Summary of Contents for Arkuz BlueNet
- Page 1 Arkuz BlueNet Switch Device Installation Guide...
- Page 2 Contents Arkuz BlueNet Device Product Contents. Typical Switchboard Panel Connections Connecting Arkuz BlueNet Switch to your Switchboard Panel Your Switchboard connections when powered by Arkuz BlueNet Switch...
- Page 3 Input to the power supply module. The set of 2 Yellow wires is output of the power supply. Arkuz BlueNet Switch Module. The BlueNet Switch has 3 sets of wires coming out of it. Set 1: Black & Red Wire with a knot are INPUT to power up the BlueNet Switch.
- Page 4 Typical Switchboard Panel Connections MAINS & NEUTRAL Switchboard Panel 220 Volt AC lines. Switches connect Input Current to Switches Regulator Socket various Loads. 220VAC Loads Fan uses Regulator for speed control.
- Page 5 Connecting Arkuz BlueNet Switch to your Switchboard Panel Items Required Arkuz BlueNet Switch Screw Driver Electric Wire Duct Tape...
- Page 6 Switchboard Panel The installation deals with High Voltage AC current hence take at most caution while installing the Arkuz BlueNet Switch. It is highly recommended that any electricity coming to the Switchboard Panel switchboard panel where the smart light...
- Page 7 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 2 Switchboard Panel Disconnect Input & Output Connections to all of the switches. Switches Socket Disconnect and 220VAC Loads remove the Fan Regulator.
- Page 8 Connecting Arkuz BlueNet Switch to your Switchboard Panel Switchboard Panel Power Supply Step 3 Connect the set of wires of Arkuz Switches Socket Power Supply with the 220VAC wires. 220VAC Loads...
- Page 9 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 4 Switchboard Panel Power BlueNet Switch Supply Connect the YELLOW set of wires to the pair of Switches Socket RED/BLACK wire set of Arkuz 220VAC Loads BlueNet Switch module.
- Page 10 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 5 Switchboard Panel Power BlueNet Switch BlueNet Switch Supply Connect the MAINS wire of the 220 Volt AC wires to the Switches Socket THICK BLACK wire on the TOP 220VAC Loads RIGHT of the Arkuz BlueNet Switch.
- Page 11 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 6 Switchboard Panel Connect the THIN set of Power BlueNet Switch Supply wire on the left left of the Arkuz BlueNet Switch as follows. Connect the TOP THICK Switches Socket BLACK wire to one end of every switch.
- Page 12 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 7 Switchboard Panel Connect the 4 THICK Power BlueNet Switch Supply Multi Coloured wire on the RIGHT of the Arkuz BlueNet Switch to different loads. Switches Socket Make sure that the...
- Page 13 Connecting Arkuz BlueNet Switch to your Switchboard Panel Step 8 Switchboard Panel Installation is Power BlueNet Switch Supply complete. Turn the power on the Switches Socket switchboard panel. Operate the switches. 220VAC Loads They should turn the same way as before.
- Page 14 Your Switchboard connections when powered by Arkuz BlueNet Switch Switchboard Panel Power BlueNet Switch Supply Switches Socket Loads 220VAC...
- Page 15 Arkuz Technologies beyond possibilities...
