Metal Garden Shed
Wood Storage
OWNER'S MANUAL
Instructions for Assembly
9820005
Overall Size: L270 x W105 x H130/158 cm
Overall Size: L8.8 x W3.4 x H4.3/5.2 Feet
Requires two people and takes
at least
1-1.5 hours for lnstallation.
Quick & Easy Assembly
Ridge Reinforced Walls
Advertisement
Related Manuals for Hanover 9820005
Summary of Contents for Hanover 9820005
- Page 1 Metal Garden Shed Wood Storage OWNER'S MANUAL Instructions for Assembly 9820005 Overall Size: L270 x W105 x H130/158 cm Overall Size: L8.8 x W3.4 x H4.3/5.2 Feet Requires two people and takes at least 1-1.5 hours for lnstallation. Quick & Easy Assembly...
-
Page 2: Before You Start
BEFORE YOU START Owner's Manual Prior to installation, it is important that you contact your local government authority to determine if building approval is required. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. -
Page 3: Site Preparation
PLAN AHEAD Site Selection Avoid overhanging trees as much as possible as leaves will make regular cleaning necessary and broken branches are a potential hazard. Small trees,bushes or fences nearby can be helpful,acting as a wind break. Site Preparation The site must be prepared so that the base of the shed is level all round and checking with a spirit level is required. - Page 4 Qty. Qty. PART PART 944mm/37.16" 944mm/37.16" 944mm/37.16" 944mm/37.16" 1620mm/63.78" 516mm/20.31" 592mm/23.3" 516mm/20.31" 1308mm/51.49" 1623mm/63.89" 1308mm/51.49" 462mm/18.18" 1088mm/42.83" 1390mm/54.72" 1540mm/60.62" 1035mm/40.74" 876mm/34.48" 1623mm/63.89" 1528mm/60.15" 799mm/31.45" 1264mm/49.76" 1528mm/60.15" 1264mm/49.76" 448mm/17.63" 1275mm/50.19" 939mm/36.96" 1390mm/54.72" 939mm/36.96" 1528mm/60.15" 1615mm/63.58" 1035mm/40.74" 1621mm/63.81"...
- Page 5 Qty. PART 1035mm/40.74" 1035mm/40.74" 592mm/23.3" 592mm/23.3" 1263mm/49.72" H1&J5 #8AB-18x2/13 #8-32x2/13 1580mm/62.2" #8-32x2/13...
- Page 7 PART Qty. Base of Tool Shed Assembly 、 When diagonal measurements are Inspection equal,the frame is square. 、 The Floor Frame must be BOTH square AND level or the holes will not line up properly. Qty. PART Door Post of Tool Shed Installation...
- Page 8 PART Qty. Right Side Wall Panels Installation Qty. PART Wall Panels Installation Corner Post 10R inside Qty. PART Left Side Panels Installation Corner Post 10L inside...
- Page 9 PART Qty. Qty. Qty. PART PART Left Side Upper Beam Installation Left Triangle Panel Installation Qty. PART Right Side Upper Beam Installation Right Triangle Panel Installation...
- Page 10 PART Qty. Front Upper Beam Installation Qty. PART Base of Wood Storage Cabinet Installation Qty. PART Side Wall Panel Installation Corner Post Installation (Wood Storage Cabinet) -10-...
- Page 11 PART Qty. Right Corner Posts Installation Qty. PART Front Beam,Frame and Triangle Panels Installation (Wood Storage Cabinet) Qty. PART Triangle Panels Fixation -11-...
- Page 12 PART Qty. Connection Between Tool Shed and Wood Storage Cabinet Qty. PART Connection Between Tool Shed and Wood Storage Cabinet Qty. PART Roof Panels Installation -12-...
- Page 13 PART Qty. Roof Panels Installation (Tool Storage) Qty. PART 25&26&27 Eaves and Plastic Ends Installation 29&30 Qty. PART Corner Connector Installation -13-...
- Page 14 PART Qty. Door Panel and Door Frame Assembly Qty. PART Door Assembly Qty. PART Turn Opposite Door Assembly and Fixation -14-...
- Page 15 Qty. PART Door of Tool shed Installation Qty. PART H1&J5 Doorknob and Bolt Installation Finishing -15-...
