The Cyber-Tech, Inc. JS-500-HD Series
is a high quality, reliable industrial
joystick. The rugged design yields
flawless operations day after day in
INDUSTRIAL CONTROL SOLUTIONS
harsh, demanding environments. The
®
®
Handy-Grips
Ergo-Grips
Joystick Bases
JS-500-HD Series joystick is equipped
P .O Box 23801
Portland, Or 97281-3801
with a 13lb spring-return-to-center
7943 SW Cirrus Dr.
assembly, long life 16 amp switches,
Beaverton, Or 97008
adjustable cams and nylon bushings
1-800-621-8754
at critical wear points. These features
J o y s t i c k s
combine to provide ease of operation
mechanical
and minimal downtime.
Custom options on the JS-500-HD
are also available. The addition of
proportional interfacing is straight-
forward and adjustment to your desired
output is as simple as flipping the switch
on the proportional control card.
Cyber-Tech, Inc. engineered this unit to
adapt to most handles and equipment
on the market and is backed by our
exceptional warranty, customer service
and technical support.
With products field tested for over 20
years you can be confident that we
have a product to fit your particular
JS - 500 - HD series
application. If you have any questions
or would like technical information on
the JS-500-HD please give us a call.
www.cyber-tech.net
Advertisement
Table of Contents
Summary of Contents for Cyber-Tech JS-500-HD Series
- Page 1 The Cyber-Tech, Inc. JS-500-HD Series is a high quality, reliable industrial joystick. The rugged design yields flawless operations day after day in INDUSTRIAL CONTROL SOLUTIONS harsh, demanding environments. The ® ® Handy-Grips Ergo-Grips Joystick Bases JS-500-HD Series joystick is equipped P .O Box 23801...
-
Page 2: Mechanical Specifications
J o y s t i c k s mechanical JS-500-HD series Mechanical Specifications Maximum handle travel: 16 +/- 2 degrees (On X/Y Axis) 18 +/- 2 degrees (On 45° Axis) JS - 2050 - HD series Force to switch contact from mounting adaptor: Force to switch contact from control grip: 10 lbs (160.00 oz) @ contact (On X/Y Axis) -
Page 3: General Dimensions
If you have a special installation Cyber-Tech, Inc. recommends that and Ergo-Grips will fit through the problem or concern, please call the technical staff at Cyber-Tech, Inc. for edges of all openings be deburred specified cutout hole except the and cleaned to ensure proper seal. -
Page 4: Ordering Information
1. LABOR: For a period of (180) days from date of purchase, if this product is determined to be defective, Cyber-Tech, Inc. will repair or replace the product, at its option, at no charge. After the Warranty Period you must pay for all labor charges.
