- Page 1 Full Range Ribbon Loudspeakers Botticelli & Botticelli X User’s Manual...
- Page 2 We would like to congratulate on your purchase of ALSYVOX Botticelli! Our mission is to make loudspeakers that can bring the musicians in your room by giving the same emotion of a great live performance. To reach this goal we have experienced that the use of thin diaphragm ribbons and...
- Page 3 Using these three transducers the result is a breathtaking coherent sound as all the audio frequency band is covered by loudspeakers of the same height, made with the same diaphragm materials and magnets, with a sensitivity of 93dB or more. Our Technology All our speakers are dipoles that approximate the ideal concept of a line source.
-
Page 4: Box Content
You will also find a cardboard box that contains 7 bolts with 3 special double washers, 1 standard M10 washer, an M10 hexagon wrench, 4 acetal levelers with grub screws and nuts. If you bought Botticelli X you will also find the 6 umbilical cables to connect the crossovers, they are under the speaker. - Page 5 4. Always keep the case you are opening with the other under it or something else with a thickness of 15-20cm to get the right height and put a thick anti-slip rug, rubber mat or carpet with no possibility to shift close to the cases were the speaker will touch the floor when you lift it up.
- Page 6 upright 2 strong people are necessary as the total force needed is about 60Kg. Please be also very careful to avoid bending our back as you might hurt yourself, always bend your knees. Picture 4 and Photo 9 Once the speaker is out of the crate you can move it on the floor using a cart or making it walk by making leverage on side levelers.
- Page 7 Positioning your ALSYVOX speakers Positioning in your room requires some move and listen trial, as always, but the line source dipole dispersion will help with minimal room influence on the timbre of the sound.
- Page 8 Botticelli or Botticelli X If you bought Botticelli it is possible to upgrade to Botticelli X buying the external crossovers. There is a switch in the back below the 4 binding posts. Switch UP...
-
Page 9: Warranty
As a consequence minor defects are totally normal and not covered by our warranty. ALSYVOX warrants to the purchaser that the Botticelli speakers are free of defects in materials and workmanship for a period of five years from date of purchase. -
Page 10: Warranty Info
There is no implied warranty of fitness for the purpose, nor is there any implied warranty of merchantability. Warranty info: Purchase Date_________________________________________________________________ Dealer_______________________________________________________________ Purchaser_____________________________________________________________ Speaker Serial Number______________________________________________________________ Send to: ALSYVOX S.L. Calle Doctor JJ Domine 4 puerta 2 46011 VALENCIA (SPAIN) - Page 14 Photo 1 - Always keep the other flight case under the one you are opening to reach the right height (or leave something strong under it with about 20cm height)
- Page 15 Photo 2 - Open the top of the flight case, please notice the protective grey lip that prevents touching the aluminum profile when pushing the speaker out of the edge...
- Page 18 Photo 3 - Push the speaker till the end with holes for 7 screws (lower side closer to the binding posts) becomes clear of the edge of the case by at least 50mm (2”)
- Page 19 Photo 4 – Clear off the edge of the protective PE film Photo 5 - Put the base in the right orientation (longer steel protrusion at the binding posts side) and position the 4 top screws with 1 washer on the head side and 1 washers on the other side...
- Page 20 Photo 6 – Add the other screws making sure they find the hole in the washer at the inside (outside washers missing here but recommended)
- Page 21 Photo 7 - Tighten the screws applying a high torque (recommend 40-50Nm if you have a torque limiter) and screw in the levelers (without cup and ball)
- Page 23 Photo 8- Make sure a thick rug or rubber pad is positioned under the base before you lift it and screw the levelers in if you have not done it already...
- Page 25 Photo 9 - Lift the speaker as described in picture 4, minimum 2 strong guys are needed here!
- Page 26 Photo 10 – Switch in the bypass position (Botticelli X) and 3 Neutrik® SpeakOn® connectors...
