Congratulations!
formance, circular light mover ever offered to our industry–the SOLAR REVOLUTION™.
I embarked on the concept of the Solar Revolution™ over 2 years ago primarily out of
displeasure with what the industry had to offer. Customers kept asking me, "why can't
somebody build a reliable circular mover that is extremely durable but also user friend-
ly?" At that moment the Solar Revolution™ was conceived. Now two years and several
designs later, the Solar Revolution™ has arrived.
Benefits of the Solar Revolution
• heavy duty drive motor
• heavy duty microswitch rated to last for years
• heavy duty bearings and housing
• all-aluminum arms for strength and light weight
• whisper quiet operation and design
• extremely low profile, compact design provides maximum plant-to-light clearance
• no need to cut your lamp cords because no hard wiring is necessary
• extremely versatile–the unit can run one, two, or four lights with the same motor
• the Solar Revolution
degrees in the opposite direction, providing complete blending of metal halide and
high pressure sodium light
• light reflectors are easily adjusted both vertically and horizontally
• when used properly, the Solar Revolution
and plant performance
• 2 year warranty on workmanship, one year warranty on motor from the date of purchase
Before assembling or turning on the motor please read and heed all
• Be sure to have all necessary tools prior to beginning assembly.
• Please do not turn the motor on prior to installation. The unit is positioned at the factory to
enable accurate and proper installation. Turning the motor on before completing installa-
tion will disrupt the proper position for installation.
2 (two) 7/16 inch wrenches
1 (one) 1/2 inch wrench
chain to hang lamps
tools and material to secure Solar Revolution
SOLAR REVOLUTION™
The light mover for the next millennium
You have just purchased the most state of the art, high per-
runs 355 degrees in one direction then reverses and runs 355
TM
TM
will dramatically increase garden efficiency
TM
instructions.
Tools required
and to shelve the ballasts
TM
