TRIGAUDIO BVT UI Quick Start Manual

BVT UI DEVELOP KIT DESCRIPTION
MULTI-SOUND EFFECT MODULE DESIGN
TOOLS
Introduction
BVT UI is a most professional quality and easy-to-use audio module which is also a concept combination with a core
module and main board (or evaluation board, EVB). Besides, BVT series is designed by TrigAudio Corp.
to meet most professional quality standard, easy-to-use application requirements and many possible end-equipment
configurations from customers in order to offer the groundbreaking music creation programs. That also can be
applied as mixer / DJ /guitar amp. / Karaoke equipments and other devices which need sound effects.
Based on this universal core module, what BVT UI gives you is the freedom to expand your production capability and
amounts of development easily and with total integration intact which no need to worry about the performance or
integrating problems, since the core module already covers most functions and features for the audio applications.
In other words, BVT series gives you an entire audio production package and optimize the greatest positive
advantages that virtually have no limits
BVT UI Instruction
Hardware:
1.1 BVT-UI EVB layout
1. Platform provides quick and easy audio input and output connections
2. Jumpers on the platform select power and module control options
3. Effect preset programs
4. Reset
5. Control data save eeprom
USB Serial Peripheral Interface (SPI) Port Configuration
6.
DC jack
7.
8. Plate algorithms and location indicator
