Wulf's Custom Welding 0298 Instructions

1 1/4" TRAIN-LINE EXTRACTOR INSTRUCTIONS:

Capacity: 1 1/4" Train-line Pipe.
FIGURE 1
Available Through:
Wulf's Custom Welding
19102 So. 156
Springfield, NE 68059
Tel: 402-253-2772
Fax: 402-253-9092
Website: wcwrail.com
Reference Part Number:
1 1/4" Train-line Pipe Extractor: 0298
Tool Weight: Less Than 1 Pound
Base Construction Material: Heat-Treated Tool Steel.

DESCRIPTION:

This extractor is designed to remove broken portions of 1 1/4" Train-line pipe. It has
no other intended uses.
1 1/4" TRAIN-LINE EXTRACTOR INSTRUCTIONS:
1. Inspect the extractor prior to use. Remove the extractor from service if any of the tines are
broken, or the extractor is excessively worn (Figure 1).
2. Place the extractor into the broken train-line pipe to be removed (Figure 2). Strike the end
of the extractor lightly with a hammer to seat it firmly into the pipe.
3. Use a 1 3/8" combination wrench or large adjustable wrench to turn the extractor counter-
clockwise to remove the broken pipe.
4. When the broken portion of pipe has been removed, turn the extractor clock-wise to
remove it from the pipe.

SAFETY PRECAUTIONS:

WARNINGS: Noncompliance could cause injury to employees.
CAUTIONS: Noncompliance could cause damage to equipment
th
Street
FIGURE 2
