Summary of Contents for ACS AUTOMOTIVE DIAGNOSTIC TOOL
- Page 1 AUTOMOTIVE DIAGNOSTIC TOOL Instruction Manual...
-
Page 2: Introduction
Introduction The Automotive Diagnostic Tool can be used during the installation of an alcohol interlock to determine the function (power, ignition, start) of the wires in the vehicle main harness, measure tach signal or locate the best position for the Digital Tach Sensor (DTS), or simulate a tach signal to perform tests when an alcohol interlock registers a “Tach Fault”. -
Page 3: Table Of Contents
Automotive Diagnostic Tool Contents Introduction ..............02 Contents................03 Parts included ..............04 Handset function ...............05 Basic function ...............05 Display ................06 Functions ..............06 Other indicators ............07 Batteries ..............07 Testing wire voltage............08 Determining wire function ..........09 Locating tach signal on alternator ........10 Measuring tach signal ............11 Simulating tach signal ............ -
Page 4: Parts Included
Parts included Handset Red receptor USB port Black receptor Display screen FUNCTION button ON/OFF button 2 x Multimeter probes 2 x Test leads (red and black) (red and black) Black alligator grounding clamp Tach sensor Parts included... -
Page 5: Handset Function
Automotive Diagnostic Tool Handset function Basic function • To turn on handset, press and hold ON/OFF (left) button for three seconds • When on, pressing the ON/OFF button without hold will turn a back light on/off • Use the FUNCTION (right) button to scroll to the desired function •... -
Page 6: Display
Handset function Display Functions Functions are shown on the display with text and comma indicators that line up with function names on the label: VOLTAGE Indicated by VOLT X.XX and comma position 1 LOCATE TACH Indicated by TACH XXX and comma position 2 MEASURE TACH Indicated by RPM XXXX and comma position 3... -
Page 7: Other Indicators
Automotive Diagnostic Tool SIMULATE TACH Indicated by OUT 0900 or OUT 2250 and comma position 4 Other indicators Indicates RS232 communication is active on USB connector Indicates low battery Batteries The device takes two AA, 1.5V alkaline batteries. Handset function... -
Page 8: Testing Wire Voltage
Testing wire volta CAUTION! Before performing any test, it is Automotive Diagnostic Tool to a shock. To ground the diagnostic grounding clamp or black multim into black receptor on handset, ground source or the probe to g Turn on handset and press F VOLTAGE function, indicated and comma position 1. -
Page 9: Determining Wire Function
Automotive Diagnostic Tool Determining wire function In the vehicle main wire harness, individual wire function may be determined based on the following readings: The POWER wire (continuous un- switched source wire) will register at approximately +12 or +24 volts in any... -
Page 10: Locating Tach Signal On Alternator
Locating tach signal on alternator If a tach signal wire cannot be found or signal is weak, it may be necessary to determine the best location to fasten the permanent Digital Tach Sensor (DTS) on the alternator: Turn on handset and press FUNCTION button until reaching the LOCATE TACH function, indicated on display by “TACH 000”... -
Page 11: Measuring Tach Signal
Automotive Diagnostic Tool Measuring tach signal To determine if there is a good signal from the tach signal wire, perform the following steps: Turn on handset and press FUNCTION button until reaching MEASURE TACH function, indicated on display by “RPM 000” and comma in position 3. -
Page 12: Simulating Tach Signal
Simulating tach signal In the case that the alcohol interlock registers a “Tach Fault”, this function is used to determine if there is a problem with the tach signal (either in the wiring or digital tach signal) or the ECU itself. If a tach fault occurs, cut the tach signal wire and connect red multimeter probe to wire leading to ECU. -
Page 13: Troubleshooting
Automotive Diagnostic Tool Troubleshooting If the Automotive Diagnostic Tool is malfunctioning, send back to ACS for maintenance or replacement. Contact information For assistance, contact your jurisdictional program manager. Alcohol Countermeasure Systems Corp 60 International Boulevard Toronto, Ontario M9W 6J2 CANADA... -
Page 14: Replacement Parts
Replacement parts To order a new device or replacement parts, contact ACS and refer to the appropriate part number(s) below: Part name Part number Handset 15- 000408 Multimeter probe (red) 22- 000827 Multimeter probe (black) 22- 000826 Test lead (red) -
Page 15: Notes
Automotive Diagnostic Tool Notes Notes... - Page 16 ALCOHOL COUNTERMEASURE SYSTEMS, ACS and The Molly are trademarks of Alcohol Countermeasure Systems (International) Inc. and are used under license. Alcohol Countermeasure Systems is trading style of Alcohol Countermeasure Systems Corp. acs-corp.com IRM-EN-60-000196-A Copyright © 2012...
