Summary of Contents for Heat Saving Systems AC400 Series
- Page 1 Owner Manual Air Curtain AC400-39E8...
- Page 2 Copyright and Trademarks All the information and drawings in this manual are the property of Heat Saving Systems/Teplomash and may not be used (other than for the actual installation and operation of the unit), photocopied, duplicated, translated and/or sent to a third party without Heat Saving Systems/Teplomash’s prior permission.
-
Page 3: Table Of Contents
Table of contents Chapter 1. General information....................4 1.1. Introduction........................4 Safety Information ...…….……….…………..…………………………...…………..4 1.3. Design and Function ....................... 5 Included with Delivery…………… ……………………………………………………...….6 Chapter 2. Operation ........................7 2.1. Specifications ........................7 2.2. Operating conditions ....................... 8 2.3. -
Page 4: Chapter 1. General Information
Chapter 1. General Information 1.1 Introduction IMPORTANT! Please read this manual and all labels attached to the unit carefully before attempting to install, operate or service Air Curtain! Check unit data plate for electrical specifications to verify compatible power requirements. Keep this manual available at all times for operations and service personnel as well as a record of operating conditions and maintenance schedules in case of future warranty questions. -
Page 5: Design And Function
1.3 Design and Function Air Curtains are most often used as energy saving devices used in conjunction with the heating and ventilation system of a building. Air Curtains can be installed horizontally or vertically over an opening, typically where a temperature difference between interior and exterior is to be maintained. Though used primarily in building applications, air curtains are also used extensively outside of freezers and walk in coolers, for the same reasons, and in addition, can be used to prevent insects from entering a building. -
Page 6: Included With Delivery
1.4 Included with Delivery 1.4.1. Air Curtain. 1.4.2. Hardware kit. 1.4.3. Installation and Maintenance Instructions. 1.4.4. Owner Manual. 1.4.5. Control panel. 1.4.6. Remote control. -
Page 7: Chapter 2. Operation
Chapter 2. Operation 2.1 Specifications Series AC400 AC400-39E8 Model Power supply V/PH/Hz 208/3/60 kBTU/h 27.3 Heat output 1590 Air volume m3/h 2700 16,4 Max. door height °F 14,4 Temperature rise °C Length 1000 43,7x13,8x13,4 Overall dimensions (LxWxH) 1110x 350x340 56,22 Weight 25,5 Max unit current*... -
Page 8: Operating Conditions
2.2 Operating Conditions -4 to +104°F (-20 to +40°C) Room temperature not to exceed 68°F (+20°C), 80% Relative humidity maximum Interior air quality: Dust and other airborne contaminants must not exceed 10mg/m3 IMPORTANT! Do not operate Air Curtains where air borne acids, alkalis, adhesives, flammable substances, fibrous (oleoresins, industrial fiber etc.) or any other corrosive contaminants are in the air, and/or substances that are damaging to carbon steel, or can clog impeller or air intakes. - Page 9 Under normal operating conditions the display shows room temperature (from 41°F (+5°С) to 95°F (+35°С)). If room temperature is higher than 95°F (+35°С), “HI” symbol appears. The symbol appears on display if the air curtain is operated in 50% heating mode, the symbols and appear when 100 % heating mode is turned on.
-
Page 10: Chapter 3. Maintenance
Chapter 3. Maintenance 3.1 Maintenance instructions IMPORTANT! Prior to cleaning or inspection make sure the power has been turned off at the circuit breaker panel and that the heating element of Air Curtain is cool. To ensure reliable and efficient operation of Air Curtains regular maintenance is required. All maintenance must be performed by qualified personnel only. -
Page 11: Chapter 4.Warranty Statement
Chapter 4.Warranty statement The guarantee is only valid if the Heat Saving Systems units are used in the manner intended by the manufacturer and in accordance with the Installation and Maintenance Instructions. Heat Saving Systems /Teplomash warranties the Air Curtain for 2 (two) years after delivery. -
Page 12: Notes
Notes ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________... - Page 13 Heat Saving Systems Air Curtains are designed and manufactured in compliance with UL STD 2021, NSF STD 37. Air Curtains are certified to CAN/CSA C22.2 STD No. 46. Air Curtain _________________________________________ Factory number № ___________________________________ Date of manufacturing ____________________ L.S. ______________...
