Summary of Contents for HARD Stockton N1035P
- Page 1 Revised 2020.1 6.12.2020 The nations #1 manufacturer of hospital cribs HOME CARE MANUAL STOCKTON BED CAREGIVER INFORMATION & ASSEMBLY INSTRUCTIONS MODELS N1035P & N2085P...
- Page 2 The weight limit of any of the cribs or beds made by Hard Manufacturing is 150lbs. If the weight limit of the bed is exceeded, the additional weight could cause damage to the bed components that could lead to expensive repairs and/or make the bed unsafe for daily use for the patient as a result.
- Page 3 SIDE RAIL OPERATION & SAFETY Bed rails and raised and lowered with fi ngertip release mechanisms shown below. To raise or lower the side rail, using both hands lift the rail slightly then squeeze both fi ngertip release mechanisms to disengage the trigger mechanism and adjust the rail to the desired position.
- Page 4 CRANK HANDLE USAGE All of the Stockton or Monroe Beds for home care use made by Hard Manufacturing have head and knee/foot elevation, as well as the Hi-Lo feature allowing the entire mattress platform to move up and down. These functions on our manual beds are accomplished with 3 crank handles.
- Page 5 CRANK HANDLE USAGE CONTINUED The Foot Crank Handle The foot crank handle is located on the far right of the foot end of your bed. The foot crank handle when not in use should be tucked in. This helps to avoid damage from it hitting or getting caught on other objects when the bed is being moved.
- Page 7 Instructions for the Assembly of N1035/N2085 Stockton Bed (Manual) 1. Unpack the bed, head board, foot board, and side frames out of the box. 2. Attach the 4 supplemental mounting plates to the top frame as shown in the pictures below. 3.
- Page 8 6. Remove the 4 supplemental mounting plates from the 4 corners of the bed. 7. Remove the screws for the foot and head attachment. There a total of 4 screws. 8. Attach the head and foot ends to the spring frame. Tap the corner lock on the end with a mallet and wood block until they are firmly seated in the corner lock on the spring frame.
- Page 9 10. a. Remove the two bolts from pull tube. b. Connect the Hi-Lo pull tube with pivot assembly using the two bolts removed in a. c. Cut off the plastic zip ties which were connected to Hi-Lo pull tube for the purpose of shipping Remove Bolts Attach the bolts again after connecting to pivot assembly 11.
- Page 10 13. Pick up side frames and place the slide rod extensions into the lower crib eyes as shown below. Pick up side frame Place slide rod stem into lower crib eye hole Completion of attachment 14. a. Push down on each end of the side frame to engage the square bushing into the upper crib eye. b.
- Page 11 Revised 2020.1 3.25.2020 The nations #1 manufacturer of hospital cribs INSTALLATION & USAGE INSTRUCTIONS FOR HEAVY DUTY BUMPER PADS FOR STOCKTON OR MONROE YOUTH BEDS *1035BP fi ts a 36” x 72” Bed *2085BP fi ts a 36” x 83” Bed...
- Page 12 INSTALLATION OF HEAVY DUTY BUMPER PADS You should have 4 pads. 2 are square shaped and identical. They are used on the headboard and footboard. The other 2 pads are long and rectangular shaped for the side rails and are “side specifi...
- Page 13 INSTALLATION OF HEAVY DUTY BUMPER PADS- CONT. INSTALLING PADS ON THE SIDERAILS With the side rail in highest position and locked in place, place one of the pads along the inside face of the side rail with the elastic straps and white strings towards the fl oor. **IMPORTANT** - The triangle shaped area on the pad (the area that doesn’t have any padding) must go towards the head end of the bed.
- Page 14 USE OF THE RAILS WITH THE BUMPER PADS LOWERING THE SIDERAILS WITH THE BUMPER PADS ON **CAUTION** This procedure must be followed when lowering the siderail otherwise the pads or Velcro may be damaged. DO NOT TRY TO LOWER THE SIDERAIL WITHOUT FOLLOWING THESE STEPS: Lift the 3 vinyl fl...
- Page 15 The nations #1 manufacturer of hospital cribs CAUTION SHEET All bolts and other fasteners must be securely tightened and maintained when crib is put in service. Before each usage or assembly, inspect crib for damaged hardware, loose joints, missing parts or sharp edges.
- Page 16 30 days of reporting the issue. Return Policy Acceptance of returns on all new and unused equipment and parts is at the discretion of HARD Manufacturing. The purchaser will be responsible for a restocking fee and the freight costs associated with returning the equipment or item.
