MOEBE Shelving System Assembly Instructions Manual

REQUIRED:
1
3
Assembly Instructions: Shelving System
Drill
10
9
7
6
4
3
1
PLAN AHEAD
Carefully plan the placement of the
shelves before starting to build your
system.
Each shelf is designed for a load
capacity of up to 20 kg.
SHELVES CAN ONLY BE ASSEMBLED
ONE WAY
The shelves have to be turned the right
way when assembling - the indicator
dot should always face downwards.
Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / info@moebe.dk / +45 71 74 74 96
Hammer Water level
8
2
5
2
2
4
ASSEMBLING A SHELF
Place the first shelf on the ground and make sure
that it is turned the right way. Insert one leg at a
time through the holes and lift the shelf to a desired
height.
Use the wedges to fix the shelf, tap them a few times
with a hammer to secure, repeat this for all four legs.
Watch out not to leave any marks.
When the first shelf is in place, the assembling gets
easier.
Ruler
BEGIN WITH THE LEGS
Insert an end cap into the bottom of
each leg. Use a hammer if needed.
