Summary of Contents for SLOC SPR-203
- Page 1 SPR-203 Inbetriebnahme INITIAL SETUP SPR-203 Version: 1.0 06/10/2020 © SLOC GmbH 2020 www.sloc.one Page 1 of 24...
-
Page 2: Table Of Contents
Transport mode ........................5 SLOC Configuration ....................6 Check data transmission ..................13 5.1. Download and install demo app ..................13 5.2. Reading SPR-203 data with demo app ................13 Mounting ......................16 6.1. SPR-203 ..........................16 6.2. SPR-203 Reference ......................17 Read out the data via BLE ................... 18 7.1. -
Page 3: Introduction
In this documentation you will learn how to put your product into operation and evaluate the data. We at SLOC are always trying to make our products as simple and intuitive as possible. However, should you encounter any problems, we are at your disposal. -
Page 4: Sloc Device Management (Sdm)
2.1. First login to the SDM portal If you purchase your products through SLOC, you have been sent a registration email to register in the SDM portal and assign a password. If you purchase the product via an external platform, please use the e-mail address with which the order was placed. -
Page 5: Sloc Activating/Deactivating
To do this, the magnet ( ) must be placed on that side of the included in the scope of delivery SLOC for at least 2s and, if necessary, moved back and forth on which the magnet symbol is shown ( see illustration 3.2. -
Page 6: Sloc Configuration
Chapter 4 NOTE: The BLE of the SLOC is deactivated after 60 seconds. If a SLOC is no longer accessible while using the app, wake it up again with the magnet (see chapter 2.1.). Registration in the SDM App:... - Page 7 SPR-203 Initial Setup 1. SETTINGS: - Server must be https://sdm.sloc.one - Other settings as in the picture on the left - API Key, Organization UUID, Organization and Privileges vary depending on the app token used 2. Scan environment for SLOCs:...
- Page 8 Selection of the SLOCs using the MAC address (see sticker on SLOC) Note: The BLE of the SLOC is deactivated after 60 seconds. If the app cannot establish a connection, the SLOC must be reactivated with the magnet. 4. HOMEPAGE - SLOC ...
- Page 9 SPR-203 Initial Setup 5. SETUP 1/2: Product: SPR-203 (cannot be changed) Name: Can be changed as desired Location: Optionally a location can be entered Click next to LOCATION Note: Steps 6-7 are only displayed when clicking next to LOCATION and can be skipped if no location is desired.
- Page 10 SPR-203 Initial Setup 7. LOCATION 2/2: Check the address for "Current Location via GPS" if the address is not correct, change it manually Click on SAVE 8. SETUP 1/2 Click on SAVE © SLOC GmbH 2020 www.sloc.one...
- Page 11 Enabled: Load state is measured and determined in intervals Max. Distance for status “loaded” Distance (in mm) from SLOC at which the condition is considered loaded Check Interval for load state: Time interval (in sec) in which the load state is...
- Page 12 SPR-203 Initial Setup 16. CONFIGURATION COMPLETED Before assembly ( ), the data see Chapter 5 transmission should be checked ( Chapter 4 © SLOC GmbH 2020 www.sloc.one Page 12 of 24...
-
Page 13: Check Data Transmission
5.1. Download and install demo app The app can be downloaded to a smartphone/tablet via the SLOC Support Center (https://support.sloc.one) on a smartphone/tablet by clicking on your product (SPR-203) and then downloading the APK file. This can be done directly from the smartphone/tablet or via a PC and USB cable. - Page 14 SPR-203 Initial Setup 2. Select SPR-203 MAC Click on MAC address of SPR-203 (queries the advertising of this sloc) 3. Close connection window Click on SLOC symbol © SLOC GmbH 2020 www.sloc.one Page 14 of 24...
- Page 15 4. Verify data Here now all data are shown, which are advertised. (Lifting height is only displayed if SPR-203 is within reach and correctly set in setup) (To calibrate lifting height at current height to 0mm, hold a magnet at the side of the magnet symbol of the Sloc for about 3 seconds) ©...
-
Page 16: Mounting
• 2 SLOC Easy Mount brackets are included in delivery. • With these brackets an easy installation is guaranteed. • The SLOC can be quickly removed thanks to the clip holder and e.g. batteries can be changed. © SLOC GmbH 2020 www.sloc.one... -
Page 17: Spr-203 Reference
The associated SPR-203 Reference should be mounted as close as possible to and at the same height as the SPR-203 on 0mm. For this purpose cable ties or the SLOC Easy Mount can be used again. The SPR-203 Reference should be mounted at a non-moving place (no stroke). -
Page 18: Read Out The Data Via Ble
SPR-203 Initial Setup 7. Read out the data via BLE In this chapter the structure of the advertisement package, which the SLOC sends via BLE, is described in detail. 7.1. Package structure Byte Content 0 bis 6 HEADER 7 bis 12... -
Page 19: Type
SPR-203 Initial Setup 7.3. Type The type depends on the SLOC product used. The SPR-203 described in this document uses type 0x05. Datatype: uint8 Example – Type 0x05: 7.4. Loading status If an object is detected within 30cm, the status changes to Load. -
Page 20: Lifting Height
SPR-203 Initial Setup 7.6. Lifting height The lifting height is transmitted in millimeters (mm). If the SLOC does not support lift height measurement, 0x0000 is always transmitted. If the reference SLOC cannot be reached, 0x8000 is transmitted. Datatype: int16 Example – 0mm (0x0000): 7.7. -
Page 21: Battery Status In Percent
7.10. Current position MAC address of a recognized SBC-203. If several SLOC - Beacons are recognized at the same time, the one with the largest signal strength is selected. If no SLOC beacon is detected, 00:00:00:00:00:00 is advertised. Datatype: 6 Byte Example –... -
Page 22: Legal Regulations
8. Legal regulations 8.1. Declaration of conformity Any changes or modifications not expressly approved by SLOC could void the user's authority to operate this equipment. There are no serviceable parts included. EC – Konformitätserklärung / EC – Declaration of Conformity SLOC GmbH Waltendorfer Gürtel 2, 8010 Graz, Austria, +43 316 395 396, office@sloc.one... -
Page 23: Copyright
Rights - including those of translation, reprint, broadcast, photomechanical or similar reproduction and storage or processing in computer systems, in whole or in part - are reserved. No reproduction may occur without the express written consent from SLOC GmbH. 8.3. - Page 24 SPR-203 Initial Setup SLOC GmbH Waltendorfer Gürtel 2 8010 Graz Österreich / Austria +43 316 395 396 support@sloc.one © SLOC GmbH 2020 www.sloc.one Page 24 of 24...
