Summary of Contents for QuantoLux QLX3
- Page 1 QLX3 Installation Guide...
-
Page 2: Are You Ready
Soon your instrument will arrive and you should be well prepared to quickly make best use of it. Here are some tips for you. If you have doubts or questions, please do not hesitate to contact your QuantoLux service partner. www.quantolux.com... -
Page 3: Dimensions And Weight
Dimensions & Weight Deliver Results ! QuantoLux 85-260 V AC, 50/60 Hz 300 W, <0.5 W in stand-by 35 kg www.quantolux.com July 2018... - Page 4 Unpacking Accessories Prepare gas accessories Place the instrument on a stable workbench or Shipment box contains the QLX3 instrument ①, Open the accessories box and take out the service Remove the two protective red caps from the table. Take the power cord and connect to a the controller box ②, and an accessories box ③.
- Page 5 QuantoLux ① ② ③ ④ Unboxing Shipment box contains the QLX3 instrument , the controller box , and an accessories box . Attached documents are a packing list and the „Quick Guide“ sheet Unpack all items and check for completeness and possible damage.
- Page 6 2 Unboxing the accessories package Deliver Results ! QuantoLux ① ② ③ Unpacking Accessories Open the accessories box and take out the service kit , the power cord and the teflon tube www.quantolux.com...
- Page 7 3 Connecting Power & USB Deliver Results ! QuantoLux Connecting Power & USB Place the instrument on a stable workbench or table. Take the power cord and connect to a power outlet. Position the controller near or above the instrument.
- Page 8 4 Prepare Gas Accessories Deliver Results ! QuantoLux ① ② ③ Prepare gas accessories Remove the two protective red caps from the teflon tube ends . Unplug the cap at the back of the instrument: push in the plastic ring and remove the tube piece .
- Page 9 5 Connecting to Argon Deliver Results ! QuantoLux 1.5 bar ① Connecting to Argon Have a cylinder of argon 4.8 (99.998%) available. Mount a pressure regulator. The fitting from the Service Kit is screwed to the outlet of the regulator. Then the end of the teflon tube can easily be pushed in.
- Page 10 5 min on to warm-up the laser, before you start the first measurement ! Also switch on the computer. Windows will start. Use Windows PIN: 010101; or the Windows user serialno@QLX3.de (user) and „qlx00000“ (password). Double- click the QuantoLux icon to start the software. www.quantolux.com...
- Page 11 In that case you need please check the user manual, write to to provide your own computer and Windows licence. support@quantolux.de or contact your local QuantoLux In this case the USB thumb drive contains the setup service partner.
- Page 12 Thank you for your Attention ! For more information, please contact sales@quantolux.de or your local QuantoLux Partner! QuantoLux GmbH | Boschstrasse 16 | D-47533 Kleve | Germany T: +49 2821 894-4870 | E: info@quantolux.de | W: quantolux.de © 2018 QuantoLux GmbH all rights reserved...
