EFFIKAL RVGP-KS-BKF Series Installation Instructions Manual

DO NOT TURN DAMPER MANUALLY WITH OR WITHOUT ELECTRICAL
POWER OR MOTOR DAMAGE WILL OCCUR, USE THE SERVICE SWITCH.
LIMITED 5 YEAR WARRANTY ON MOTORIZED CONTROLLER
LIMITED 25 YEAR WARRANTY AVAILABLE TO HOMEOWNER
SPECIFICATIONS, INSTALLATION INSTRUCTIONS, AND TROUBLESHOOTING GUIDE FOR EFFIKAL AUTOMATIC
VENT DAMPER RVGP-KS-BKF SERIES FOR USE ON LISTED GAS FIRED BOILERS WITH A DRAFT HOOD.
READ INSTRUCTION BOOKLET CAREFULLY AND COMPLETELY BEFORE PROCEEDING WITH THE INSTALLATION.
• The Effikal RVGP Series Automatic Damper must be
installed by a qualified installing agency in accordance
with the manufacturer's installation instructions. The
definition of a Qualified Installation Agency is: any indi-
vidual, firm, corporation or company which either in
person or through a representative is engaged in, and
is responsible for, the installation and operation of gas
appliances and automatic vent damper devices, who
is experienced in such work, familiar with all the pre-
cautions required, and has complied with all the
requirements of the authority having jurisdiction. The
qualified installer shall fill in the installer's name,
address and installation date on the label attached to
the vent damper device.
• Do not negate the action of any existing safety or
operational controls.
• When servicing controls, all wires must be LABELED
prior to disconnection. Wiring errors can cause
improper and dangerous operation.
• Device must be installed by a qualified installer, in
compliance with local codes or the National Fuel Gas
Code (ANSI Z223.1 NFPA 54) and the National
Electric Code (ANSI C1-NFPA 70).
• Device conforms to ANSI Z21.66 and ADDENDA.
CGA and AGA design certified.
• Use only with a listed gas fired boiler equipped with a
draft hood, the outlet area of which is not greater than
the inlet area of the device.
For continued safe operation, the appliance-device combination should be inspected annually by a qualified service agency. It is
recommended that the homeowner examine all flue product carry areas of the appliance, its vent system, and the damper device,
with particular attention given to deterioration from corrosion or other sources. This examination should be performed prior to and
during each heating season. Also use Exhibit A, page 2 and Final Inspection, page 7.
Install this plug in hole in damper blade on all boilers
equipped with intermittent ignition systems only. DO
NOT install this plug on standing pilot systems. Failure
to follow these instructions can cause nuisance odor
problems and minor property damage due to moisture if
ignored.
EFFIKAL INTERNATIONAL INC.
143 NORTHPOINTE DRIVE
ORION, MICHIGAN 48359
(248) 370-9554
WARNING
TO THE USER
CAUTION
• Install after the boiler draft hood, as close to the draft
hood as practicable, and without modification to the
draft hood or the vent damper.
• Locate in a venting system or section of a venting sys-
tem so that it services only the single boiler for which it
is intended.
• A minimum clearance of 6 inches (153mm) between
the damper device and combustible construction must
be maintained and that there be provisions for access
and service of the damper device.
• Position indicator and service switch must be accessi-
ble to the user.
• The installer must fill in the label on the side of the
controller cover.
• This device must be installed only on a boiler connect-
ed to a factory built chimney or vent complying with a
recognized standard, or a masonry or concrete chim-
ney lined with a lining material acceptable to the
authority having jurisdiction.
• This vent damper device shall not be installed on an
appliance with an automatic valve having a manual
opener unless the manual opener has been rendered
in-operative or the automatic valve has been replaced
with a redundant automatic valve not equipped with a
manual opener.
RVGP-KS 3/00 ©
