ARMOTECH WG65 SERIES PAINTBALL MARKER OWNER'S MANUAL

WARNING

ARMOTECH PAINTBALL MARKERS ARE NOT A TOY. ANY MISUSE MAY CAUSE SERIOUS INJURY OR DEATH.

THE USER AND ANY PERSON WITHIN RANGE MUST WEAR EYE PROTECTION DESIGNED FOR PAINTBALL USE.

READ THIS OWNER'S MANUAL COMPLETELY BEFORE LOADING, PRESSURIZING, OR OPERATING YOUR

ARMOTECH PAINTBALL MARKER.

This paintball marker is intended for sale to adults only, for use in compliance with all applicable laws and regulations. Adult

supervision is recommended at all times whenever a minor is handling this paintball marker. All persons within range MUST wear

protective goggles & headgear specifically designed for paintball when a paintball marker is in use. Paintball safety rules must be

followed at all times.

John L.R. Dovale, Dangerous Enterprises. Imagery by Mark Chance, Island Designs (ala Section 8)

Armotech International / Armotech Taiwan Ltd.

ARMOTECH WG065 OWNER'S MANUAL, Compiled for ARMOTECH International, by

6F No 10 Sec 4 Tzu Chiang Rd, San Chung, Taipei Hsien, Taiwan R.O.C.

Technical support forum

http://www.armotech.net

, http://www.armotech.us

http://www.armotech.us/forum

Table of Contents

Need help?

Do you have a question about the WG65 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ARMOTECH WG65 Series

Page 1 ARMOTECH WG65 SERIES PAINTBALL MARKER OWNER’S MANUAL WARNING ARMOTECH PAINTBALL MARKERS ARE NOT A TOY. ANY MISUSE MAY CAUSE SERIOUS INJURY OR DEATH. THE USER AND ANY PERSON WITHIN RANGE MUST WEAR EYE PROTECTION DESIGNED FOR PAINTBALL USE. READ THIS OWNER’S MANUAL COMPLETELY BEFORE LOADING, PRESSURIZING, OR OPERATING YOUR ARMOTECH PAINTBALL MARKER.
Page 2: Table Of Contents
Cleaning Lubing in any manner. Cupseal Maint. Stock Adjustment ARMOTECH WG065 OWNER’S MANUAL, Compiled for ARMOTECH International, by John L.R. Dovale, Dangerous Enterprises. Imagery by Mark Chance, Island Designs (ala Section 8) Armotech International / Armotech Taiwan Ltd. http://www.armotech.net , http://www.armotech.us 6F No 10 Sec 4 Tzu Chiang Rd, San Chung, Taipei Hsien, Taiwan R.O.C.
Page 3: Paintball Safety Rules
Paintball Safety Rules Safety First! WARNING ARMOTECH PAINTBALL MARKERS ARE NOT A TOY. ANY MISUSE MAY CAUSE SERIOUS INJURY OR DEATH. THE USER AND ANY PERSON WITHIN RANGE MUST WEAR EYE PROTECTION DESIGNED FOR PAINTBALL USE. READ THIS OWNERS’S MANUAL COMPLETELY BEFORE LOADING, PRESSURIZING, OR OPERATING YOUR ARMOTECH PAINTBALL MARKER.
Page 4 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E the Paintball Park or field where the marker is in use.
Page 5: Operating Instructions
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Operating Instructions WARNING Every person within range of this paintball marker must...
Page 6 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E button again will put the marker in 3-BURST mode.
Page 7 FIRE position and then squeeze the trigger with an even pressure. The cocking knob should snap forward into the un-cocked position. You have just dry-fired your Armotech marker. Do this a few times until you are comfortable with this operation and the feel of the marker when cocking, and firing it.
Page 8: Compressed Air/Gas
Follow safety rules for handling compressed air/gas. If any leaks occur in the power system, refer to troubleshooting section or Armotech support. Use only cylinders for compressed gas or air that comply with all applicable laws and...
Page 9 P E R F E C T G A M E The ARMOTECH paintball marker may be powered by CO2, regulated compressed air (HPA), or regulated nitrogen. From the source of gas or air through the entire power system, there are varying pressures that are applied to the marker and the components of the power system.
Page 10: Co2 Safety
330 p.s.i. or pressures over 1200 p.s.i. it is recommended that the specified operating pressure of the Armotech marker be used in order to avoid problems.) • Never exceed recommended pressures, as this may be dangerous to you and damaging to the marker.
Page 11 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E •...
Page 12 • The velocity knob is located at the back on the receiver (marker body). On the Armotech WG65, 65E, marker this velocity adjuster can be turned by hex tool only. On the Wg65A1 and A2 there is NO adjustment screw for velocity.
Page 13 • Velocity of the marker can also be affected or controlled by the settings of a regulated air/gas supply. On the Armotech WG series an aftermarket regulator would have to be added for CO2 users (such as the palmer stabilizer, or the CM2000 from fun supply).
Page 14: E-Trigger Operations
180mA rating. • The Armotech Electronic trigger frame is outfitted with an electronically controlled SAFE switch. The SAFE switch is located on the left-hand side of the trigger frame just above and to the back of the trigger assembly.
Page 15 • Armotech recommends that this marker be used with some form of agitated or force fed electronic loader/ball feeder if a player plans to use burst mode or full auto mode on the trigger frame.
Page 16: Specifications
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Chapter WG Series Marker Specifications...
Page 17: Wg Parts & Diag
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Parts Listing &...
Page 18 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E 17.
Page 19: Trigger Parts
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Semi Trigger Frame Cross Section of Parts E-Trigger Frame Cross Section of Parts WG SERIES 17...
Page 20: Lubrication
HAVE BEEN ASKED TO DO SO BY AUTHORIZED ARMOTECH SERVICE TECHNICIANS. TIGHTENING SCREWS • Armotech ships all markers only lubed with machine oil and with most of the screws lightly tightened to allows for expansion and contracting from changes of temperature and pressure during shipping process. As...
Page 21 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E properly aligned in reference to the rear sight (tighten barrel first, align these elements after) in order to have the best performance.
Page 22: Assembly/Adjust
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E PROPER ASSEMBLY AND ADJUSTMENTS Ball Detent Adjustment Unscrew the retaining bolts holding the ball detent plate, then remove the...
Page 23: Sight Adjustment
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Sight Rail and Rear Sight Adjustment Ensure that the rear sight rail and carry handle are secure –...
Page 24: Cleaning Lubing
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E CLEANING AND LUBRICATION OF INTERNALS •...
Page 25 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E •...
Page 26 RECOMMENDED LIST OF ITEMS WHICH SHOULD BE KEPT AS SPARES, OR REPLACEMENT PARTS • Teflon or Urethane O-rings, • Rubber bottle and ASA O-rings, • ARMOTECH spare parts/spring kit Extra 9v rechargeable battery if you have an e-trigger Replacement cup seal (original or a black magic) WG SERIES 24...
Page 27: Cupseal Maint
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E CUP SEAL MAINTENANCE Unscrew the VOLUMIZER (counterclockwise).
Page 28 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Reassemble –...
Page 29: Stock Adjustment
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E COLLAPSING STOCK ADJUSTMENT PROCEDURE On some older versions of the WG marker which came with bolts that had longer back-end sections, tightening of the stock too far in could...
Page 30: Troubleshooting
A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E Chapter Troubleshooting Tips, Hints ‘n Tricks...
Page 31 The other most common leak that could occur after some time is the cup-seal. This is easily replaced with an Armotech cup-seal or any spyder compatible equivalent – the BLACK MAGIC cup-seal is highly recommended to cure cup-seal leaks.
Page 32 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E •...
Page 33 • Balls roll out of the barrel or shoots 2 at a time: o Ball bore is too small. It needs to be .689 o Armotech recommends using tournament quality paint § RPS / PMI Brand (Big Ball/Warrior, El Tigre, Slam, All Star, Premium, Premium Gold, Marballizer) §...
Page 34 Min pressure should not be less than 450 p.s.i. Optimal is 550 to 750 p.s.i. o Check your main striker spring, it may be too short. If so replace with original armotech WG spring kit, or with 32-degrees madman gold spring. • Powerfeed wobbles a bit when hopper is attached o Check to ensure the retainer screws have not come undone.
Page 35: Warranty Info
WARRANTY CLAIMS USA customers: Attach your name, address, description of problem, phone number and copy of sales receipt to product. Package and return to Armotech US P.O. Box 607 Berlin, NJ 08009. International Customers: Please return product to your nearest distributor.
Page 36 A R M O T E C H – T H E P E R F E C T M A R K E R … T H E P E R F E C T G A M E SUGGESTED ITEMS FOR PROPER MAINTENANCE Flexible Squeeqee Rod Squeege with Swab on the end...
