Summary of Contents for LUXTEC CLX
- Page 1 User Manual for CLX Xenon Light Source ENGLISH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Symbols ……………………………………………………..…1 General Warnings ……………………………………………………… 2 Overview ………………………………………………………………... 3 Operation ……………………………………………………………….. 4 Xenon Lamp Replacement …………………………………………. 5-6 Optional Floor Stand Installation ………………………………….….. 7 Equipment & Parts List ...……………………………………………..8 Troubleshooting …...……………………………………………….…... 9 Maintenance and Cleaning .……………………………………….…. 10 Specifications .…………………………………………………….……... -
Page 3: General Warnings
EMC. These precautions are defined on pages 11 thru 14 of this Users Manual. The CLX must be installed and put into service according to the EMC information provided. The leakage current of medical electrical devices can be additive. When using the CLX in combination with other medical electrical devices, such as endoscopes and/or endoscopically-used accessories, the leakage current should be verified to ensure it continues to meet requirements. -
Page 4: Overview
The CLX delivers white Xenon light. The lamp can be easily replaced by the user without special tools. The rear panel, main power on/off rocker switch, is located on the back of the CLX. See Figure 1. The front panel push button, on / standby switch, is used to select lamp on or lamp standby. -
Page 5: Operation
When the lamp is operating there is light visible through the vent holes and the fan grill. Light Attenuation The CLX has a manually operated light intensity Figure 5 Attenuator ring ring to control the desired light output level. To increase the light output, rotate the ring clockwise until the desired level is reached. -
Page 6: Xenon Lamp Replacement
3. Remove the retaining screw located at the back of the at the CLX. See Figure 3. 4. Slide the top cover of the CLX towards the back of the unit. Do not slide the cover off completely, rather just enough to remove and replace the lamp. - Page 7 3. Fully slide the top cover of the CLX forward. Install the retaining screw (Figure 3) using a screwdriver. 4. Connect power cord to the back of the CLX. Set main power on/off switch to the “on” position then press on / standby switch to turn the unit “on”.
-
Page 8: Optional Floor Stand Installation
Tighten handle screw to hold in place. Caster base Fully insert post of the CLX base plate into plastic bushing on top of upper column. Rotate base plate until fingers in the bushing engage slots at the bottom of the post. -
Page 9: Equipment & Parts List
EQUIPMENT & PARTS LIST To place an order, contact your local Luxtec distributor or call Luxtec Customer Service at 800-325-8966 (USA) or +1-508-835-9700 (International). Light Source 00-CLX CLX, Xenon light source 850358 User Manual for the CLX Adapter Options 401193... -
Page 10: Troubleshooting
(Fuse 3.15A, 250VAC, 5x20 mm, Slo-Blo, IEC Standard, Luxtec part number 601919). After replacing fuse(s), push the red plastic fuse holder back into the power entry module and snap access cover close. Plug the cord back into Light Source and re-test the unit. -
Page 11: Specifications
SPECIFICATIONS Lamp Type Xenon Short Arc Lamp Wattage 150 Watts Lamp life 500 Hours Light Source Dimensions 12.6"L x 6.2"W x 5.9"H (320mm L x 157mm W x 150mm H) Weight 9.2 lbs. (4.2kg) Power Input 100~240VAC 50-60 Hz ± 10% Fuses (2) 3.15A, 250VAC, 5x20 mm, Slo-Blo, IEC Standard Power Consumption... -
Page 12: Electromagnetic Compatibility (Emc) User Information
WARNING: Portable and Mobile RF Communications Equipment can affect Medical Electrical Equipment. WARNING: The CLX Light Source should not be used adjacent to or stacked with other equipment. If this becomes necessary the CLX should be observed to verify normal operation in the configuration in which it will be used. - Page 13 Guidance and Manufacturer’s Declaration—Immunity All Equipment and Systems The CLX Light Source is intended for use in the electromagnetic environment specified below. The customer or user of the CLX Light Source should assure that it is used in such an environment. IEC 60601 Test...
- Page 14 18 and 23 V/m. During the testing the energized probes of the ESG were at a distance of 6" from the CLX and the ESG was energized in the cut and coagulate modes. The functioning of the CLX was not effected by exposure to this energy.
- Page 15 Equipment and the CLX Light Source Equipment and Systems that are NOT Life-Supporting The CLX Light Source is intended for use in the electromagnetic environment in which radiated disturbances are controlled. The customer or user of the CLX Light Source can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF Communications Equipment and the CLX Light Source as recommended below, according to the maximum output power of the communications equipment.
-
Page 16: Product Warranty
PRODUCT WARRANTY Luxtec warrants that the CLX light source (except the lamp) shall be free from defects in material and workmanship under normal use and service for a period of three (3) years from the date of shipment from Luxtec. Luxtec’s sole and exclusive liability under the warranty shall be, at Luxtec’s option, either to repair or to replace any component... - Page 17 Luxtec Corporation declares that this product meets the Essential Requirements specified in Annex 1 of the Medical Device Directive (MDD). 99 Hartwell Street • West Boylston, MA 01583• USA Telephone: (800) 325-8966 (USA only) or +1-508-835-9700 Facsimile: +1-508-835-9976 E-mail address: info@luxtec.com...
