Summary of Contents for vufold INTU Micro
- Page 1 Fitting Instructions Micro Beadfit Blinds...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS INTU Micro Beadfit What you will need Supplied : Bracket Fitting Top Corner Bottom Corner Tool Brackets Brackets P Clips Side Extrusions Not Supplied : Scissors Scan our QR code to view our fitting video or visit www.vufold.co.uk... -
Page 3: Installation Steps
INSTALLATION STEPS INTU Micro Beadfit Place the top corner bracket into the top left slot on Position the bracket behind the rubber seal at the top the bracket fitting tool. right corner of the frame. Carefully push until the metal legs are behind the rubber seal. - Page 4 Place the bottom corner bracket into the bottom left Position bracket behind the rubber seal at the slot on the bracket fitting tool. bottom right corner of the frame. Carefully push until the metal leg is behind the rubber seal. Check the bracket is square to the sides of the frame and fully secure.
- Page 5 Remove the endcap covers from the headrail by At the appropriate position(s) on each side profile, fit pulling them off. retention clips (long side profiles only). Press into position using the fitting tool. Remove the Velcro straps that wrap around the Remove the cords from the elastic band and allow to hang from the blind.
- Page 6 If your blind requires further tension, pull the cord Cut and remove the elastic bands from the blind. through the hole in the bottom button until you feel the Test the tension by raising the blind, ensure it stays fully blind has sufficient tension and tie a fresh knot.
-
Page 7: Contact Information
CONTACT INFORMATION Call : 01625 442899 Email : aftercare@vufold.co.uk Web : www.vufold.co.uk...
