siffron Spiral Anti-Sweep Hook Installation Instructions

Spiral Anti-Sweep Hook™ - Narrow Round Hood Style
INSTALL
1
Insert hooks into pegboard
and follow your plan-o-gram
layout.
LOCK DOWN
3
Insert the Lock Down Plate
into the holes directly below
the unit. Rotate up into place,
until the screw inserts into
back plate.
LOADING MERCHANDISE
5
Insert the merchandise by following the ramp
upwards until product stops, then turn the knob
counter clockwise until product catches hook.
Thin packages:
ONE COMPLETE ROTATION provides the
position for loading the next package.
Thick packages:
TWO COMPLETE ROTATIONS are required.
Repeat Steps 5 and 6 for loading the
rest of the merchandise.
WARNING: Do not overturn coil. Product will go all the
way off the rear of the coil and become inaccessible.
For more information,
call 800.422.2547
visit www.siffron.com
6
Open window and
insert price label.
2
Allow enough space between the
displays so that product does not
touch the surface below or obstruct
other merchandise.
4
Tighten screw with a Phillips
Head Screwdriver.
Close Screw Cover
Cap when
finished.
ATTENTION:
Keep product
faced to the
front.
DISPENSING MERCHANDISE
0000000000
Installation Instructions
Screw
Cover
Cap
20190311
