Green Panther GP-4019BP-P User Manual

Brush cutter back pack
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GP-4019BP-P
BRUSH CUTTER BACK PACK
USER MANUAL
Note: Please read the following instructions before use. This book contains important information on SAFETY, ASSEMBLY, OPERATION
& DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-4019BP-P and is the answer not in the manual?

Questions and answers

Related Manuals for Green Panther GP-4019BP-P

Summary of Contents for Green Panther GP-4019BP-P

  • Page 1 GP-4019BP-P BRUSH CUTTER BACK PACK USER MANUAL Note: Please read the following instructions before use. This book contains important information on SAFETY, ASSEMBLY, OPERATION & DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE...

  • Page 2: Before Operation

    GENERAL INSTRUCTIONS FOR SAFETY OPERATION All our company products are delivered with an Owner’s manual. Please read it carefully to get acquainted with the operation of your unit. For further details, consult your dealer. Before Operation Protect head (eyes and ears), feet and hands with safety hat, ear cover, goggles, safety shoes and protective clothes.
  • Page 3 The operator must obey the local regulations of cutting area. Never carry the unit with the engine running. For safety, the unit should not run in full throttle without any load. Don’t run the unit without a muffier. During a heavy work, be always with a partner. When making a repair or adjustment, the unit must be stopped and the fuel completely drained.
  • Page 4 3.Throttle cable and stop cord Put throttle cable and stop cord through cable passage of shaft grip,then connect each terminal with each proper position respcctively.(Fig.3) Finally,clamp those connected throttle cable and stop cord together to flexblc shaft with two wire clamp bands provided.(Fig.4) 4.

  • Page 5: Operating Procedures

    6. Blade I) When installing a steel blade, fit the blade as shown in the fig. 7 2) When installing or removing a blade, lock cutter holder with lock handle to tighten or to untighten as shown in Fig. 8 NOTE: As the blade fixing bolt is left threaded, tum it counter-clockwise and take a special care not to hurt your fingers by the blade.
  • Page 6 2. Starting I) Open the fuel cock. (Fig. I 0) 2) Move the throttle lever to start position or about I /4 full throttle, in case of metal lever. (Fig. II) NOTE: Staring with full throttle causes sudden high revolution of Blade, which is dangerous, so please avoid it.
  • Page 7 4. Cutting I) The blade turns counterclockwise, therefore be advised to operate the cutter from right to leftward for efficient cutting. 2) When working on a slope,the blade should allow the contour from top to bottom, with the operator looking down to the left. 3) Keep the onlookers out of the working area at least 7~8m (30ft).

  • Page 8: Maintenance

    MAINTENANCE 3. I. Periodical check l) Cleaning l - l Clean the cleaner element. (Fig. 17) I - 2 Scrape off the carbon from the spark plug gap (standard gap is 0.6mm or 0. 023in. ). (Fig. 18) 1 - 3 Clean the cylinder exhaust port and muffler.

  • Page 9: Specifications

    SPECIFICATIONS Model 4019BP-P Engine Type Brush cutter Dispiacement 42.7cc Max.Output 1.25kw 6500rmin Carbureor Diaphragm type Lgnitiop system rc [gnition Lgnition plug BM-A Fuel Mixed fuel of Gasoline and 2 cycle oil at 25: I Fuel tank capacity 1.2L Body Drive Flexible shaft, Drive shaft,Pinion and Gear Rotational direction of the cutter...
  • Page 10 PARTS LIST FOR OUR COMPANY BACK-PACK BRUSH CUTTER MODEL FOREWORD l.The parts list contains listing for all the spare parts available for the OUR COMPA”--Y BACK. PACK BRUSH CUTTER MODEL and should always be used \\.hen ordering genuine OUR COMPANY parts. 2.
  • Page 11 All dimensions arc in milimeters except for special fasteners, pulleys, wheels and steel balls. PARTS NAME EXAMPLE INTERPRETATION SCREW or BOLT 5X 13 5mm diameter, 13mm length WASHER for 6mm fastner TUBE 6X 150 6mm inside diameter, 150mm lengh 6X 12 6mm diameter, 12mm length 12mm inside diameter, 22mm outside OlLSEAL...
  • Page 12 PIPE ASSEMBLY DIAGRAM & PART LIST OF GP 4019BP-P...
  • Page 13 PART NO. DESCRIPTION 4019BPP-T1 Pipe Assembly 4019BPP-T2 Shock pad 4019BPP-T3 Bearing 4019BPP-T4 Shaft 4019BPP-T5 Connector 4019BPP-T6 Fastener 4019BPP-T7 Screw 4019BPP-T8 Bolt 4019BPP-T9 Gear case assembly 4019BPP-T10 Gear case 4019BPP-T11 Bearing 4019BPP-T12 Bearing 4019BPP-T13 Circlip 4019BPP-T14 Oil seal 4019BPP-T15 Gear shaft 4019BPP-T16 Gear 4019BPP-T17...
  • Page 14 PART NO. DESCRIPTION 4019BPP-T28 Bolt 4019BPP-T29 4019BPP-T30 4019BPP-T31 Flexible shaft assembly 4019BPP-T32 Shaft 4019BPP-T33 Flexible shaft 4019BPP-T34 O-rings 4019BPP-T35 Frame carrier 4019BPP-T36 Back cushion 4019BPP-T37 4019BPP-T38 Ring 4019BPP-T39 Screw 4019BPP-T40 Support frame 4019BPP-T41 Connector 4019BPP-T42 4019BPP-T43 bolt 4019BPP-T44 4019BPP-T45 On/Off line 4019BPP-T46 4019BPP-T47 Switch...
  • Page 15 PART NO. DESCRIPTION 4019BPP-T58 Filter assembly 4019BPP-T60 Hoop 4019BPP-T61 Oil pipe 4019BPP-T62 Spring 4019BPP-T63 Circlip 4019BPP-T64 4019BPP-T65 Belt 4019BPP-T66 Bolt 4019BPP-T67 Cover 4019BPP-T68 Bolt 4019BPP-T69 4019BPP-T70 Guard assembly 4019BPP-T71 Guard 4019BPP-T72 Fix frame 4019BPP-T73 Bolt 4019BPP-T74 Washer 4019BPP-T75 Blade 4019BPP-T76 4019BPP-T77 Switch assembly 4019BPP-T78...
  • Page 16 ENGINE SPARE PARTS DIAGRAM & PART LIST OF GP 4019BP-P...
  • Page 17 PART NO. DESCRIPTION PART NO. DESCRIPTION 4019BPP-E1 SCREW 4019BPP-E32 RUBBER GASKET 4019BPP-E2 TANK SUPPORT 4019BPP-E33 TANK SUPPORT 4019BPP-E3 STARTER 4019BPP-E34 SCREW 4019BPP-E4 AL.GASKET 4019BPP-E35 CYLINDER COVER 4019BPP-E5 PULLEY 4019BPP-E36 SPARK PLUG 4019BPP-E6 LEFT CASE 4019BPP-E37 CYLINDER COVER 4019BPP-E7 CASE GASKET 4019BPP-E38 BAFFLE 4019BPP-E8 OIL SEALING...

  • Page 18: Inspection And Maintenance

    INSPECTION & MAINTENANCE For safety use, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle,and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop.
  • Page 19 1st Free Service Coupon ISO 9001-2015 CERTIFIED COMPANY FREE SERVICE COUPON (30 Days / 30 hrs (Which ever is earlier) Model Serial Number GP-4019BP-P BRUSH CUTTER PDI Date Service No. Purchase bill no. Date Dealer’s Office Seal & Signature Customer Signature.........
  • Page 20 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
  • Page 21 Warranty Card CUSTOMER COPY Purchaser’s Name & Address Date of Delivery Dealer’s Office Seal Product Name GP-4019BP-P BRUSH CUTTER Product Serial No. Dealer Sign Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
  • Page 22 Small Maintenance. Big Savings. Small Maintenance. Big Savings. Small Maintenance. Big Savings.
  • Page 23 Do’s Don’ts • Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. • It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines.
  • Page 24 GP-4019BP-P BRUSH CUTTER BACK PACK IMPORTERS & DISTRIBUTORS RATNAGIRI IMPEX PVT LTD Annapurna House, #1/1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore-560 026 Customer Care: 1800-425-3036 email: info@ratnagiriimpex.com www.ratnagiriimpex.com AN ISO 9001:2015 CERTIFIED COMPANY...
