Summary of Contents for BSJ-Link BC30
- Page 1 BC30 Hardware design manual V1.0.0 WiFi Module BC30 Hardware Manual Shenzhen BoShijie Technology Co., Ltd. IOT Division...
- Page 2 BC30 Hardware design manual V1.0.0 1. Overview The BC30 has the most competitive package size and ultra-low power technology in this Industry, Size is only 24.0*16.0*3.0mm and supporting secondary development. BC30 can be widely used in various IOT applications, suitable for home automation, industrial wireless control, baby monitors, wearable electronics, wireless location-aware devices, wireless positioning system other IOT applications.
-
Page 3: Pin Definition
BC30 Hardware design manual V1.0.0 3. Pin Definition 3.1 Pin Layout 3.2 Pin Definition Name Of Pin Type Description Power Down signal of the chip Shenzhen BoShijie Technology Co., Ltd. IOT Division... -
Page 4: Product Features
BC30 Hardware design manual V1.0.0 GPADC0 General purpose ADC GPIO12 General purpose input/output GPIO0 General purpose input/output GPIO2 General purpose input/output GPIO3 General purpose input/output GPIO13 General purpose input/output VBAT Power supply GPIO5 General purpose input/output GPIO25 General purpose input/output... -
Page 5: Product Specifications
BC30 Hardware design manual V1.0.0 ◆Main frequency up to 160MHz ◆Built-in 10bit high precision ADC ◆Supports interfaces such as UART/GPIO/IIC/PWM/ADC ◆SMD-22 package for easy soldering and testing ◆Integrated Wi-Fi MAC/BB/RF/PA/LNA ◆Support multiple sleep modes, standby power consumption as low as 1.0mA ◆Embedded Lwip protocol stack... -
Page 6: Technical Parameters
BC30 Hardware design manual V1.0.0 safety WEP/WPA-PSK/WPA2-PSK Power supply range Supply voltage 3.0V~3.6V, supply current >300mA Operating temperature -20℃~85℃ Storage environment -40℃~85℃，<90%RH weight 1.4g Certification FCC、CE 4.3 Technical Parameters Classification Project Parameters Wireless standard 802.11 b/g/n Frequency Range 2412M ~ 2462MHz 802.11 b: -91 dBm (11 Mbps) -
Page 7: Power Consumption
BC30 Hardware design manual V1.0.0 5. Power consumption Parameter Minimum Typical Maximum Unit Tx802.11b, CCK 11Mbps, P OUT=+17 dBm Tx 802.11g, OFDM 54 Mbps, P OUT =+15 Tx 802.11n, MCS7, P OUT =+13 dBm Rx 802.11b，1024 Bytes，-80 dBm Rx 802.11g，1024 Bytes，-70 dBm Rx 802.11n，1024 Bytes，-65 dBm... -
Page 8: Functional Schematic
◆ Access register AHB interface 7.2 Built-in storage The BC30 chip has a built-in memory controller that includes ROM and SRAM. The MCU can access the memory controller through the iBus, dBus, and AHB interfaces. All storage units can be accessed after the request is initiated. The storage arbiter determines the order of access... -
Page 9: External Flash
SRAM space in the Heap+ Data area is 96kB. Embedded 8Mbit Flash storage. 7.3 External Flash The BC30 uses an external SPI Flash to store the user program. In theory, it can support up to 16MB of storage. 8. Applications ◆... -
Page 10: Fcc Statement
This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2AQSK-BC30” When the module is installed inside another device, the user manual of this device must contain below warning statements; 1. This device complies with Part 15 of the FCC Rules.
