts Maintenance Cleaning Service interval Tests, applied standards and support DESIGN BY: Eker Design... -
Page 4: Introduction
ABOUT THIS MANUAL. Please read this maunal before using your EasyRoller wheelchair. EasyRoller is the only wheelchair of its kind which consists of 100% plastic/ polymer materials, and only weighs 17kg. The wheelchair is designed and developed by Eker Design AS. -
Page 5: General Information
EasyRoller is produced in 100% plastic/polymer, and can be recycled without sorting the various parts. 1.3 Temperatures, high and low EasyRoller can be used in extreme low and high temperatures, up to +65 degrees Celsius, for example use in a sauna or steamshower. DESIGN BY: Eker Design... -
Page 6: Basic Description
2.2 Basic description Back padding Seat padding Armrest with padding Parking brake Footrest Footrest strap Rear wheel Front wheel Driving handle Cloth protector Driving ring Tipstop WWW.EASYROLLER.NO... -
Page 7: Spesi Cations
2.3 Spesi cations The driving ring is designed with a wavy pattern for better grip. 1/2: Detachable seat-/back padding for extraordinary cleaning or The tipstop prevents the chair from tipping backwards. replacement. Armrest with padding for better comfort. The parking brakes can be adjusted after being actively used and worn. -
Page 8: Use / Functions
Normally, when getting out of the or out of the wheelchair. wheelchair the footrest is tilted up. The EasyRoller footrest is designed so this operation is not necessary. Simply place To adjust the parking brake: Deactivate the parking brake, turn the Hex your feets on the outside of the footrest 6mm nut so the brake is about 5mm from the tire (see illustration). -
Page 9: Pool
If the wheelchair will not be used in the pool, weights are unnecessary. EasyRoller creates no problems with rust in the wheel bearing / frame, and does not create any rust water. Water will not remain in the chair frame, and thus prevent bacterial problems. -
Page 10: Spare Parts
-Replacing front wheel holder (2), -Replacing footrest strap (3), -Replacing footrest (4), -Replacing front wheel (right /left side) (5), -Replacing armrest with padding (6), -Replacing break, left side (7), -Replacing break, right side (8), -Replacing rearwheel (right /left side) (9), -Replacing tipstop(10). WWW.EASYROLLER.NO... -
Page 11: Maintenance
Control of break settings Checking tires 6.0 Tests, applied standards and support EasyRoller is tested and approved according to the European Standard EN 12183 og International Standard ISO 7176. When service is needed, EasyRoller AS may be contacted by phone +47 90 97 86 07 or e-mail service@easyroller.no. - Page 12 Company: EasyRoller AS Sorlandsveien 50 NO-‐8640 Hemnesberget www.easyroller.no Sales Department: easyroller@easyroller.no Phone +47 90 64 35 35 ...
