Summary of Contents for Sensoteq Chi
- Page 1 C h i User Guide Sensor & App Quick Start Guide...
-
Page 2: Table Of Contents
Contents - Introduction - Item Checklist Measure - Quick Start Instructions - Samsung Galaxy Tab A Tablet - Welcome to your Chi Service Tool of Confidence - Sensoteq Chi Android App - Sensoteq Analytix - Troubleshooting - Service Tool Support... -
Page 3: Introduction
Sensoteq Chi is an industry leading system that monitors vibration and rotating patterns. The Chi app can connect with up to four Chi sensors and presents the data in an easy to understand view, helping engineers and technicians to get an in- depth look at the energy and rotating profile for their machinery. -
Page 4: Item Checklist
Item Checklist Thank you for purchasing a Sensoteq Product. Please ensure you have all the items listed before proceeding with installation. If anything is missing, contact your dealer. Sensoteq Chi Wireless Micro USB Charging Samsung Galaxy Tab A Samsung Galaxy Tab A*... -
Page 5: Quick Start Instructions
Open the app Quick Start Refer to page 11 for download instructions, or search 'Sensoteq Instructions Chi' in the Google Play Store Log In Enter your Sensoteq credentials. Alternatively, you can opt to remain logged out but you will be... - Page 6 Quick Start Begin session to start collecting data in 10 second cycles. Instructions Compare results from multiple sensors. Pause or stop when you are finished Save Saved data is uploaded to the Sensoteq Analytix platform for remote diagnosis and reporting capabilities...
-
Page 7: Samsung Galaxy Tab A Tablet
If you purchased a tablet with your service tool kit, it should be ready to use, however a charging cable is provided should it need charged up. You will need to download the Sensoteq Chi app from the Google Play store. See page 11 for assistance. -
Page 8: Welcome To Your Chi Service Tool
Welcome to your Chi Service Tool Let's Get Started. Refer to 'Troubleshooting' or 'Chi Service Tool Support' pages at any time if you are having issues... - Page 9 You can check the battery charge level This is your wireless sensor: in the application on your tablet. When reading data from the sensor the charge percentage is shown at the bottom of the screen. The sensor base is magnetic. Affix it to any ferrous surface to detect triaxial vibrations and surface temperature.
- Page 10 Alignment The X and Y on the front of your sensor indicate the directions of the axial measurements the sensor is making. The Z axis of measurement is perpendicular to these two so is directed through the base and into the attachment surface. This sensor is rated to IP64 –...
-
Page 11: Sensoteq Chi Android App
Sensoteq Chi Android App The Sensoteq Chi app is where you can see what measurements your sensor is making. Your sensors communicate with the application which is pre-installed on the tablet provided. If you did not purchase a Sensoteq prepared tablet, you can scan the QR code below to download the app. - Page 12 Modes Measurements Vibration Analysis Measure a vibration waveform and Quick Measurement spectrum to show the energy levels Show data on the device only Stroke Analysis Online Defined Measurement Analyse the stroke pattern of your machine at up to four points at once Sample data and send to our Analytix platform for further analysis Hammer Test...
-
Page 13: Sensoteq Analytix
Sensoteq Analytix Your Chi app connects to the Sensoteq Analytix platform for more in-depth diagnosis. View historical or recent data sorted by machine name or measurement type in great detail, with advanced features and tools to give you even greater insight into the behaviour of your machines... -
Page 14: Troubleshooting
Troubleshooting If one or more sensors are not displayed by the app: Ensure your Updates may Make sure the sensor is Ensure Bluetooth have been sensor is within charged. A full and location installed on your range. Typical Contact Us charge services are app. -
Page 15: Service Tool Support
Service Tool Support Should you need any further information on how to operate your sensor, or for any other enquiries, please contact your dealer. Or use the information below Website: www.sensoteq.co.uk Email: support@sensoteq.co.uk Phone: +44 (0) 28 9620 8453... -
Page 16: Product Specifications
Product Specifications... -
Page 17: Contact Us
Contact How to reach us Mailing Address Unit 23, Ormeau Business Park, Cromac Avenue, Belfast BT7 2JA Phone Number +44 (0) 28 9620 8453 Email Address contact@sensoteq.co.uk... - Page 18 C h i Sensor & App Quick Start Guide...
