evalink ipTNA4i Installation Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ipTNA4i

Installationmanual

Table of Contents

Need help?

Do you have a question about the ipTNA4i and is the answer not in the manual?

Questions and answers

Summary of Contents for evalink ipTNA4i

Page 1 Installationmanual...
Page 2: Table Of Contents
Connecting the ipTNA4i Commissioning of ipTNA4i Step 1: Capture device via evalink live Step 2: Commissioning Step 3: Transmission test Fault diagnostics on the device 3.1 Overview of the device state 3.2 Select detail status 3.3 Fault diagnosis intranet/internet connection 3.4 Fault diagnosis mobile connection...
Page 3: Connecting The Iptna4I
TCP/IP to alarm receiving centres. The encrypted data connections via the redundant communication paths (Ethernet and Mobile) are regularly monitored by “Alive-Checks”. Connecting the ipTNA4i The following explains how to connect the ipTNA4i to a danger alerting system:...
Page 4 Antenna Mount the antenna in a suitable location with sufficient reception and connect the antenna cable to the ipTNA4i SMA connector. The strength of the cellular signal can be measured with evalink live. --> Commissioning Step 2...
Page 5 ¹) • Mobile reception strength is out of tolerance (if configured in evalink) Fault contact 2 The contact is actuated when the ipTNA4i is Terminals a - c: Critical Fault inoperable. A combined fault has the Contact opens in the...
Page 6: Commissioning Of Iptna4I
Commissioning of ipTNA4i For easy installation of your device evalink live is available. evalink live independent of the terminal and can be used on any smartphone, tablet or PC via the browser. After successful registration under www.evalinklive.com and login on evalink live...
Page 7 You will then be prompted to enter the ipTNA4i MAC address. Under Check Connection you see the channels through which the device is connected. Next, you can check the signal strength by clicking on the mobile (GPRS/LTE) button. By clicking on the Configuration Log button you can receive the log via email.
Page 8: Step 3: Transmission Test
Once a connection is available, you can switch to the transmission test. To start the test, press the SW1 button on the ipTNA4i for 2s. Now you can test the inputs and outputs, as well as simulate the technical faults.
Page 9: Fault Diagnostics On The Device
• Press SW3 3x: GSM connection - L3 - L5 • Press SW3 4x: return to the Status Overview You can also get to back to Status Overview by pressing the SW4 key. Restart: If you hold the SW3 button down for longer than 6 seconds, the ipTNA4i reboots.
Page 10: Fault Diagnosis Intranet/Internet Connection
• If only L5 is lit, there is a fault with the internet connection (e.g. firewall • impermeable). -> Contact the local IT administrator. • If only L5, L4 and perhaps L3 are lit, the login to evalink has not been successful -> Contact the operator of the evalink platform 3.4 Fault diagnosis mobile connection If L4 continues to flash: •...
Page 11: Advanced Fault Diagnosis
With the optional TP-Link TL-WN821N dongle, the ipTNA4i can be used as a WiFi Access Point. This is very helpful if it is not otherwise possible to access the Internet from a smartphone, tablet or PC and thus the evalink platform in order to carry out the commissioning.
Page 12: Local Configurations
3.5.3 Local configurations If it should be necessary to configure a fixed IP address and/or special Mobile Access information to enable a connection to evalink at all, this can also be done via the local web server of the ipTNA4i.
Page 13: Requirements Of The Evalink Platform
The configured port numbers for connecting to the platform must be opened in the firewall. The ipTNA4i can obtain its IP address from the network DHCP server. If this is not possible or desired, a static IP address can also be defined.
Page 14: Notes And Warnings
Notes and Warnings Intended use: The intended use of the ipTNA4i is only applies when the instructions of the Installation Guide for the installation, electrical connection and commissioning are observed. Any deviation from the installation instructions shall be deemed to be improper.
Page 15 CH-4513 Langendorf +41 31 511 01 01 info@sitasys.com www.evalink.io/en/devices Although the information has been correctly reproduced in good faith in this publication, Sitasys AG assumes no liability for its completeness or accuracy. Sitasys AG is not responsible for damage of any kind which is caused by the use of information provided in this publication.
