Sports Authority Bodyfit BDEL2906.0 Owner's Manual

Elliptical exerciser

Hide thumbs

Table Of Contents

Quick Links

ELLIPTICAL EXERCISER

Owner's Manual

Model No. BDEL2906.0

SKU No. 20181624

Table of Contents

Need help?

Do you have a question about the Bodyfit BDEL2906.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sports Authority Bodyfit BDEL2906.0

Page 1 ELLIPTICAL EXERCISER Owner’s Manual Model No. BDEL2906.0 SKU No. 20181624...
Page 2: Table Of Contents
BDEL2906.0 TABLE OF CONTENTS Before You Begin ........3 Safety &...
Page 3: Before You Begin
BDEL2906.0 BEFORE YOU BEGIN • A flat area of 5’ x 4’ will be required to assemble and properly use the BF Elliptical Exerciser. • For your benefit, read this manual carefully before using the BF Elliptical Exerciser. Please review the exploded diagram and familiarize yourself with the parts that are labeled.
Page 4: Safety & Precautions
BDEL2906.0 SAFETY & PRECAUTIONS IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. • Thank you for purchasing our product. Even though we make great efforts to ensure the quality of each prod- uct we produce, occasional errors and/or omissions do occur.
Page 5: Exploded Diagram
BDEL2906.0 EXPLODED DIAGRAM 62 33 24 54 17 32 69 68 1-877-872-6970 PLEASE DO NOT RETURN TO STORE; CALL OUR CUSTOMER SERVICE DEPARTMENT FIRST AT...
Page 6: Parts List
BDEL2906.0 PARTS LIST Description Description 1. Frame 26. M8 x 3/4" hex bolts 2. Front stabilizer 27. Bearing covers 3. Upright 28. Rear stabilizer endcaps 4. Left pedal tube 29. Transport wheels 5. Left handlebar leg 30. Drive belt 6. Handlebars 31.
Page 7 BDEL2906.0 PARTS LIST Description Description 51. M8 x 3 1/2" carriage bolts 64. Right pedal tube 52. M8 washers 65. Right side shield 53. M10 washers 66. Right disc cover 54. M8 arc washers 67. Reed switch and wire 55. M6 washers 68.
Page 8: Assembly Instructions
BDEL2906.0 ASSEMBLY INSTRUCTIONS STEP 1 Identify the Front Stabilizer (2), which has Transport Wheels (29) attached to it. Attach the Front Stabilizer to the Frame (1) with two M8 x 3 1/2" Carriage Bolts (51), two M8 Arc Washers (54), and two M8 Cap Nuts (24).
Page 9 BDEL2906.0 ASSEMBLY INSTRUCTIONS STEP 3 Battery Compartment The Console (22) requires two 1.5 V “AA” batteries Console Wire (not included). Remove the battery cover from the Console and insert two batteries into the battery com- partment. Make sure that the batteries are oriented Pulse Wire as shown by the diagram inside the battery com- partment.
Page 10 BDEL2906.0 ASSEMBLY INSTRUCTIONS STEP 5 Identify the Right Pedal (63), which has an “R” molded into its bottom surface, and the Right Pedal Tube (64), which is marked with a sticker. Attach the Right Pedal (63) to the Right Pedal Tube (64) with two M8 x 1 9/16"...
Page 11 BDEL2906.0 ASSEMBLY INSTRUCTIONS STEP 7 Insert a Plastic Sleeve (16) into the top of the Right Handlebar Leg (71). Then, insert a Handlebar (6) into the Right Handlebar Leg. Align the holes in the Handlebar with the holes in the Right Handlebar Leg. Attach the Handlebar with two M6 x 5/8"...
Page 12: Console Instructions
BDEL2906.0 CONSOLE INSTRUCTIONS FEATURES OF THE CONSOLE HOW TO USE THE CONSOLE The easy-to-use console features five displays that Make sure that the console has batteries (see assem- provide instant exercise feedback during your work- bly step 6 on page 10). If there is a sheet of clear plas- outs.
Page 13 BDEL2906.0 CONSOLE INSTRUCTIONS 3. Begin pedaling and follow your progress with For the most accurate heart rate reading, continue the displays. to hold the handgrips for about 30 seconds. As you exercise, the console will provide instant If your heart rate is not shown, make sure that your feedback about your workout.
Page 14: Training Instructions
BDEL2906.0 TRAINING INSTRUCTIONS EXERCISE/SPECIFICATIONS As your fitness improves, you can increase your exer- cise intensity to 70% to 85% of your maximum pulse To achieve a considerable improvement of your rate. physical fitness and health, take note of the following information and recommendations.
Page 15: Limited Warranty
WARRANTY INFORMATION Sports Authority warrants that this product will be free from defects in materials and workmanship for a period of 90 days from date of purchase. This warranty applies only to the original purchaser when purchase of the product is from an authorized retailer and is for personal or household use, but not when the sale is for commercial use.
Page 16 PLEASE DO NOT RETURN TO STORE; CALL OUR CUSTOMER SERVICE DEPARTMENT FIRST AT 1-877-872-6970 This department is open Mon.–Fri. from 8:00 am–5:00 pm MST SPORTS AUTHORITY 1090 West Hampden Avenue Englewood, CO 80110 www.sportsauthority.com Part No. 239963 R0506A...
