Micromat 1575 User Manual

Pcb drilling system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MICROMAT INTERNATIONAL,
SANDERS LODGE,
WELLINGBOROUGH ROAD,
RUSHDEN,
NORTHANTS,
NN10 6BQ
ENGLAND
Tel:
(01933) 313093
Fax:
(01933) 319293
MICROMAT
PCB DRILLING SYSTEM
USER MANUAL
Intnl : +44 1933 313093
Intnl : +44 1933 319293

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1575 and is the answer not in the manual?

Questions and answers

Related Manuals for Micromat 1575

Summary of Contents for Micromat 1575

  • Page 1 MICROMAT PCB DRILLING SYSTEM USER MANUAL MICROMAT INTERNATIONAL, SANDERS LODGE, WELLINGBOROUGH ROAD, RUSHDEN, NORTHANTS, NN10 6BQ ENGLAND Tel: (01933) 313093 Intnl : +44 1933 313093 Fax: (01933) 319293 Intnl : +44 1933 319293...
  • Page 2 MICROMAT PCB DRILLING SYSTEM INTRODUCTION Welcome to the Micromat World of Drilling. If you are an existing Micromat user you will already be aware of the advanced features and concepts of the Micromat control system. The Model 1575 takes those features a step further in usability. This screen based control system provides an unequalled clarity of comprehension and with direct CAD disk compatibility there should be no circuit boards that you cannot process.

  • Page 3: Routine Servicing

    ROUTINE SERVICING The only basic attention required by the Micromat is that it is kept clean and free from dust and grease. The swarf extraction unit should be emptied at least daily and the filter bags well shaken to avoid dust clogging and subsequent overheating and destruction of the motor. The motor brushes should be inspected monthly and replaced if required.

  • Page 4: Installation

    In some areas it may be necessary to use a power supply filter / regulator unit to prevent power line interference. Although the Micromat will operate under a wide variety of conditions it should not be subjected to extremes of temperature as this will obviously affect its accuracy.
  • Page 5 INTERCONNECTIONS Micromat PC...

  • Page 6: Getting Started

    Please don't press any keys at this point. After a few moments, the Micromat Welcome screen will be shown and a number will countdown from 10 to 1 while the control system is loaded and configured.

  • Page 7: Menu Screen

    This is the central point of the control system and any of the three screens through which the system is controlled may be accessed from here. All the functions of the Micromat control system are accessed through either the Program, Run or Files screen, making the system simple to learn and easy to remember.
  • Page 8 Single Step and Back Step controls, is shown on the TV screen and whose Tool number and Command are shown on the Reference display line. General help is available at the basic screen level to remind you of the available functions. Micromat PC...
  • Page 9 Micromat PC...

  • Page 10: Functions And Commands

    A RESET command sets the system to the FIRST command of the program and sends the machine to its HOME position. Both the ABSOLUTE and REFERENCE position displays are set to ZERO. Any offset information that may have been programmed is also set to Zero. Micromat PC...
  • Page 11 The two numbers displayed after conversion correspond to the number of commands in the Step-and-Repeat program and the actual number of commands in the new, expanded program. Micromat PC...
  • Page 12 EXIT - Esc EXIT - Esc EXIT - Esc The Esc key offers a return to the Menu screen. Press Enter to Exit to the MENU screen or Esc once again to cancel the command and return to Program. Micromat PC...
  • Page 13 Then press Enter. The user programmable value is now selectable along with all the other values which can be accessed by using the Up and Down arrow keys as above. The value will be saved and restored the next time the system is switched on. Micromat PC...
  • Page 14 Pressing P allows changes to the position, size and colour of the TV Target. Press P to show a GREEN highlight Picture Position Esc will cancel the function. Use the arrow keys to change the POSITION of the target. Press C to set the target to the centre of the screen. Micromat PC...
  • Page 15 O (oops!) and the last command you deleted will be recovered. This only works for the very last delete! Delete twice and you can only restore the last one. If you don't want to delete, don't press the button! Micromat PC...
  • Page 16 Single Step and Back Step are used. When a Tool number and Command are displayed they are those of the Current Command. The Tool number and Command are also displayed for a short time whenever a command is entered with the Spacebar. Micromat PC...
  • Page 17 TV Picture to avoid driving the table to any of it's limit positions. YELLOW bars indicate that the table is within 6mm of its limits, a RED bar indicates limit. If the table is driven into its limit then all motion will stop and HOME must be pressed to enable further movement. Micromat PC...

  • Page 18: Program Backup

    ..so just use floppy disks. The Micromat has another program backup system and its use is intended to solve the problems of power failures and other inadvertent shut downs which may cause loss of data.
  • Page 19 Arcs can be entered by just using the Down command to program three points around the arc. The cutter will trace an arc through all three points starting with the first point, moving through the second point and finishing at the third point. Micromat PC...
  • Page 20 TOOL number IS important, since UP commands are used in conjunction with previously entered DOWN commands using the same TOOL number. NOTE:- DOWN and UP and DOWN and CTR commands for the same cut must be programmed with the same TOOL number. Micromat PC...
  • Page 21 The backup data can be re loaded into memory by pressing Shift and the L key. The memory of the Micromat will store 9,800 individual commands. This is exactly the same as the original Micromat systems and the number is retained for compatibility.
  • Page 22 Use 30,000 to 40,000 rpm for the 450 watt spindles. If a high pitched whine is heard then try reducing the cutter rpm, or increasing the cutting rate. For smaller cutters, e.g. 1 mm and under, use a higher spindle speed (55,000) and slower cutting rate. Micromat PC...
  • Page 23 Any measurement of routed parts should be conducted with great caution as changes in temperature can greatly change the size of a piece of laminate. Micromat PC...
  • Page 24 Positions 1 to 11 are programmed sequentially with DOWN commands at each point. Position 12 is then programmed with 3 commands, all in the same place:- DOWN, UP and END. Note that in this example points 6 and 8 are in the same position. Micromat PC...
  • Page 25 359.5 degrees in either direction; the Double Down indicates the start of the arc. ARCS using DOWN-CENTRE-DOWN COMMANDS Position Command DOWN DOWN CTR CW DOWN DOWN Position 3 needs only to be approximate, the system will recalculate it's position to keep both 'a' and 'b' equal in length. Micromat PC...
  • Page 26 As above but position 2 is programmed with CTR CCW SIMPLE CIRCLES Outside circles Position Command CTRCW CTRCW An UP command is not required as it is automatic after the second CTR Two CTRCCW commands can be used for inside circles Micromat PC...
  • Page 27 ONLY the commands programmed with that tool number will be performed. Rout, Speed, Feed, Clear, Depth and Peck can all be changed while a program is running or by pessing HOLD (F7), changing the settings and pressing F7 again. Micromat PC...
  • Page 28 Press Shift - D and Z axis will drive down to its lowest position. Refit spindle with tip of tool touching top of the 0.5mm material. Tighten spindle clamp and reconnect spindle cable. Press Shift - D to lift head to up position. Micromat PC...
  • Page 29 On the RUN screen, Clear sets the position of the head during its travel between holes and is probably best left at the same setting for a given job. The Depth setting sets the depth of the hole below the Workheight for each particular Tool Number. Micromat PC...
  • Page 30 0.8 mm above the bed of the machine and a backup material of greater than 1.6 mm should be used to ensure that the drill will pass completely through the circuit board. For large diameter drills (above 2 mm) the backup material thickness should be increased unless the drills have flat tips. Micromat PC...
  • Page 31 Press the Tab key to highlight “X & Y Limits” and press Enter The machine will measure its table limit positions relative to the camera position and store the results. Press Esc to return to the Main Menu Micromat PC...
  • Page 32 11) Use SST and BST to look at the holes and adjust the target position if necessary by pressing P and using the arrow keys to adjust the target position. 12) Target size and colour may also be adjusted. Press F1 for details 13) Press Enter when finished Micromat PC...
  • Page 33 HOW TO ENTER, EDIT AND DRILL A PROGRAM In order to fully understand the operation of the Micromat, it is strongly advised that these instructions are followed, step by step, until the procedures become second nature to the operator. The basic controls will be dealt with first, and after becoming fully conversant with these the operator should progress to the section covering RPT, BRACKET, SIL, MOVE, and EXPAND commands.
  • Page 34 Reference coordinates will be set to Zero and a round target will appear on the TV picture. The system is ready for manual program entry. 2) Place your Micromat Drill Program Tutor No 1 on the bed of the machine with the arrow pointing towards the machine's HOME position.
  • Page 35 14) To finish, simply press the E key and an END command will be added to the program. The Micromat is now programmed to drill the 14 hole pattern which has just been entered. The program consists of 14 HOLE commands and one END command.
  • Page 36 To edit the position, Tool number or Command of a particular position, use Single Step or Back Step to move the target to the position, adjust the position with the joystick if required, ensure that the Active Tool and Command are correct and then press the Spacebar. Micromat PC...
  • Page 37 Back Step or Single Step. After the delete, the TV target will move forward through the program to the next position. An END command cannot be deleted but it can be overwritten by another command. Micromat PC...
  • Page 38 END. Practice moving various programmed positions, deleting and inserting, but initially, only attempt to move, delete or insert one position at a time, learning what happens when Single Step and Back Step are used immediately after each operation. Micromat PC...

  • Page 39: Practice Makes Perfect

    Tool numbers other than Zero will drill (or rout) the commands that were programmed with that Tool number. Try reprogramming some of the positions with different tool sizes and try using the CHECK function to view the result of running with different Tool number settings. PRACTICE MAKES PERFECT Micromat PC...
  • Page 40 The last Tool number to be run will stay YELLOW on the screen with a RED highlight END. The screen will also show the time taken and the number of holes drilled. The program will remain in the control systems memory until a new one is entered or the existing one is modified. Micromat PC...

  • Page 41: The Run Screen

    Esc. Whenever a GREEN function highlight is on the screen, pressing F1, HELP, will give assistance with that particular function. General help is available at the basic screen level to remind you of the available functions. Micromat PC...
  • Page 42 Micromat PC...
  • Page 43 HOME position. RUN - F6 RUN - F6 RUN - F6 RUN - F6 Pressing F6 will start a drill or rout program from the point shown in the message box above the Time to run display. Micromat PC...
  • Page 44 GREEN cursor to the Hits, Max and Rout columns. When the system is running, the GREEN cursor can be moved to the right to alter the values on the fly for the active tool number. Micromat PC...
  • Page 45 Hits value for the tool, if it has already been used, and press Enter to carry on with the run. If Enter is pressed without using the Up and Down arrow keys, then the Hits will be set to zero and the run will continue. Micromat PC...
  • Page 46 1, followed by 2, etc., With the Micromat, Tool numbers can be entered in any order and in any combination of sizes, the only exception being that routing commands for a given cut must all be programmed sequentially and with the same Tool number.
  • Page 47 Change type, BEWARE it may be the Keeper so use INIT to fit the correct tool into the collet because the Keepers don't drill holes very well and they certainly don't rout!. The Tool number has a similar effect on the CHECK procedure. Micromat PC...
  • Page 48 Search function to find the point at which the tool broke, pressing Single Step once and then pressing F6 and Enter to go to the RUN screen and commencing the run by pressing F6 once more. Micromat PC...
  • Page 49 The Tool number setting is irrelevant for REPEAT and BRACKET commands as they are automatically entered as Tool zero. When the program is in the RUN mode, any REPEAT and BRACKET commands will always be required whatever Tool number setting is used for RUN. Micromat PC...
  • Page 50 The commands entered are just the same as those entered manually and can be stepped through and edited just as normal commands. Micromat PC...
  • Page 51 PROGRAM MOVE AND EXPAND These functions are helpful to the programmer in that they allow patterns to be moved around the drilling bed of the Micromat and to be repositioned to make the best use of laminate blanks. The MOVE routine simply repositions a drilling or routing pattern, complete with any REPEAT or bracket commands.

  • Page 52: Program Move

    The command, and everything following it up to the END, will be moved, and the TV target will indicate the new position of that command. CAUTION The operator must ensure that the moved program will still fit within the limits of the drilling table. Micromat PC...
  • Page 53 If enough memory is available the Micromat will compute the new program and write it into memory in place of the old step and repeat program. The target will move to the first command after expansion.
  • Page 54 The initial FILES screen consists of a representation of the two disk drives on the front panel of the Micromat function menu panel to the right and an information panel below. When a function is selected, a more detailed screen will appear with full instructions for each function.
  • Page 55 Micromat PC...

  • Page 56: Data Format

    If data is saved when the line beneath the filename window shows MA the data will be saved in Micromat ASCII format as detailed below. This has the same command structure as the binary format but is viewable with a normal text editor such as Notepad...
  • Page 57 The Up and Down arrow keys change the function described on the GREEN strip across the centre of the screen and allow the selection of one of the five options. The selected option is accessed by pressing Enter. Micromat PC...
  • Page 58 Enter) Any other name will not work. On return to the Disk screen, WORK.MMM will be the Micromat format version of the originally unrecognised file and this will be loaded into the control systems memory. If you wish to give it a different name then simply use the SAVE function and then delete WORK.MMM to avoid confusion.
  • Page 59 If just a name of up to 8 characters is given, the system will automatically append .mas to the name if MA is displayed. ( .mmm if not ) LOAD A MICROMAT FILE FROM NETWORK SAVE A MICROMAT FILE TO NETWORK These are the same as the floppy disk functions but the Network Drive must already have been set in Windows and the assigned drive letter entered in the Utils 2 screen.
  • Page 60 CAD data files from floppy disk. The converted data will be saved back to floppy disk and can then be loaded into the Micromat control system using the LOAD function. MM-PLOT also contains a drill path optimiser. Micromat PC...
  • Page 61 Micromat PC...
