GRIDMESH ANCHOR GA03 User Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL GA03
USER INSTRUCTION MANUAL
FOR MATERIALS HANDLING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA03 and is the answer not in the manual?

Questions and answers

Summary of Contents for GRIDMESH ANCHOR GA03

  • Page 1 MODEL GA03 USER INSTRUCTION MANUAL FOR MATERIALS HANDLING...
  • Page 2 This manual should be used as part of an employee training program. DESCRIPTION: The Gridmesh Anchor (GMA) is designed to be a part of a hauling system for use on suitable steel structures that are covered by trafficable gridmesh. This application might typically be in processing plants, on oil rigs and other applications in chemical plants, mining and oil &...
  • Page 3 The device can be installed in under 5 minutes with two people. The Gridmesh Anchor concept may also be used as an attachment point for fall protection and Compatibility of Connectors: Connectors are compatible with connecting elements rescue - see user manual for fall protection for more information.

  • Page 4: Installation

    610 UB 101 D. Inspection: Parallel Flange Channel Before installing the Gridmesh Anchor on the mesh, both the mesh and its Un-equal angle structure should be visually inspected to confirm that it will hold hauling loads. If there is Rectangular hollow section...
  • Page 5 2. Open the storage bag and lay the GMA base 4. Open the GMA lid and remove the rope tag-line, onto the gridmesh walkway area. Be sure to wire sling and support beam. Connect the end of align the load points of the GMA onto a location the sling to the rope tag line.
  • Page 6 6. Lower the rope tag line ‘sling first’ through the 8. Haul the sling with chainblock/block & tackle GMA base and the slot in the gridmesh. It may attached by pulling the rope back through be necessary to squeeze the eye of the sling so the gridmesh, such that the end of the sling that it fits through the mesh.

  • Page 7: Operation

    To avoid swinging loads, locate the load to be hauled as close to a position directly under the Gridmesh Anchor as possible. Utilise the green webbing line to attach to the load to reduce the risk of swinging during 11.

  • Page 8: Specifications

    5.0 Inspection 7.0 Specifications Inspection Frequency: The Gridmesh Anchor has been tested to ensure it is capable to performing to the rated load requirements. The Gridmesh Anchor should be periodically inspected as follows. Before each use: An inspection of the Gridmesh Anchor by a competent person must be...

  • Page 9: Limitation Of Warranty

    This warranty will not apply to and Gridmesh Anchor will not accept liability for defects that result from product abuse, misuse, alteration or modification, or for defects that are due to a failure to install, maintain or use the product according to the manufacturer’s instructions.
  • Page 10 MODEL GA03 USER INSTRUCTION MANUAL FOR MATERIALS HANDLING...
  • Page 11 This manual should be used as part of an employee training program. DESCRIPTION: The Gridmesh Anchor (GMA) is designed to be a part of a hauling system for use on suitable steel structures that are covered by trafficable gridmesh. This application might typically be in processing plants, on oil rigs and other applications in chemical plants, mining and oil &...
  • Page 12 The device can be installed in under 5 minutes with two people. The Gridmesh Anchor concept may also be used as an attachment point for fall protection and Compatibility of Connectors: Connectors are compatible with connecting elements rescue - see user manual for fall protection for more information.
  • Page 13 610 UB 101 D. Inspection: Parallel Flange Channel Before installing the Gridmesh Anchor on the mesh, both the mesh and its Un-equal angle structure should be visually inspected to confirm that it will hold hauling loads. If there is Rectangular hollow section...
  • Page 14 2. Open the storage bag and lay the GMA base 4. Open the GMA lid and remove the rope tag-line, onto the gridmesh walkway area. Be sure to wire sling and support beam. Connect the end of align the load points of the GMA onto a location the sling to the rope tag line.
  • Page 15 6. Lower the rope tag line ‘sling first’ through the 8. Haul the sling with chainblock/block & tackle GMA base and the slot in the gridmesh. It may attached by pulling the rope back through be necessary to squeeze the eye of the sling so the gridmesh, such that the end of the sling that it fits through the mesh.
  • Page 16 To avoid swinging loads, locate the load to be hauled as close to a position directly under the Gridmesh Anchor as possible. Utilise the green webbing line to attach to the load to reduce the risk of swinging during 11.
  • Page 17 Inspection Frequency: The Gridmesh Anchor should be periodically inspected as follows. The Gridmesh Anchor has been tested to ensure it is capable to performing to the rated load requirements. Before each use: An inspection of the Gridmesh Anchor by a competent person must be...
  • Page 18 This warranty will not apply to and Gridmesh Anchor will not accept liability for defects that result from product abuse, misuse, alteration or modification, or for defects that are due to a failure to install, maintain or use the product according to the manufacturer’s instructions.
