1. Introduction

The Skylane Optics® Tuning Box allow you to set the wavelength of the Skylane Optics® XFP DWDM Tunable
50GHz (P/N: XFDTU0800H0D000)
The tuning box software is only compatible with Microsoft Windows XP / VISTA / SEVEN
Even if the Tuning Box has 3 pluggable ports (SFP+ / XFP / GBIC), only the XFP port is enabled.

2. Connecting the tuning box to the computer

1. Connect the supplied USB cable to the Tuning Box and the twin USB to your computer.
If you connect only one part of the twin USB, the box won't work properly.
