Spintly Smart Access Uno User Manual

SMART ACCESS UNO
User Manual
About Spintly Smart Access Uno:
Spintly Smart Access Uno is a smart phone based
access control system which enables the user to
unlock any of your doors using smartphone or
NFC cards.

Features:

➢ Proximity based access (smart phone)
➢ NFC card based access.
➢ Remote Access (smart phone)
➢ Easy to install and easy to use
➢ Multiple layers of security
➢ Works with various locking systems
➢ Works with the App in background

Electrical Specifications:

➢ Power Source: 12V – 35V DC input
➢ Power Consumption:
➢ 2.4 W max at 12V

Contents in the box

Qty
Spintly Smart Access Uno 1
Back plate 1
IS0 6X25 mm Screw 4
M3x8 mm Screw 2
Wall Plugs 4

Assembly Instructions:

Wall plugs
Back plate
ISO 6X25 mm screws
Fig 0.1
• Mount back plate on the wall with the help of wall
plugs and screws
Fig 0.2
6 core
cable
Fig 0.3
M3x8
screws
(1)
Fig 0.4
Accessories: (Exclusive)
➢ 12V, 1 Amp Power supply.
➢ Spintly Product Gateway/Router
➢ Extra 6 Core cable
➢ NFC cards
➢ Electromagnetic Lock
Please contact your
authorized dealer for further assistance
2) Wire the Uno as per
connection diagram
( page no 2)
3) Place Uno on the back
plate
4) Use M3 x 8mm
screws to secure Uno to
the Bracket.
