Deep 6 Excursion User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Deep6 Excursion



USER MANUAL
V 1.0 (Beta)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Excursion and is the answer not in the manual?

Questions and answers

Related Manuals for Deep 6 Excursion

Summary of Contents for Deep 6 Excursion

  • Page 1: Deep6 Excursion

    Deep6 Excursion
 USER MANUAL V 1.0 (Beta)

  • Page 2: Table Of Contents

    Deep6 Excursion 1. Screen and Functions 1.1 Buttons function 1.2 Main Menu 1.3 Watch Mode and Setting 1.4 Scuba Mode and Settings 1.5 Gauge Mode 1.6 Apnea Mode and Settings 1.7 Log Mode 1.8 Settings Mode 1.9 AUTO Mode 2. Deep6 Contact info...

  • Page 4: Screen And Functions

    1. Screen and Functions - 1.1 Buttons function
 Locate： Right Top Name ： Up Key Locate： Left Top Func ： Move Up / Quick Name ： Power Key Settings. Func ： Power Switch / Escape Locate： Left Middle Name ： Mode Key Func ：Menu / Enter Locate：...

  • Page 5: Main Menu

    1.2 Main Menu 1.2Main Menu Description： Watch Mode Enter： Default Screen when turn on. Others : or Choose the WTACH mode under the main menu Description： Scuba Mode Enter： When dive into the water, Scuba Mode will be automatically active if your default mode settings is “SCUBA”.
  • Page 6 1.2Main Menu Description： Apnea Mode (Free dive) Enter： When dive into the water, APNEA Mode will be automatically active if your default mode settings is “APNEA”. Others：Or Choose the APNEA mode under the main menu Description： Dive Logs Enter： Press the mode button, and choose LOG mode.
  • Page 7 1.2Main Menu Description： Sync Mode Enter： Press the mode button, and choose SYNC mode. Others： Once entered, computer will wait for the connection from your devices.

  • Page 8: Watch Mode And Setting

    1.3 Watch Mode and Setting 1.3.1 Watch Mode Description：The default screen when turn on. Enter： By pressing esc to the top layer, or choose the watch mode from the menu. Others： 1. When the device has no any operation under the watch mode screen, it will enter the standby mode (no screen), and for a longer period (about 24 hrs) without any operation, then enter the...
  • Page 9 1.3.2 Watch Mode Settings Description： Date Settings Enter： Press the Up Ley under the watch mode, or from the Menu -> Setting. Others：Move up or down to the DATE and press Middle Key to enter, then you will see the dates is blinking, then press Up or Down to adjust, then press the Middle key to confirm and next setting, until stop blinking and finish the settings.
  • Page 10 1.3.2 Watch Mode Settings Description： Auto active mode when dive into the water. Enter：Press the Up Key under the watch mode, or from the Menu -> Setting. Others：Move up or down to the AUTO MODE and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish...

  • Page 11: Scuba Mode And Settings

    1.4 Scuba Mode and Settings 1.4.1 Scuba Mode Scuba Mode Enter： Press the Up Ley under the watch mode, or from the Menu -> Setting. Others：Move up or down to the DATE and press Middle Key to enter, then you will see the dates is blinking, then press Up or Down to adjust, then press the Middle key to confirm and next setting,...
  • Page 12 Description: Scuba Under Water Mode 18.6m: Current Depth NDL: The Non-Decompression Limit time in minutes. PPO2: Current PPO2, there has alarm if reaching the limit. ：Ascent speed in Meter/Min, If reach the 10M/minutes, there has alarm. TIME: Dive time. TEMP：Water temperature. Description: Scuba Under Water Mode - When exceed the NDL NDL: When exceed the NDL time, the first...
  • Page 13 Description: Scuba Under Water Mode - When exceed the NDL and finished the ceiling depth stop. CLEAR：When you finish the deco stop at the ceiling depth, it shows CLEAR means the stop finished, you may slowly ascent to surface.
  • Page 14 1.4.2 Scuba Mode Settings Description: Scuba Preview Mode Press the Top Right buttons to enter the settings. Notes: Scuba mode settings is available only under the predate mode Description： Nitrox Setting. Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting.
  • Page 15 1.4.2 Scuba Mode Settings Description： PPO2 Setting. Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the PPO2 and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish the settings.
  • Page 16 1.4.2 Scuba Mode Settings Description： Depth Alarm - on./off. Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the SDPTH- ALM and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish...
  • Page 17 1.4.2 Scuba Mode Settings Description： Depth Alarm Setting. Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the SDPTH- THD and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish the settings.
  • Page 18 1.4.2 Scuba Mode Settings Description： Sampling Rate. Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the SAMPLING and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish the settings.
  • Page 19 1.4.2 Scuba Mode Settings Description： Scuba User Interface Setting Enter：Press the Up Key under the Scuba Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the UI and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish the...

  • Page 20: Gauge Mode

    1.5 Gauge Mode 1.5 Gauge Mode Description: Gauge Mode ：Battery Indication 1008 mBar: Current ATM AVG：Average Depth in the current stage STPW：Stop Watch - Dive Time in the current stage TIME: Dive Time TEMP：Water temperature. Notes: you may reset the AVG - Average Depth and and STPW - Stop Watch - Dive Time in the current stage by pressing the Right Top Button to...

  • Page 21: Apnea Mode And Settings

    1.6 Apnea Mode and Settings 1.6.1 Apnea Mode Description: Apnea Mode (Free Diving) ：Battery Indication 000.0m: Current Depth SI：Surface Interval LAST DPTH：Max Depth of the last dive LAST TIME: Dive Time of the last dive TEMP：Water temperature. Description： Stop Watch Enter：Press the Down Key under the Apnea Mode.
  • Page 22 1.6.1 Apnea Mode Description： APNEA AVERAGE history Enter：Press the Down Key under the MAXIMUM RATE Mode. Others： ASCENT：Average Ascent speed DESCENT：Average Descent speed 1.6.2 Apnea Mode Settings Description： Dive Time Alarm - on./off. Enter：Press the Up Key under the Apnea Mode - or from the Menu ->...
  • Page 24 1.6.2 Apnea Mode Settings Description： Dive Time Alarm - on./off. Enter：Press the Up Key under the Apnea Mode - or from the Menu -> Setting. Others：Move up or down to the FTIME- ALM and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish...
  • Page 25 1.6.2 Apnea Mode Settings Description： Surface Interval Alarm Enter：Press the Up Key under the Apnea Mode - or from the Menu -> Setting. Others：Move up or down to the FSI-ALM and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and finish the settings.
  • Page 26 1.6.2 Apnea Mode Settings Description： Depth Alarm Setting. Enter：Press the Up Key under the APNEA Mode - Preview, or from the Menu -> Setting. Others：Move up or down to the FDPTH- THD1 - 3 and press Middle Key to enter, then you will see a blinking, then press Up or Down to select, then press the Middle key to confirm, until stop blinking and...

  • Page 27: Log Mode

    1.7 Log Mode 1.7 Log Mode Description： Log Mode. OC: Open Circuit Scuba mode. If Freedive logs shows F, Gauge dives shows GA DATE: Dive Date and Time MAX：Max depth of the dive TIME: Dive time TEMP：Water temperature. 000 / 000 : Log Number / Total Logs Notes: you may press UP or DOWN keys to scroll up or down to view other logs.

  • Page 28: Settings Mode

    1.8 Settings Mode 1.8 Settings Description： Unit Setting. Enter：From the Menu -> Setting -> Select UNIT. Others：You may choose M/C：Metric（Meter and Celsius ） Ft/F：Imperial（Feet and Fahrenheit） Notes : Change the settings will affect to all the related display, there has some tolerance because of the transform calculations.
  • Page 29 1.8 Settings Description： Back Light setting Enter：From the Menu -> Setting -> Select BACKLIGHT. Others：There are 3 levels of the brightness, 25, 50, 75, means the LED power consumption percentage. Higher number means brighter backlight, which is use more battery power. Notes : Any change will affect the running time of the device.
  • Page 30 1.8 Settings Description： Clean Tissues - Clear the residual nitrogen calculation from the device. Enter：From the Menu -> Setting -> Select TISSUE CLR. Others：ON / OFF WARNIMG : 1. DO NOT use this function unless you FULLY UNDERSTAND the decompression theory and aware the consequence of cleaning the residual nitrogen.
  • Page 31 1.8 Settings Description： Reset to factory setting. Enter：From the Menu -> Setting -> Select SYS RST. Others：ON / OFF Notice : 1. By restore all the settings to the factory reset. 2. All the custom settings will be lost, but residual nitrogen and logs won’t be affected.

  • Page 32: Auto Mode

    Enter：From the Menu -> SYNC Notice : 1. You may exit any APP that connect to the the computer, once no any other devices connected, it’ll back to the waiting status. . Deep 6 Gear Contact information EMAIL：SUPPORT＠DEEP6GEAR .COM WEBSITE : www.deep6gear.com PHONE: +1-404-800-5967...
