Summary of Contents for GAIM Commercial
- Page 1 GAIM COMMERCIAL USER GUIDE...
-
Page 2: Table Of Contents
Contents Prerequisites ......................... 2 Pack List ..........................2 Hardware Setup ........................3 Software Setup and Calibration ..................... 5 Swift menu options and setting ................... 10 Tips when playing ....................... 12 Troubleshooting ........................13 Software Issues ....................... 13 Vive Tracker Issues ......................14 Vive Headset Issues ...................... -
Page 3: Prerequisites
Prerequisites A working internet connection is required during setup, or the setup will undoubtedly fail. Internet is not required for usage of the system, once installed, however recommended to keep the software updated. As a minimum make sure the system regularly is connected to check for updates. -
Page 4: Hardware Setup
Hardware Setup 1. Plug in the computer to a power outlet and make sure it receives power. If using a laptop-based system, the laptop should be started and run plugged in, otherwise the graphic card won’t run at full capacity resulting in a bad VR experience. If using a laptop-based system skip step 2-3. - Page 5 Recommended lighthouse positioning for optimal tracking in static scenarios, like hunting. If movement is required in the space optimal placement of the lighthouses would be diagonal across the floor.
-
Page 6: Software Setup And Calibration
Software Setup and Calibration When delivered, the system still needs some finalising setup before usage. Parts of the setup are personalised; hence they need to be done by you. Initial Windows setup 1) After the very first powerup, Windows operating system will do its final setup. Please follow the onscreen instructions and customise the computer to fit your preferences. - Page 7 Finish the Steam VR setup. GAIM OS GAIM OS should be installed as part of the initial Windows installation, if not, please use the USB stick provided with the installation file and run the installation. 1) Creating a GAIM OS desktop shortcut g.
- Page 8 GAIM OS. 2) Start GAIM OS from the computer desktop. a. The first time you launch GAIM OS you will get see a version number at the bottom left (7) that tells you what launcher and engine version currently...
- Page 9 To install these updates click the “install all” button (7) and wait until all products are updated before launching GAIM OS (8). 3) Place the headset on the floor in the direction you want the shooter to be facing when playing and press “Q”...
- Page 10 6) In the option menu you can adjust the gridwalls (13), toggle sound effects, music, and whether or not you would like your system in demo mode (14), and finally go back to the previous menu with the arrow button (15). 7) Gridwalls are set by clicking the up and down arrows (16) for each wall.
-
Page 11: Swift Menu Options And Setting
Swift menu options and setting 1) The Swift menu is opened by holding the controller vertically and twisting 90 degrees. See image below. Once in the Swift menu you have many options available to you. These are:... - Page 12 a) Tutorials – Toggling this setting will change whether you are shown how to target and lead your shots prior to starting a scenario (17). Not that these tutorials are not on all scenarios. b) Dominant eye – Setting the dominant eye will make it easier and more natural to aim using the red dot scope (18) c) Extra large sight –...
-
Page 13: Tips When Playing
m) Close menu – This will close the Swift menu and take you back to the previous screen or scenario (29). Tips when playing Please keep the following things in mind when using the system: ● Wipe the lenses with a cloth designed for lenses/glasses regularly. ●... -
Page 14: Troubleshooting
Troubleshooting Software Issues There is no sound If the program is silent after starting it, make sure the program is focused in the computer by clicking on the program window on the computer. If there is still no sound, close and restart the program. The keyboard controls are unresponsive Make sure the program is focused on the computer by clicking on the program window on the computer. -
Page 15: Vive Tracker Issues
Vive Tracker Issues Tracker light meaning ● Green when Vive Tracker is connected and functioning correctly. ● Blue when Vive Tracker is not connecting with the headset or dongle. ● Blinking Blue when Vive Tracker is pairing with the headset or dongle. ●... -
Page 16: Vive Headset Issues
Vive Headset Issues Headset light meaning ● Green when headset is connected and functioning correctly. ● Dim Green when ready for use, but has timed out into standby mode. To wake up your headset, move it within view of the base stations or start a VR application. ●... -
Page 17: Vive Lighthouse Issues
Low framerate or lag Check the following: • Go to Steam VR Settings →General, Make sure “SteamVR Always on Top” is “On” ● The laptop is connected to a power outlet and receiving power. ● The laptop Power Settings (found in the control panel) is set to “High Performance”. ●... - Page 18 This will likely cause issues for both parties. Coordinate both setups so that the lighthouses see as little as possible of the opposing booth. The lighthouses emit large amounts of infrared light, and it is important that the lighthouses from one setup can’t see any headsets, controllers, trackers or lighthouses from another set, or they will start sending faulty data.
-
Page 19: Rifle Issues
Rifle Issues Nothing happens when I pull the trigger The VR software must be in focus on the laptop to function correctly. On your computer, simply click anywhere in the window of the VR simulator to bring it to focus. I can’t see the rifle •... - Page 20 The rifle shakes or moves erratically This is most commonly caused by the lighthouses losing connection to the tracker. If only one lighthouse can see the tracker, minor disturbances may occur. Review your lighthouse positioning to ensure maximum exposure of the tracker. Make sure the lighthouse mounts aren’t shaking or have been disconnected.
-
Page 21: Key Commands
Key Commands Weapon controls Point weapon upwards and twist weapon = Back to map select ° back and forth Calibration and setup controls = Calibrate centre = Calibrate railing = Switch spectator mode = Restart environment = Toggle which controller to track Ctrl = Toggle between hand controllers Backspace...
