Page 8 Page 8 FiberPatrol Site Planning & Installation Guide...
Page 9: System Description
Principles of operation The FiberPatrol FP1150 fence-mounted perimeter intrusion detection system detects and locates intruders using fiber optic technology. FiberPatrol senses and locates minute vibrations in the fence caused by climbing, cutting, lifting, or otherwise disturbing the fence fabric. A fiber optic sensor cable is attached to the perimeter fence.
Page 10: Fp1150 Configurations
2 fiber optic perimeter non-detecting lead cables 1 fiber optic sensor cable Figure 1 FiberPatrol block diagram - fully closed loop redundant configuration FP1150 configurations There are three distinct configurations for the FP1150 Series sensor: • Loop configurations in which the two sensors run in opposite directions in one fiber optic cable.
Page 11: Alarm Reporting
The FP1150 Series sensor can be incorporated into any security system, which accepts contact closure alarm data. A contact closure based FP1150 Series system can be configured to report up to 262 distinct alarm zones, plus system supervision and fail alarms through the UltraLink I/O system.
Page 12: Fiberpatrol Components
IDS software, contact closure outputs, or via the Network Manager software. The FiberPatrol sensor unit includes 2 SSD RAID hard drives, as well as dual redundant power supplies. There is an audible alert output that is activated in the event that one of the power supplies fails.
Page 13: Outdoor Splice Enclosure
The outdoor splice enclosure houses all field splices for the FiberPatrol system. The splice enclosure is also used to protect the FiberPatrol end module when it is installed outdoors. The splice enclosure is mounted on the protected fence. There are 2 models of the splice enclosure available.
Page 14: End Module
Figure 5 FiberPatrol dual end module Sensor cable/non-detecting lead cable FiberPatrol sensor cable is telecommunication grade single-mode fiber optic cable with a medium density polyethylene outer jacket and a waterblock system. The non-armored loose tube cable is comprised of a 5 unit fiber optic core (12-fiber buffer tubes and PE filler units) a central strength member and a rip cord.
Page 15: Cable Ties
The stainless steel cable ties are available with bare metal or vinyl coated in lengths of 8, 14, and 20 inches. For situations in which the FiberPatrol cable will be installed on a temporary fence and will be redeployed later, UV resistant plastic cable ties are recommended.
Page 16: Service Loops
13 m (43 ft.) isolation loop inside a buried vault. The cable is then run through another section of conduit and back onto the fence where it continues as another zone. Figure 9 provides the dimensions for the FiberPatrol buried vault. end view side view...
Page 17: Site Planning
Site planning FiberPatrol configurations The recommended method for installing FiberPatrol sensor cable is to use the minimum number of splices possible; i.e., run a single length of cable from the equipment room to the fence, and continue for as far as site conditions will allow you to go. Use splices for the equipment room connection to the SU, for the end module, and for any fiber drop points.
Page 18 S1 (sensor fiber 1 - internal to fiber optic cable) sensor unit S2 (sensor fiber 2 - internal to fiber optic cable) keyboard, monitor, mouse Figure 12 FiberPatrol fully closed redundant loop configuration (no field splices) Page 18 FiberPatrol Site Planning & Installation Guide...
Page 19: Split Configuration
S2 (sensor fiber 2 - internal to fiber optic cable) (min. possible required splices = 4) keyboard, monitor, mouse Figure 13 FiberPatrol partially closed redundant loop configuration Split configuration The split configuration provides extended length coverage by using each sensor fiber independently.
Page 20 Figure 16 FiberPatrol split configuration (closed loop with start point splice) Page 20 FiberPatrol Site Planning & Installation Guide...
Page 21: Line Configurations
Figure 17 FiberPatrol split configuration (closed loop no start point splice) Line configurations The line configuration is typically used when the sensor unit equipment is located at one end of the protected perimeter, and the perimeter extends away from the equipment room in one direction.
Page 22: Extended Lead Configuration
S2 (sensor fiber 2 - internal to fiber optic cable) keyboard, monitor, fusion splice mouse fiber optic termination sensor unit indicates software defined start of detection fiber connection module Figure 20 FiberPatrol extended lead configuration Page 22 FiberPatrol Site Planning & Installation Guide...
Page 23: Site Survey
Site survey Site survey The first step in installing a FiberPatrol fence protection system is to conduct a detailed site survey. The survey assesses the site conditions to determine the specific installation requirements including the fence type, fence condition, fence length, zone layouts, sensor cable route, non- detecting lead cable length, length of sensor cable required to cover the perimeter, and the location for the electronic components.
Page 24: Weld-Mesh Fences
Fence height considerations FiberPatrol will provide a good level of detection for fences up to 3 m (10 ft.) high with a single pass of cable. The single cable pass is installed at one-half the fence height unless the fence includes a middle rail.
Page 25: Razor Ribbon/Concertina
Site survey It is possible to install FiberPatrol sensor cable on barbed wire, but extra precautions must be taken to avoid damage to the sensor cable. Run the sensor cable along the fence and loop the cable up beside the fence posts. Secure the sensor cable to the barbed wire so that the cable avoids contact with the barbs.
Page 26: Gates
Figure 24 Gate bypass Protecting swinging gates with FiberPatrol To cover a swinging gate with FiberPatrol sensor cable, a cable management kit (p/n FPKT0500) is used to protect the sensor cable and allow it to move freely when the gate opens and closes.
Page 27: Gate Protection For Periodically Bypassed Gates (Independent Zones)
(see Figure 28). Attach the isolation loops to the fence with cable ties. The isolation loops must be far enough away FiberPatrol Site Planning & Installation Guide Page 27...
Page 28: Determining Cable Length Requirements For Gates
The cable management kit includes a 1 m length of split conduit, two 1.15 m pieces of split loom and two gear clamps. The split conduit is fitted against the fence post Page 28 FiberPatrol Site Planning & Installation Guide...
Page 29: Protecting Masonry Walls And Buildings
Protecting masonry walls and buildings If some, or all, of the perimeter is comprised of masonry walls or buildings, FiberPatrol sensor cable can be installed along the outside edge, and if necessary, the inside edge of the structure to protect against climb over intrusions.
Page 30: Selecting Conduit For Below Ground Bypasses
Figure 33 Solid wall conduit Solid wall conduit • Both ends of the conduit must be sealed to prevent water from entering the conduit and freezing. Page 30 FiberPatrol Site Planning & Installation Guide...
Page 31: Split Wall Conduit
NOTE: All double arrows indicate 30 cm (1 ft.) separation. All turns must respect the minimum bend radius. Figure 34 Sensitivity loop (heavy gauge post) NOTE: All double arrows indicate 30 cm (1 ft.) separation. All turns must respect the minimum bend radius. Figure 35 Sensitivity loop (corner post) FiberPatrol Site Planning & Installation Guide Page 31...
Page 32: Service Loops
14 in. steel cable tie fence wire 7 loops 60 cm (2 ft.) diameter app. 13 m (43 ft.) of sensor cable Figure 37 Zone boundary isolation loop (fence-mounted) Page 32 FiberPatrol Site Planning & Installation Guide...
Page 33: Cable Bypasses For Buildings And Structures
Otherwise, use the below ground cable bypass method. To ensure the bypass cable will not cause alarms, use a 13 m (43 ft.) isolation loop at each end of the bypass. The isolation loops can be buried in FiberPatrol vaults (see Figure 39).
Page 34: Deploying The Sensor Cable
Figure 40 Perimeter structure bypass (below ground) Deploying the sensor cable Note Install FiberPatrol sensor cable on the side of the fence that is opposite the threat (the secure side of the fence). There are two standard methods of deploying FiberPatrol sensor cable.
Page 35: Site Analysis Checklist
(type, condition, location, size) locate all obstacles on site survey spur fences or fences abutting the perimeter fence sidewalks, paths, roads, driveways buildings, walls and other structures utilities (sewers, pipes, conduits and electrical cables, etc.) FiberPatrol Site Planning & Installation Guide Page 35...
Page 36: Cable Requirements
FiberPatrol system. Specific FP1150 Series software licenses are available for cable lengths of 1 km, 2 km, 3 km, 4 km, 5 km, 9 km, 12 km, 16 km, 20 km, and 25 km.
Page 37: Installing Fiberpatrol
10. Test the system to ensure it meets the site’s detection requirements. 11. Commission the system. Laser light safety FiberPatrol operates with Class 1 laser light levels. The laser light is invisible to the human eye, but can still cause eye damage. WARNING NEVER look directly into the end of a fiber connector.
Page 38: Optical Fiber Safety
Fiber optic cable handling Note Standard FiberPatrol cable (p/n FPSP04XX - XX = number of fibers) typically includes 12, 24, 36, or 48 optical fibers inside 1, 2, 3, or 4 gel filled buffer tubes. The number of tubes and the number of fibers inside each tube may vary, depending on the specific cable used at the site.
Page 39: Cable Loss Limits (Maximum Attenuation)
Ensure the cable is snug against the fence post, but is not pulled tightly and stressed. 50 cm (20 in.) 25 cm (10 in.) 25 cm (10 in.) 50 cm (20 in.) Figure 44 Cable tie spacing at fence posts FiberPatrol Site Planning & Installation Guide Page 39...
Page 40 = 22 cm (8.66 in.) smallest allowable bend radius for installed sensor cable = 11 cm (4.33 in.) Figure 46 Static and dynamic bend radius limits Page 40 FiberPatrol Site Planning & Installation Guide...
Page 41 60 cm cable loops (13 m of sensor cable) 60 cm (2 ft.) diameter attach isolation loops with cable ties at each 45º point around the loop Figure 48 Isolation loops FiberPatrol Site Planning & Installation Guide Page 41...
Page 42 (e.g., service loops, gates, bypasses) lay the cable on the ground in a large figure 8 pattern to prevent twisting or kinking. Never lay the cable in a circular roll. Figure 50 Laying cable in a figure-8 pattern Page 42 FiberPatrol Site Planning & Installation Guide...
Page 43: Fiberpatrol Sensor Cable And Below Ground Bypasses
FiberPatrol sensor cable and below ground bypasses FiberPatrol sensor cable typically passes through conduit that is buried below ground to get from one side of a gate to the other. There are several techniques that can be used to pull the cable through conduit.
Page 44: Attaching The Sensor Cable
6. If the installation extends past the end of this cable reel, leave enough cable to make a 10 m service loop for the splice, and continue deploying the sensor cable. Attaching the sensor cable FiberPatrol sensor cable is attached to the fence fabric with stainless steel cable ties. Figure 52 an overview of the recommended cable attachment procedure.
Page 45: Attaching The Sensor Cable At Protected Gates
8. Form a sensitivity loop and attach the sensor cable to the fence panel leading up to the gate. 9. Form a sensitivity loop and attach the sensor cable to the fence panel leading away from the gate. FiberPatrol Site Planning & Installation Guide Page 45...
Page 46: Masonry Walls And Buildings
Figure 55 Masonry surface P-clamp spacing 1. Measure and mark the mounting hole locations on the surface. 2. Using a 5/32 carbide-tipped bit, drill the mounting holes 1 1/2 in. deep. Page 46 FiberPatrol Site Planning & Installation Guide...
Page 47: Sensor Cable Verification And Test
Control equipment installation The FiberPatrol electronic control components are designed to be installed in an EIA 19 in. equipment rack. The rack requires a mounting depth of 20 in. (51 cm) plus a minimum 2 in. (5 cm) of front space between the equipment and the rack doors and at least 6 in.
Page 48: Fiberpatrol Splices
The FiberPatrol sensor unit operates on 100 to 240 VAC 50/60 Hz and consumes 200 W maximum. The sensor unit requires 2 independent AC receptacles. An additional AC receptacle is required if the optional rack-mount keyboard/monitor/mouse is being used at the site.
Page 49: Maintenance
Maintenance Recommended maintenance The FiberPatrol system requires minimal maintenance to ensure proper operation. However, setting up and following a maintenance schedule based on your site-specific requirements can ensure proper detection performance, prevent nuisance alarms and extend the operational lifetime of the system. The frequency at which the maintenance should be scheduled depends on your security requirements and on the installation environment.
Page 50 Any dust or contamination will compromise system operation. 6. Battery test (once per year) If your FiberPatrol system includes battery back-up, disconnect the power to the components and allow the system to run on battery power until the battery runs down and the system shuts down.
Page 51: System Diagnostics
When FiberPatrol software detects an error condition, it alerts local and remote operators by reporting the corresponding System Status and generating Head End alarms. The System Status indicator in the lower left corner of the FiberPatrol software interface can show four general states: •...
Page 52: Local Systems
System Diagnostics If other equipment at the site is still communicating, but the FiberPatrol system is not, then it could be a FiberPatrol system failure, requiring a site visit for further diagnostics. Local Systems Locally, the state of the system can be quickly assessed by checking the sensor unit Alarms screen.
Page 53: Troubleshooting Procedures
Troubleshooting procedures This section outlines the procedures to follow when checking, or troubleshooting an installed FiberPatrol system. The initial steps in addressing a system malfunction are: • System inspection •...
Page 54: Fiberpatrol Software Check
System Diagnostics • Frozen with a Windows screen • Frozen with a FiberPatrol software screen • BIOS error screen • Windows error message FiberPatrol software check If the sensor unit (computer) is responsive, document any of the following conditions: •...
Page 55: Sensor Unit Reboot
OFF, waiting at least 30 seconds, and then turning the power switch back ON. • Shut down the FiberPatrol software via the Exit function (under the System menu) • Reboot the computer via the Windows Restart function •...
Page 56 System Diagnostics Page 56 FiberPatrol Site Planning & Installation Guide...
Page 57: Ids Software Environment
5 IDS software environment FiberPatrol Sensor Unit The FiberPatrol sensor unit (SU) uses the Windows 10 pro 64-bit operating system. The SU comes with the FiberPatrol Intrusion Detection System (IDS) software and software license installed. The FiberPatrol documentation is available on a USB drive.
Page 58: Operator Access Level
SU is powered up. Launch FiberPatrol.exe also monitors the sensor unit and will restart the FiberPatrol IDS software when it detects that the program is not running. User access to the SU is via the keyboard monitor mouse unit in the equipment rack.
Page 59: Configuration & Calibration
FiberPatrol software will auto-start when the sensor unit is powered up. Once the FiberPatrol software is running, it will restart automatically if it is shut down by the user. When FiberPatrol is starting, a window displays the time remaining until the software is launched.
Page 60: Safe Start
Figure 60 FiberPatrol System Status panel during initial startup Safe Start The FiberPatrol FP1150 series launches into safe start mode during the initialization process. Safe start mode prevents potential damage to the photo-detectors that can be caused by incorrect fiber installation.
Page 61 1. A warning will be displayed asking the user to login at the installer level if the software detects a possible cross-fiber connection. Figure 62 FiberPatrol Safe Start Warning After logging in as the Installer, the user will be prompted to disconnect one of the sensor cables from the processor (if a cross-connection is suspected).
Page 62 5. If no problems are detected with the sensor cable installation a Safe Start Check complete message will display. At this time the installer should select Skip SafeStart in the Future. Figure 66 SafeStart Check Complete Page 62 FiberPatrol IDS Software Guide...
Page 63: Fiberpatrol Sensor Cable Configurations
Status fields Figure 67 FiberPatrol default Alarm screen (installer access level) FiberPatrol sensor cable configurations Figure 68 illustrates the most common FiberPatrol sensor cable configurations. Refer to FiberPatrol configurations on page 17 for additional sensor cable configurations and installation details.
Page 64: System Configuration
Select the System tab on the Alarm Screen window. Figure 69 illustrates the System window for the FP1150 Series sensor. The numbered points in the illustration correspond to the configuration procedure that follows. CAUTION The FP1150 configuration settings should be adjusted only by a factory trained technician.
Page 65: Global Setup
3. Once the lengths and Medium are specified the system will automatically set the Pulse Rate, Frame Rate, Low Frequency, High Frequency, System End, Set End and if checked, the Environment Compensation will also be set. FiberPatrol IDS Software Guide Page 65...
Page 66: Troubleshooting Dialog
The FP1150 configuration settings should be adjusted only by a factory trained technician. Setting up the FiberPatrol system is best done by two people who are in communication during the procedure. One person walks around the perimeter and taps the sensor cable to mark the features of the site for the system software.
Page 67: Location Calibration - The Tap Test
Calibration setup In FiberPatrol installations, the actual length of the sensor cable does not match the length of the protected fence. Adjustments must be made for the non-sensing lead cable between the equipment room and the fence, as well as for site features that require extra sensor cable (i.e., gates, bypasses, service loops, sensitivity loops, isolation loops).
Page 68: Location Calibration For Loop Configurations
For Sensor 1, the FiberPatrol cable between the Sensor Unit and the detection start point on the fence must be set to non-sensing. For Sensor 2 the end of the FiberPatrol sensing region must be defined. Adjust the Detection Settings (see Tap test setup on page 67).
Page 69: Calibrating The Set Start For Sensor 2 And Set End For Sensor 1 (Loop Configurations)
For Sensor 2, the FiberPatrol cable between the Sensor Unit and the start point of the perimeter must be set to non-sensing. For Sensor 1 the end of the FiberPatrol sensing region must be defined. Adjust the Detection Settings (see Tap test setup on page 67).
Page 70: Calibrating The Sensor 2 Offset (Loop Configurations)
134 m + 2734 m = 2868 (Sensor 2 Offset) 3. Set the Sensor 2 Offset to the above result. 4. Set the Sensor 2 Scale to -1. 5. Save the configuration (select the Configure menu > Save Configuration). Page 70 FiberPatrol IDS Software Guide...
Page 71: Calibration Setup For Split Configurations
1. Conduct a series of 3 tap tests to create 3 alarms at location 0. Location 0 is at the S1 end module and represents the start point of detecting cable. 2. Verify that the alarm results are not negative (must be a positive value). FiberPatrol IDS Software Guide Page 71...
Page 72: Location Calibration For Split Configurations
Figure 79 Tap test location - Set Start (line configuration) Note The FiberPatrol cable between the Sensor Unit and the start point of the perimeter fence must be set to non-sensing. 1. Set the Sensor 1 Offset = 0, Sensor 1 Scale = 1, Sensor 2 Offset = 0, Sensor 2 Scale = 1.
Page 73: Calibrating The Set End Position (Line Configurations)
Calibrating the Set End position (Line configurations) Note The end of the FiberPatrol sensing cable must be defined. The Set End values for Sensor 1 and Sensor 2 define the end location of the sensor. 1. Proceed to a location that is 10 m (33 ft.) before the end point of the sensing cable and conduct a series of 3 tap tests at this location, waiting at least 15 seconds between tests.
Page 74: Locating The Site Features And Zone Boundaries
Calculate the average location of each series of 3 tap tests for each feature and Zone boundary location and record the result in the Location/calibration table. 4. Make a copy of the completed Location/calibration table and keep it in a safe place. Page 74 FiberPatrol IDS Software Guide...
Page 75 Note The FiberPatrol system uses “soft” zone boundaries, which are defined in software. The location resolution of FiberPatrol is 4 m (13 ft.). Therefore, if CCTV coverage will be used for alarm assessment there should be an overlapping field of view of at least 8 m (26 ft.) at all zone boundaries (see Figure 81).
Page 76: Zone Boundary And Site Feature Identification
The following figures illustrate the types of features that should be identified and located on the FiberPatrol map. To accurately locate and display alarms on a scale site map, the FiberPatrol software requires the locations of the start point of sensing cable; the end point of sensing cable;...
Page 77: At Splice Locations
1 panel away from gate tap cable 1 panel away from gate Figure 86 Tap test location - gate (part of zone, no service/isolation loops) FiberPatrol IDS Software Guide Page 77...
Page 78: At Bypass Locations
Figure 89 Tap test location - non-linear cable deployment Page 78 FiberPatrol IDS Software Guide...
Page 79: At Zone Boundary Locations
Figure 90 Tap test location - service loops At Zone boundary locations Tap the cable at the location of all soft zone boundaries. Zone 1 Zone 2 tap cable at zone boundary Figure 91 Tap test location - zone boundaries FiberPatrol IDS Software Guide Page 79...
Page 80: Creating The Site Map
Creating the site map Creating the site map The FiberPatrol IDS software can display alarms on a graphical site map created from a satellite image. The map is created with the IDS Map Manager software, and is imported into the FiberPatrol IDS software.
Page 81 2. To start a New Project select Project > New Project... The New Project window displays: Figure 95 New Project dialog 3. Enter the Site ID (use any 6 digit number) and Site Name, and then select OK. FiberPatrol IDS Software Guide Page 81...
Page 82 7. Add a device; select Project > New Device... Figure 98 Add New Unit dialog • Enter the IP address of the FiberPatrol sensor unit (if you don’t know the sensor unit’s IP address, enter 127.0.0.1). Page 82 FiberPatrol IDS Software Guide...
Page 83: Creating The Perimeter
A minimum of 4 vertices are required for the map creation process. 1. Select and highlight the Sensor in the Project tree. Select the Perimeter Editor tool, and then select the Perimeter Extender tool. The Zoom level should fully display the site’s protected perimeter. FiberPatrol IDS Software Guide Page 83...
Page 84 Note For line configurations, the last node can be left unconnected. For closed loop configurations, the start and end nodes must be the same. Page 84 FiberPatrol IDS Software Guide...
Page 85: Select The Area Of Interest (Aoi)
Figure 102 Selecting the Area of Interest 3. Select the Extract AOI button. increase the zoom when either Image Width or Height is approximately 1000 select OK Figure 103 Extracting the Area of Interest FiberPatrol IDS Software Guide Page 85...
Page 86: Importing Configuration Files Into The Fiberpatrol Ids Software
ORIG to the end of the file name before the extension (e.g., IDS map calibration ORIG.txt). 3. On the FiberPatrol sensor unit, copy the three IDS Map Manager configuration files into C:\FiberPatrol\Configuration. 4. Go to the Configure menu, and select Load Configuration.
Page 87 Figure 105 Verifying the Map image 5. Go to the Help menu, and select About FiberPatrol. Change the Site ID and Unit ID to the appropriate numbers. Verify that there are no License Errors. Enter the appropriate details...
Page 88: Defining The Zone Boundaries (Zone Definitions)
For a fully closed perimeter, the end point location of the final Zone must be the same as the start point location for the first Zone. Note The FiberPatrol FP1150 sensor supports up to1440 distinct alarm zones. Note The Zone Definition dialog includes error checking to prevent errors in setting up the detection zones.
Page 89: Remote Interface/Alarm Output Setup
Interface Mode is a drop-down menu that selects the remote interface type from the available options. The following are two of the standard options. • In TCP/IP Server mode, the FiberPatrol IDS implements a TCP/IP server. It accepts a single connection through the default Port (4122). FiberPatrol IDS Software Guide...
Page 90: Setting Alarm Detection Parameters
Setting Alarm Detection Parameters • In TCP/IP Client mode, the FiberPatrol IDS implements a TCP/IP client. It connects to a TCP/IP server via the specified IP Address and Port. Note Select Server mode for NMI applications. • The IP Address specifies the remote server’s IP address when TCP/IP Client mode is in use.
Page 91: Intrusion Simulation Tests
Save Raw Data at the beginning of each test, and stop it when the test is completed. To test the FiberPatrol sensor you conduct simulations for both cut and climb intrusions. Using the Save Raw Data function, thoroughly test the detection along the full length of the sensor cable, while recording each test.
Page 92: Simulated Cut Intrusion Tests
Simulated climb intrusion tests on page 92). 4. On the FiberPatrol sensor unit, access the Signal sub-panel and observe the Disturbance display and Alarm status. Note the magnitude of the disturbance, and how quickly the gray bars turned to red (signaling an alarm). Repeat the climb test five times to determine how a typical climb intrusion appears on the display.
Page 93: Setting Zone Specific Sensitivity Thresholds
5. Perform a series of intrusion tests to verify the new settings. 6. Repeat this procedure for each Zone. Note You must select Apply, and then select Replace for the sensitivity changes to take effect. FiberPatrol IDS Software Guide Page 93...
Page 94: Fine-Tuning Detection Parameters
The values for the start and end locations use the same unit that was chosen in the System panel (meters or feet). Multiple different sections can be defined for Temporal Environment Compensation. Page 94 FiberPatrol IDS Software Guide...
Page 95: Spatial Compensation
Motion Rejection – Parallel settings should be used to prevent these nuisance alarms. To open the Motion Rejection – Parallel settings panel, go to the Service menu and then select Motion Rejection – Parallel (see Figure 112). Figure 112 Motion Rejection - Parallel panel FiberPatrol IDS Software Guide Page 95...
Page 96: Motion Rejection - Perpendicular Settings
Rejection – Perpendicular settings can be used to reject these nuisance alarms. To open Motion Rejection – Perpendicular settings panel, go to the Service menu and then select Motion Rejection – Perpendicular (see Figure 113). Page 96 FiberPatrol IDS Software Guide...
Page 97 Upper Threshold 1 and Upper Threshold 3 settings (time slots 1 and 3) to reject a perpendicular motion event. Upper Threshold 1 and Upper Threshold 3 are defined as a percentage of the maximum Disturbance signal in time slot 2. FiberPatrol IDS Software Guide Page 97...
Page 98: Save Raw Data
The Repeat checkbox will replay the selected data when checked. Frequency Display The FiberPatrol FP1150 Series sensor includes a Frequency Display window for each sensor, under the Service menu. In Zone Mode, the Frequency Display window enables an advanced user to view signal amplitudes on a zone by zone basis.
Page 99: Additional Installer Level Settings
It also enables an advanced user to troubleshoot the system by checking the status of the hardware components of the SU. Note DO NOT adjust the Troubleshooting Settings without direct technical support. FiberPatrol IDS Software Guide Page 99...
Page 100: Configuration File Safety Backup
Once the system is setup and configured, it is strongly recommended that a backup copy be made of the configuration folder: C\FiberPatrol\Configuration. Save the Configuration folder to removable media so the configuration data can be reloaded in the event of a catastrophic system failure.
Page 101: Operator's Functions
Event Duration The length of time between the beginning and the end of the disturbance. Event Level The cumulative amount of disturbance over the event duration. FiberPatrol IDS Software Guide Page 101...
Page 102: Auto-Start Routine
After a one-minute delay for the initialization process to complete, the FiberPatrol IDS main panel opens, with the FiberPatrol login window displayed. • If login information is not entered within one minute, the FiberPatrol IDS will start at the Operator access level with the user name “LocalOperator”. Manual Windows login The FiberPatrol system can be configured for manual startup.
Page 103: Fiberpatrol Operator Control Panel
The Factory Service access level is not available. FiberPatrol Operator Control Panel The FiberPatrol Operator Control Panel provides access to the Alarms and the Alarm History sub- panels. The Alarms Sub-Panel is the default display of the FiberPatrol Software Interface. It displays detailed attributes of current alarms and enables the Operator to process alarms via the Clear Alarm button.
Page 104: System Status
System Status, Alarm Status, and Alarm Location fields Figure 119 Operator Alarms panel (2 alarms) System Status The System Status field displays information on the current state of the FiberPatrol system (see Figure 119). The System Status messages include: •...
Page 105: Menu Bar
Grayed out menus and menu items are not available Figure 120 FiberPatrol Operator menus The following is a summary of the FiberPatrol Operator menu items: System menu Login - displays the login window, used to change the access level while the system is running...
Page 106: Clear Alarm Button
The time the alarm was cleared and the Operator’s comments are included in the Event Log. • The Apply button saves the Operator’s comments and closes the Alarm Dialog without clearing the alarm. Additional comments can be added and the alarm can be cleared later. Page 106 FiberPatrol IDS Software Guide...
Page 107: Alarm History Sub-Panel
Actions Taken Clear Alarm button Figure 122 FiberPatrol Alarm Dialog Once the alarm is cleared, the Alarm Dialog closes and the selected alarm is removed from the Current Alarms list and Map Display. The details of the cleared alarm are accessible through the Alarm Log on the Log sub-panel for the remainder of the day (until archived).
Page 108 Page 108 FiberPatrol IDS Software Guide...
Page 109: Supervisor's Functions
(archived) and cleared from the Log display at midnight, as well as each time the FiberPatrol sensor unit is shut down. The archived Log Files are permanent records and can be used for reviewing the FiberPatrol system activity beyond the current 24-hour time window.
Page 110: The Signal Sub-Panel
FP1150 Signal sub-panel. Note Do not adjust the Filter Cutoffs without direct technical support. A value of 0 in the High Frequency display box indicates that the High Frequency filter is set at the maximum value. Page 110 FiberPatrol IDS Software Guide...
Page 111: Disturbance Signal Display Graphs
Selecting the Waterfall button opens 2 waterfall graphs of Sensor 1 and sensor 2. Supervisor menus The Supervisor access level provides access via the menu bars to various functions that enable system configuration and test. Figure 128: FiberPatrol Supervisor’s menu bar FiberPatrol IDS Software Guide Page 111...
Page 112: System Menu
System > Login - Displays the Login Dialog that is used for changing the Access Level while the FiberPatrol software is running. If an incorrect password is entered or the Cancel button is selected, the software continues to run with the same Access Level.
Page 113: Service Menu
Status dialog includes a Raid Alerts button to check the status of the Raid hard drives. 1. Select Service > Status. Figure 129: FiberPatrol Status dialog 2. Select the Raid Alerts button on the Status dialog. Figure 130: FiberPatrol Status dialog 3.
Page 114: Supervisor Functions
2. Select a table cell to edit the Zone’s attributes. 3. Right-click on the table to add/delete Zones. 4. Save the Zone definition by selecting the Apply button. Figure 131: FiberPatrol Zone Definition dialog • The Start Location and End Location define the location range (length) of the corresponding zone.
Page 115: Zone Masking (Access)
(All Zones can be Masked by selecting De-Activate All). 3. Select De-Activate to Mask the selected Zone. 4. Select Schedule to setup a Schedule for when the Zone will be Masked automatically by the system. FiberPatrol IDS Software Guide Page 115...
Page 116: Password Maintenance
The Change Password dialog enables the Supervisor to assign and change passwords for system users. There is one password available for each level of user access. Figure 133: FiberPatrol Change Password dialog 1. Select Manage > Password Maintenance. 2. Select the Access Level for the User.
Page 117: Remote Interface
2. Specify the time period after which the Alarms will automatically clear. 3. Check the Upon Completion checkbox for alarms to clear automatically when completed. 4. Apply the changes. Figure 134: FiberPatrol Alarm Auto Clearing Settings Remote Interface Select Configure > Remote Interface to display the Remote Communications Interface dialog. This dialog provides access to the Remote Interface Controls.
Page 118 Page 118 FiberPatrol IDS Software Guide...
Page 119: System Component List
Description FiberPatrol sensor unit FP1150XX FiberPatrol sensor unit for fence mounted applications: up to XX km of cut-immune detection processing up to 2 x XX km of non cut-immune detection processing XX variants = 01, 02, 03, 04, 05, 09, 12, 16, 20, 25...
Page 120 1 m (3.3 ft.) section and two gear clamps for sensor swinging gate protection cable installation at protected swinging gates FiberPatrol connector GX0313 fiber technician connector cleaning kit for FiberPatrol applications cleaning tool kit FiberPatrol installation tool GX0314 fiber technician tool kit customized for FiberPatrol applications Contact Senstar for information on ordering FiberPatrol sub-assemblies.
Page 121: Specifications
FPSP04XX (XX = no. of fibers: 12, 24, 36, 48) Sensor cable part number • armored cable FPSP0624 (24 fibers) • FP1150 Series approximately 12 km (7.5 mi) Max. length per reel • optional number of fibers: 12, 24, 36, 48 (2 required as sensor fibers, Fiber count remaining dark fibers available for perimeter applications) •...
Page 122 • used to prevent nuisance alarms caused by vehicles approaching Perpendicular motion the sensor cable directly, or passing through frequently used gates, rejection and by planes passing over fences at airports Page 122 FiberPatrol Site Planning & Installation Guide...
Page 123: Location/Calibration Table
Location/calibration table tap point # description time/location 1 time/location 2 time/location 3 avg. location FiberPatrol Site Planning & Installation Guide Page 123...
Page 124 # description time/location 1 time/location 2 time/location 3 avg. location Page 124 FiberPatrol Site Planning & Installation Guide...
Page 125: Remote Alarm Output
For Network Manager alarm reporting the most common Report Mode is either 0 or 6. In the default configuration, the FiberPatrol sensor unit provides a TCP/IP server with one available connection for interfacing to a remote security management system (SMS). Additional connections can be configured (restrictions apply).
Page 126: Communication Timing
Communication timing By default, FiberPatrol alarm reports are transmitted approximately once per second. When a new alarm is generated, a report with the new alarm information is transmitted immediately. Alarm information is transmitted for as long as an alarm is active (typically, for the duration of an event plus 60 seconds).

This manual is also suitable for:

Fp115001 Fp115002 Fp115003 Fp115004 Fp115005 Fp115009 ... Show all
