Summary of Contents for E-Drive 750C
- Page 1 E-Drive Product Specification TFT LCD Display Product 750C Mode 750C Abbreviation E-Drive Client E-Drive onderdeel van E.F.U. B.V. Supplier...
-
Page 2: Product Name
E-Drive 1． Product Name TFT LCD display Model : TFT 750C 2． Suppliers E-Drive 3． Electrical Parameters 3.2inch IPS screen 24V/36V/48V battery supply Rated operating current : 40mA Off leakage current < 1uA ... -
Page 3: Functional Description
E-Drive Suitable for low temperature，Max -20℃. High-contrast 3.2inch IPS colorful matrix screen. Ergonomic external button design, easy to operate. Speed display : AVG SPEED, MAX SPEED, SPEED(Real-time). Kilometer / Mile : Can be set according to customers’ habits. - Page 4 E-Drive automatically shut down when there is no operate & ride for X minutes （ X could be 0~9）. *If the display has been set password power on, you need to input the right password before start. 7.2 Assist level operating Short press UP/DOWN button can change the assist level.
-
Page 5: Parameter Setting
E-Drive when release the button. 1 5 . 5 4 . 5 Km/h Km/h ASSIST ASSIST Power Power Trip Trip 2 5 6 . 8 k m 2 5 6 . 8 k m 3 8 9 w 3 8 9 w * This feature needs to be supported by controller. - Page 6 E-Drive 8.2 Brightness : Press Up / Down button to change the brightness of the backlight, ׀is darkness， ׀׀׀׀׀is brightness MENU MENU Display Setting Basic Setting Display Setting Basic Setting System Metric System Metric Brightness || ||| Brightness Auto off...
- Page 7 E-Drive 0 . 0 0 . 0 0 . 0 Km/h Km/h Km/h ASSIST ASSIST ASSIST Power Trip Power Trip Power Trip 2 5 6 . 8 k m 3 8 9 w 2 5 6 . 8 k m 3 8 9 w 2 5 6 .
- Page 8 E-Drive 24V/36V/48V/UBE，UBE means user define value. MENU MENU Display Setting Basic Setting Display Setting Basic Setting Wheel 27.5 inch Wheel 27.5 inch Battery 24 V Battery 36 V Start password > > Start password > > Advance setting Advance setting Factory setting >...
- Page 9 E-Drive default password is ‘1919’. Start Input Password Display Setting Basic Setting Wheel 27.5 inch BACK Battery 36 V Input Pas s word Start password > > Advance setting 0 0 0 0 Factory setting > > Information EXIT Start Input...
- Page 10 E-Drive Advance Setting Advance Setting Advance Setting Speed limit Speed limit Speed limit 10km/h 10km/h 10km/h Current limit Current limit Current limit Poles in motor Poles in motor Poles in motor Start affter poles Start affter poles Start affter poles...
- Page 11 E-Drive 8.18 Start mode : Pow/ECO/STD represent Power/ECO/Standard, STD (default). Power mode means use maximum current when speed up, ECO mode means use minimum current. *This function is optional, may not supported by each mode. Advance Setting Advance Setting Advance Setting...
- Page 12 Full Charge Capacity Battery Infor EXIT 9． Error Code define 750C can show warning message, icon shows on the screen, and show error code at the bottom of the screen, error code from 01~07, definition see the table below. Error Code...
- Page 13 E-Drive 0 . 0 0 . 0 Km/h Km/h ASSIST ASSIST Power Power Trip Trip 2 5 6 . 8 k m 2 5 6 . 8 k m 3 8 9 w 3 8 9 w 10． Assembly instructions Please pay attention to the screw’s torque value, damaged caused by excessive...
-
Page 14: Connector Descriptions
E-Drive 25.4mm and 22.2mm （ marked with L or R ） , transfer ring must be assembled with the special directions, pay attention to the green arrow below. 22.2 L Clamp L 11． Connector descriptions Red wire : Anode(24v/36v/48V) 1、... - Page 15 E-Drive No power assist 13． Certification CE / IP65 (water proof) / ROHS.
