Hidden Fence CatWatch Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CatWatch Hidden Fence
DogWatch® products are protected under U.S. Patent Nos.: 5,353,744; 5,465,687; 6,079,367; 6,467,435; 6,360,698.
Hidden Fence brand® should not be confused with Invisible Fence® or Invisible Fencing® which are products and registered trademarks of Invisible Fence, Inc. sold in the US.
© 1990-2019 DogWatch Inc. All rights reserved. No photographs, illustrations or text can be reproduced in any form without the express written consent of DogWatch Inc. Dog Fence.
© 2002-2019 Hidden Fence. All rights reserved. No photographs, illustrations or text can be reproduced in any form without the express written consent of Canine Containment Company
Pty Ltd. DogWatch, DogWatch logos, FastReact ™, Automemory ™, Safelink ™, Performance ™, Scoot ™, PowerPak ™, Pet-Friendly ™, are all registered trademarks of DogWatch, inc. Dog Fence.
© 2002-2019 "Hidden Fence brand –experts in pet containment...guaranteed" is a registered logo trademark.
© 2010-2019 Dog Stop by Hidden Fence brand is a registered logo trademark of Hidden fence brand.
© 2002-2019 Canine Containment Company Pty Ltd. All rights reserved. DogWatch Hidden Fence Systems, The Hidden Fence Company and The Hidden Fence Company logos are all Registered
trademarks of the Canine Containment Company Pty Ltd.
Hidden
Fence
Operating Instructions
R
Brand

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CatWatch and is the answer not in the manual?

Questions and answers

Related Manuals for Hidden Fence CatWatch

Summary of Contents for Hidden Fence CatWatch

  • Page 1 DogWatch® products are protected under U.S. Patent Nos.: 5,353,744; 5,465,687; 6,079,367; 6,467,435; 6,360,698. Hidden Fence brand® should not be confused with Invisible Fence® or Invisible Fencing® which are products and registered trademarks of Invisible Fence, Inc. sold in the US.
  • Page 2 Thank You for purchasing the CatWatch Hidden Fence system. We believe that when you purchase a quality system like the DogWatch brand, you’re receiving the best system available and an investment for your pets safety. Our products and training tools promote a lifestyle of protection, and security that no other brand can o er.
  • Page 3 Hidden Fence Dealer. Servicing the Dogwatch hidden fence system without using an authorized dealer may invalidate the warranty. • The Hidden Fence is recommended for cats four (4) months or older. Your Dealer will recommend if a kitten under 4 months old is ready. •...

  • Page 4: Main Components

    MAIN COMPONENTS IB200 Multi Transmitter Cat Receiver Collar (components not shown) Flags Power Supply MultiTool 150m Boundary Cable w/ female connector (may look di erent to above photo) *Items not shown - mounting hardware, joiners and flag stands (indoor) Additional Tools or installation aids: •...

  • Page 5: How It Works

    HOW IT WORKS A hidden fence is a electronic cat fence system which has a cable that follows the perimeter of the boundary. Through the cable is a radio signal transmitted via a transmitter control unit. Your Cat wears a receiver collar that receives the signal and activates a warning sound indicating proximity to the boundary.
  • Page 6 HOW IT WORKS Signal Field: The receiver collar activation distance is adjusted by the Range dial on the back of the Transmitter. This creates a signal eld on each side of the wire. Most installs work well with the collar activating around 1 meter from the wire;...
  • Page 7 HOW IT WORKS Boundary Con guration Examples Proper con guration is key to a pets success on a system. This cannot be ignored as the boundary area where the pet is going to be “corrected” if attempting to pass, makes sense. Traditional example 1 example 2...
  • Page 8 HOW IT WORKS example 1 example 2 ....Boundary Cable Twisted Cable MultiTransmitter Popular for suburban applications or canal or water front properties. This is great for back yards. Cable can be attached to a fence, or buried in the ground. If burying, we recommend 50mm minimum depth.

  • Page 9: Getting Started

    GETTING STARTED Introducing the Cat to the Hidden Fence in STEPS! STEP 1. Remove all components from the box and assemble the cats receiver collar STEP 2. Set up and begin the indoor training protocol. STEP 3. Install outdoor perimeter cable.

  • Page 10: Receiver Collar

    RECEIVER COLLAR R12M RECEIVER COLLAR The R12M is designed for smaller pets on the Hidden Fence system. The R12M has exclusive features to assist in containing your cat. 1. R12M Receiver 2. Battery Cap 3. Status LED 4. Stimulation Level Adjust Location 5.
  • Page 11 RECEIVER COLLAR STEP 2 SET YOUR TRAINING STIMULATION LEVEL Using supplied MULTI-TOOL, place magnet tip end of the multi-tool, and place it next to the “D” shaped location on the side of the receiver. MULTI-TOOL Magnet Tip “D” While holding the magnet tip to the “D” shape, the receiver will indicate the current stimulation level by an audible “beep”...
  • Page 12 Hidden Fence M12 receiver collar. While your cat is in the “standing” position, put the collar around his neck, and gently pull the strap to tighten the collar.
  • Page 13 MULTI-TRANSMITTER The IB Multi-transmitter is a state-of-the-art transmitter used for multiple applications related to your cat fence. 1. MULTI-TRANSMITTER The IB200 Multi-transmitter has dual signal fucntions. Wireless for cat training indoors, and wired for outdoor containment. 2. POWER LED The LED displays if you have a complete circuit or no circuit.
  • Page 14 The typical cat training is done relatively “hands o ”, as leads and handling usually preoccupy the cat; we prefer to disassociate the owner from the process. Once the cat has been conditioned to the fundamentals of the Hidden Fence using a speci cally placed “IB200 Multi-Transmitter“ in a controlled environment (house), the outdoor boundary is installed, and your cat is allowed outside under supervison.
  • Page 15 CAT TRAINING PROTOCOL cont. SIGNAL FIELD Kitchen bench Set the SIGNAL FIELD, by turning the RANGE dial located on the back of the multi transmitter. Turn the dial CLOCKWISE to achieve RANGE a small signal around a space or object. (approx.
  • Page 16 CAT TRAINING PROTOCOL cont. signal eld “BEEP BEEP BEEP” Flags Cat fence collar Using the cats receiver collar, place the indoor plastic ags just inside the stimulation zone. Typically set a ag 100mm inside the stimulation zone as indicated by the cat collars audible sound.
  • Page 17 CAT TRAINING PROTOCOL cont. signal eld Cat wearing collar The cats receiver collar is placed on the cat. It’s advised to set to the lower training level, as the cat may only need a low stimulation. signal eld yummy food bits trail Everyday for 1 week, place something yummy in the centre of the ags (human food, i.e.: chicken, steak, sh, etc.…NOT cat food);...
  • Page 18 CAT TRAINING PROTOCOL cont. signal eld Eating yummy food bits Allow your cat to discover and eat the food trail towards the ags and signal led zone signal eld Collar “BEEPS”, then gives small “Electrical Stimulation” Once your cat gets close enough for the warning “beep” to alert, he will be close enough to receive the stimulation from his collar.
  • Page 19 Once approx. one week has passed with the owner repeatedly placing yummy food bits into the centre of the ags, and the cat shows clear evidence that it’s avoiding the ags and stimulation zone, it’s ready for the next step, and you may commence the outdoor installation of your Hidden fence.

  • Page 20: Outdoor Installation

    OUTDOOR INSTALLATION BEFORE YOU CONTINUE INSTALLATION TIPS FOUND NEAR THE BACK OF THIS OWNERS GUIDE Switch MUST be in the “EXT” position for the outdoor installation. This switch changes your training zone from indoor training, to the outdoor wired mode. 240v power point oooooooooooooooooooooooooo...
  • Page 21 OUTDOOR INSTALLATION continued... Step 2. Find a location to place your electronics. Typically a garage or car port will su ce. If need be, a covered pool lter area will also work well. The power source must be a power point that can always remain on with power.

  • Page 22: Installation

    NOTE. The cables to the boundary need to be close to the perimeter together. together, or twisted so they cancel the hidden fence signal and don’t activate the collars. This can be achieved by simply taping them together, or wrapping...
  • Page 23 OUTDOOR INSTALLATION continued... The cable can be run at whatever height is needed to assist in containing your cat. If the cat is a jumper...sometimes putting the wire high on the fence may be best. If the cat gets under the fence or climbs, lower may be best.
  • Page 24 OUTDOOR INSTALLATION continued... Step 13 Finish your boundary by making sure you have completed the loop. Step 14 The receiver collar activation distance is adjusted by the Range dial on the back of the Transmitter to create a signal eld on each side of the wire. Turn the dial “CLOCKWISE”...

  • Page 25: Final Stage

    It can take a few days, if not more, for your cat to be comfortable using your yard after the Hidden Fence was installed. It’s natural for any pet to assess its new parimeter and feel comfortable. Some cats will adapt almost immediately, while others may cautiously adapt at their own pace.
  • Page 26 Use a staple gun to secure to the timber. In the ground Once your Hidden Fence cable is installed. Carefully check to see if it’s exactly where the cable needs to be to properly contain A spade or pick is best used when your pet.
  • Page 27 ATION TIPS Cattle fence. String your cable through the pilot holes in the timber posts. You can also use cable ties to secure as well. Position your cable on the fence based on your pets wandering habits. High for jumpers, low for diggers.
  • Page 28 OUTDOOR INSTALLATION TIPS continued... When installing on to fences, be sure to plan accordingly. Ask yourself...”What is my cat doing to escape? Digging? Jumping? Etc. Chain Link Fence Cable on Chainlink fence can be woven through, however, using cable ties is more practical. White line indicates where to position boundary cable Cats that jump to escape over fences Cats that dig to escape under fences...
  • Page 29 If this page was unable to solve your issue, please contact your supplier or contact a Hidden Fence Professional for assistance. There will be a charge if the Hidden Fence Dealer needs to appear on-site.
  • Page 30 Warranty and Guarantee for DIY Equipment For the purpose of this document, “DW” pertains to DogWatch Hidden Fence and CatWatch. These terms and conditions are enforceable by all dealers of DW, otherwise known as a Hidden Fence. For the purpose of this document, “DW”...
  • Page 32 © 2000-2019 DogWatch Inc. All rights reserved. No photographs, illustrations or text can be reproduced in any form without the express written consent of DogWatch Inc. Dog Fence. © 2002-2019 Hidden Fence. All rights reserved. No photographs, illustrations or text can be reproduced in any form without the express written consent of Canine Containment Company Pty Ltd.
