Summary of Contents for DE&E HA9055
- Page 1 Accessories & Packing List ................Parts Name Diagram ..................Electrical Circuit Diagram ................Main Technical Parameter ................Installation Diagram..................Installation Steps..................... Safety Instructions................... Oprating Instructions..................Detachable Parts....................Troubleshooting....................
- Page 2 Accessories & Packing List 1. Range Hood x 1 unit 2. User Instructions manual x 1 pc 3. Flow Exit x 1 pc 4. Flow Exit seal x 1 pc 5. Oil cllection container x 1 pc 6. Flexible exhaust duct x 1 pc Extended Protection Tube Protection Tube Hood Flow Exit...
- Page 3 Main Technical Parameter Model No HA9055 HA9053 HA9052 Rated Voltage 220V~ Rated Power 50Hz Max Airflow 19m³/min） Max Noise Level 54dB Max Pressure ≥390Pa Wind pressure ≥300Pa Lighting ≤4W Motor Capacity 230W 234W Tot.Absorption Product Size 895X506X920(mm） 31kg 30kg 32kg installation diagram IMPORTANT:Installation must be carried out by our registered contractors.
- Page 4 Punch position Punch position This product must be installed by our company's professional staff. 1.Slide the upper cover plate in the direction of arrow, remove the buckle piece and remove the upper cover plate. 2.The internal bladder is assembled on the two side of the machine box with four M4 * 8 cross slot large flat head self tapping screws to fix the inner liner, and the back is fixed with three M4 * 8 cross slot large flat head self tapping screw.
- Page 5 1. drill holes in the punching position of the picture, bury the plastic expansion pipe, and fix the hook bar on the wall with 3 ST5 * 45 wood screws. 2. insert the end of the exhaust pipe out of the tuyere seat, fix the exhaust pipe on the side, take the silver white tape on the exhaust pipe, and tear the bottom paper to the seams and seal it.
- Page 6 1. Ensure there is proper ventilation in the cooking area. 2. Instructions concerning the discharge of air have to be followed. 3. Do not flambe under the range hood. 4. Avoid using materials which could cause spurts of flame near the range hood. 5.
- Page 7 Detachable Parts 1.Oil cup installation: push the oil cup into the lower foot of the hood of the hood. Dismantle: gently pull the oil cup along the horizontal direction, then it can be unloaded. Remove as far as possible during the use of hood, and prevent excessive force when disassembling, so as not to spill oil spills or cause accidents.
