Summary of Contents for SmartCow Cerberus NX
- Page 1 Cerberus NX Guide Creating safer and smarter cities...
- Page 2 • Host Ubuntu version is Linux 18.04.4 LTS. • The NVIDIA SDK Manager version is 1.2.0.6733 or up. BSP version is JetPack_4.4_Linux_JETSON_XAVIER_NX (L4T 32.4.3) • The SOP take Cerberus NX as an example The SOP Patch is “R32_4_3_Cerberus_NX_Camera_IMX290_Dual_1.tar.gz” Description BSP folder path : ~/nvidia/nvidia_sdk / JetPack_4.4_Linux_JETSON_XAVIER_NX (home/nvidia/nvidia_sdk/JetPack_4.4_Linux_JETSON_XAVIER_NX)
- Page 3 • Xavier NX production module and Cerberus NX carrier board (Include Requirement for Power Adapter and cable) Patch file • x86 PC (Include Linux 16.04 or Linux 18.04 system) and monitor Installation Device • USB Cable (Micro-B To Type-A)
- Page 4 Use NVIDIA SDK Manager to Download BSP Please use Host computer to download NVIDIA SDK Manager from Jetson download Center https://developer.nvidia.com/embedded/downloads ***DO NOT open Jetson system in advance*** After download, click “SDK Manager deb” to execute the file Click “Install” Click top left corner “Search your computer”...
- Page 5 Use NVIDIA SDK Manager to Download BSP Type in “SDK” Click “SDKManager” Open “SDK Manager”...
- Page 6 Use NVIDIA SDK Manager to Download BSP Enter Account and Password and Click “LOGIN” If you don’t have an Account and Password, please visit Nvidia website and register. After Login, if you don’t want to install “Host Components”, please cancel the selection of “Host Machine”.
- Page 7 Use NVIDIA SDK Manager to Download BSP Choose the Module. Select “Jetson Xavier NX” Please select the Module based on your flashing need. Choose Product Version (BSP Version). Please select “JetPack 4.4” Please select the Product Version based on your flashing need. Confirm the Module and BSP version.
- Page 8 Use NVIDIA SDK Manager to Download BSP “Jetson OS” and “Jetson SDK Components” will be selected automatically. If you don’t want to install the later one, cancel the selection of “Jetson SDK Components”. Click “I accept the terms and conditions of the license agreements”. And click “CONTINUE TO STEP 03”.
- Page 9 Use NVIDIA SDK Manager to Download BSP Enter Password. It will start to download “Jetson OS Image”. After finishing the download of “Jetson OS Image”. Be aware that choosing different modules will look slightly different.
- Page 10 Use NVIDIA SDK Manager to Download BSP Please select the “Manual Setup. Finish the selection. ***DO NOT click “Flash” and “Skip” or close “SDK Manger”*** Please open the folder from the path “Home/nvidia/nvidia_sdk” to install Patch file...
- Page 11 Patch file installation After downloading “Jetson OS Image (BSP)”, enter “Home/nvidia/nvidia_sdk”. You will see “JetPack_4.4_Linux_JETSON_XAVIER_NX ” folder. Attention! This SOP take JetPack_4.4_Linux_JETSON_XAVIER_NX as an example. The folder will vary with the downloaded JetPack version and the selection of Modules. To check whether “Jetson OS Image (BSP)” is downloaded completely, please enter the following path to see if there are files in the folder.
- Page 12 Patch file installation Copy the Patch file to “Home/nvidia/nvidia_sdk”. Click right button of mouse and click “Open in Terminal”...
- Page 13 Patch file installation Please enter Unzip Command. E.g. The Patch file name as an example in this SOP: R32_4_3_Cerberus_NX_Camera_IMX290_Dual_1.tar.gz Unzip Command: tar -zxvf R32_4_3_Cerberus_NX_Camera_IMX290_Dual_1.tar.gz...
- Page 14 Patch file installation cd to R32_4_3_Cerberus_NX_Camera_IMX290_Dual_1 and Enter Patch file Installation Command: ./setup.sh After the commands, system will request you to enter the username and password of Ubuntu. When the process is done, it’ll shown as right.
- Page 15 Confirm if Patch file Installation is done Enter kernel folder. Check the image and dtb time have been modified. If yes, it means the Patch file installation is successful. E.g. Executing setup patch at 02:10 The following folder path is an example in this SOP. Attention! The folder path varies with different Jetson OS Image.
- Page 16 Jetson OS flash (BSP) Before flashing BSP, please connect USB Cable (Micro-B To Type- A) to Micro-B connector of Jetson system and USB port of x86 Set system to recovery mode (Described in next slide) Go to Host PC. Open SDK Manager.
- Page 17 Set System to Recovery Mode Step1. Power down the device. If connected, remove the AC adapter from the device. The device must be powered OFF, and not in a suspend or sleep state. Step2. Connect the Micro-B plug on the USB cable to the Recovery (USB Micro-B) Port on the device and the other end to an available USB port on the host PC.
- Page 18 Jetson OS flash (BSP) Click “Flash”* *When Jetson system is not open or not in recovery mode, click “Flash” will be show: could not detect Nvidia Jetson Device.
- Page 19 Jetson OS flash (BSP) After clicking “Flash”, it’ll start to flash.
- Page 20 Jetson SDK Components Installation When the flash is done, it’ll pop up the window Jetson platform will auto reboot after BSP flashing. Follow System configuration wizard on Sentinel and setup username and password. Enter the Username and Password...
- Page 21 Jetson SDK Components Installation Click “Install”. It will start to install “Jetson SDK Components” Finish...
- Page 22 SmartCow www.nvidia.com www.smartcow.ai SmartCow is affiliated to Nvidia under the Metropolis Software Partner Program...
- Page 23 MALTA - HeadQuarters INDIA Engineering & Manufacturing: SmartCow Co. Limited SS1, Marina Milling Complex, SmartCow Ai Technologies Private Limited Valletta Waterfront No.6, Forni Complex, Aikya Vihar, Plot No. 218, B Block, Industrial Estate, 45-46 Pinto Wharf, Floriana FRN1913 2nd Floor, Kavuri Hills Phase - II...
