MIJA Critical Alert Universal User Manual

Critical Alert Universal
USER MANUAL
Part # 1-05873
U.S. Design Pat. No. D817,794 & Patent Pending

SPECIFICATIONS

4
Coin Cell Batteries– CR1632

OPERATION

1.
The Critical Alert Universal from MIJA is completely assembled and
ready to be installed onto an oxygen regulator. See Figure 1 below.
Analog Gauge
Black Snooze &
On/Off Button
Figure 1. Critical Alert Universal Layout
2.
The Critical Alert Universal seen in Figure 1. can be installed onto an
oxygen regulator, per NPT installation standards, using a 7/16" wrench
on the brass hex on the backside of the Universal. The Critical Alert
Universal will fit most regulators using an 1/8" NPT fitting.
Figure 2. Critical Alert Universal Installed on Oxygen Integrated Regulator
3.
The Critical Alert Universal is now ready to use. The Critical Alert
Universal needs to be switched on, the switch can be found on the lens of
the housing as shown in Figure 1. Press the black button and release.
Figure 3. Critical Alert Universal Installed on a Post Valve Regulator
www.MIJA.com
781-871-5750
LED Indicators
4.
The green LED will flash letting the user know the Critical Alert
Universal is ready and has power. The analog gauge will read the
pressure in the oxygen cylinder and will be in the green area on the dial
when the cylinder is fully charged.
5.
The red LED will flash and an audible alarm will sound when the
oxygen level gets to 500 psi and lower. The black snooze button , see
Figure 1., can be pressed (press and release) to silence the alarm
while a new oxygen cylinder is sourced. See Table 1 for the estimated
minutes of available oxygen.
6.
The yellow LED will flash when the battery power is low. The
batteries should be changed at this point for optimal performance of the
Critical Alert Universal. The analog gauge will continue to work should
the battery be completely drained of power but there will be no visual or
audible alerts from the system.
7.
The Critical Alert Universal may be shut off while in normal
operating conditions or while in the alarm state. Press and hold the
black Snooze & On/Off button until all three LED lights appear, a single
tone of the alarm will also sound, it is now safe to release the button.

CLEANING INSTRUCTIONS

Before Cleaning:
•
Make sure the Critical Alert Universal is powered off.
•
Ensure that the cylinder valve is closed.
Recommended:
•
Sanitizing Wipes/Germicidal Disinfecting Wipes
•
Bleach on damp Cloth
•
Alcohol Swab
•
Citric Acid
•
Use Acetone or anything containing Acetone
•
Use Ammonia or anything containing Ammonia
•
Hose Down
•
Submerge in water
Contact MIJA with any questions about cleaning or product information.
The snooze function will silence the audible alarm for 20
Use of the snooze function is not suggested for flow rates
higher than 4 LPM.
Maintenance Instructions & Product Warranty on Back - >
Do Not:
minutes.
****
