Savvier Fitness Booty Kicker BK200 Use And Assembly Instructions

A n i n n o v a t i o n p o w e r e d b y S a v v i e r F i t n e s s
Use and Assembly Instructions
Video instructions can be found at www.BootyKicker.com/Instructions
Congratulations on receipt of your Fitness Barre. The innovative patent
pending design will provide you with great Barre fitness workouts that will
kick your booty, tighten your abs and tone your entire body.
CAUTION! READ ALL INFORMATION BEFORE USE.
SERIOUS INJURY OR FATALITY MAY OCCUR
- The Booty Kicker is not a toy. Keep out of reach of children.
- Always check with your physician before starting this or any exercise program.
- Do not use the Booty Kicker for anything other than its intended exercise purpose.
Use only as shown, illustrated and intended.
- Do not attempt any type of gymnastic movements on the Booty Kicker.
- Always inspect the Booty Kicker before every use for loose screws, nuts or damage. Tighten any screws or nuts prior to use. If you find
any cracks or damage, then discontinue use immediately.
- Only use the Booty Kicker on a clean level surface making sure you have adequate clearance around the Booty Kicker for performing the
exercises.
- When using the Booty Kicker, only engage your hands, arms, legs, or feet with the wooden barre. The metal uprights and base legs are
not intended to be used as gripping or exercise surfaces.
- Similarly, when using any type of resistance band with the Booty Kicker, engage the band only with the wooden barre. Do not allow
bands to contact sharp objects. Be sure to inspect any resistance bands before use and discontinue use if any signs of nicks or tears.
- When first attempting any exercise, use caution while determining your physical limitations. When performing any exercise involving
pushing or pulling forces on the barre, use caution to assure such forces do not create an instability causing either you or the barre to tip
over. Placing hands (or in the case of a resistance band) towards the middle of the wooden barre increases stability.
- Placing weights in the weight racks increases the Booty Kicker stability for performing certain pushing/pulling exercises. Removing
weights during exercises reduces the unit stability.
- Be sure to wear appropriate exercise clothing.
- Always properly store the Booty Kicker indoors after use. The Booty Kicker could pose a hazard to children and pets, and should not be
left unattended. Store out of reach of children when not in use.
- Use caution when folding, as hinges may pose pinch points for fingers, hands, feet and toes. When the Booty Kicker is in the folded
position, always secure base legs and uprights together with the two Velcro straps. Weights should be removed from weight racks when
moving / transporting the Booty Kicker.
Assemble on a hard, flat, level surface (not carpet or rug). Carefully unpack and familiarize yourself with each component, assembly, hardware
and tools. Remove the Base Rod and two Cross Rods shipped inside the Upright Bar and the Leg Assemblies.
Step 1
• Place the two Leg Assemblies flat on the floor with the Acorn
Nuts facing outward.
• With the Leg Assembly still in the folded position. Place the two
identical Cross Rods into the holes of the Upright Bars, as shown
in Fig.1. Secure with four Acorn Nuts, forming an X between
the Upright Bars. (Hand tighten only) Note the Top Cross Rod
overlaps on top of other Cross Rod as shown
• Place the Base Rod between the Leg Assemblies and into the
holes shown in Fig1, Secure with two Acorn Nuts. (Hand tighten
only)
• Place each Folding Gusset into the holes on the Base Bar, as
shown in Fig.1. Secure with two Acorn Nuts. Important, Acorn
nuts face outward. (Hand tighten only)
Step 2
• Holding the Base Leg in place, rotate the Upright Bars to
approximate position. As shown in Fig.2
• While holding the Upright Tube in place, Rotate a Folding Gusset upward. Holding the end of the Folding Gusset, gently flex the end outward.
Aligning the open end of the Folding Gusset and hole on the Upright Bar. Gently release the Folding Gusset completely through the Upright Bar
hole. As shown in Fig.2. Repeat on the other side of the assembly.
• Place the Straps onto the Gusset Rods. While holding the unit in place, gently pull outward on a Gusset Rod and rotate to place the first hole of
the Strap onto the Gusset Rod. Important. Assemble the Strap with the hook or scratchy side of the Velcro facing upward. As shown in Fig.2. Do
not wrap the Strap yet.
BK200
Weight Rack
Assembly Steps:
Step 1
FIG.1
Top Cross Rod
Base Rod
Leg Assembly
Bracket
Wooden Barre
Stretch Sleeve
Strap
Base Rod
Remove
Cross Rods & Base Rod
Gusset Rods
Cross Rods
Acorn Nuts
copyright 2019 Savvier Fitness LLC
Upright Bar
Assembled Unit
Folding Gusset
Base Leg
Folding
Acorn Nuts
191202
