Sports Construction Progressive 503285 Installation Instructions Manual

Ceiling suspended basketball backstops
Hide thumbs

Advertisement

Quick Links

Download this manual
Ceiling Suspended Basketball Backstops
Copyright ©2014 Draper Inc.
Form PSCG_Ceiling_Inst14
Installation Instructions
765-987-7999
866-637-5611
411 S. Pearl St.
Spiceland IN 47385 USA
www. progressivescg.com
Printed in U.S.A.
If you encounter any difficulties installing or service
your backstop, call your dealer or Progressive Sports
Construction Group.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Progressive 503285 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sports Construction Progressive 503285

  • Page 1 Installation Instructions Ceiling Suspended Basketball Backstops 765-987-7999 866-637-5611 411 S. Pearl St. If you encounter any difficulties installing or service Spiceland IN 47385 USA your backstop, call your dealer or Progressive Sports www. progressivescg.com Construction Group. Copyright ©2014 Draper Inc. Form PSCG_Ceiling_Inst14 Printed in U.S.A.

  • Page 2: Installation Tips

    These instructions are meant as a guide only. They do not bind Progressive 10 All Progressive Gymnasium Equipment is supplied with Grade 5 hardware. Sports Construction Group in any way and do not imply any responsibility of Clamps are designed to be installed with the nuts and bolts “tight.”...

  • Page 3: Operation

    3 For warranty information, consult separate information sheet. lubricate the cable). If fraying is encountered, contact your dealer or 4 When calling Progressive Sports Construction Group with questions, Progressive Sports Construction Group for replacement. please have your order number, and, if possible, project drawing that Caution: Wear gloves when checking for frays! was provided with your backstop.

  • Page 4: Technical Information

    Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 4 of 37 Installation Instructions 503285/503280 Electric Backstop Winch by Progressive Sports Construction Group Technical Information Caution WEIGHT 68 LBS 1 As with any lifting device, the installation shall be made only by persons LENGTH 22.85 in...
  • Page 5 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 5 of 37 2 Attach one half of each pipe clamp to the base plate of the winch as 9 Re-position the winch clamps over the holes in the pipe and tighten the shown.
  • Page 6 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 6 of 37 WARNING: Cable winding on drum poses a severe pinch hazard! Use ex- treme caution while installing cable. Do not guide cable onto drum with hands; use proper tools. Do not damage or nick the cable in the process of winding it onto the drum.
  • Page 7 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 7 of 37 Winch Dimensions Cable Wind Direction 4" " 1'11" 1'6" + Ø4" 5¾" Manual Winch B) To mount to plate or other steel brackets. – Winch is attached to steel plate or brackets using "-16 x 1¼"...
  • Page 8 1 Use scaffolding or lift when attaching safety belt. the backstop mast as possible. The warning tear tab should be just below 2 Safety straps are recommended with all Progressive Sports Construction the white roller guides at the bottom of the Aut-O-Loc 2 when the back- stop is in the fully raised position.
  • Page 9 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 9 of 37 8 Tighten the top and middle ½" clamp nuts to a torque of 35 ft lbs. 5 Insert ½" x 3" bolt in top clamp hole and finger tighten into opposite half 9 Tighten the bottom "...
  • Page 10 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 10 of 37 Backboard padding. Please Note: This step can be completed at any point during installation; the most convenient time is during bank/goal assembly, prior to bank attach- ment. A0253/A0264 (glue-on:) 1 Hold each half of pad in place and mark pads for trimming around support structure (if required).
  • Page 11 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 11 of 37 Basketball Backstops by Progressive Sports Construction Group Inspection/Maintenance List Backstop Number: Backstop Model: Periodically inspect your backstops and all related equipment and attachments. Frequency of inspections depends on use of the equipment. Use guide- lines mentioned earlier in this manual when conducting inspections.
  • Page 12 Please Note: Be sure to apply the entire tube as described. If the lubricant is missing from your package, contact Progressive Sports Construction Group. 4 Thread nylon bolts into rear mainframe assembly until they just touch the slip tubes.

  • Page 13: Wiring Diagram

    Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 13 of 37 Attaching Bank Lift Angle & Backboard to Height Adjuster 7" " 1 Locate Bank Lift Angle from the appropriate backboard kit. These will be 1" 5" used to attach the Height Adjuster to the upper mounting holes of the ½"...
  • Page 14 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 14 of 37 Assembled Height Adjusters Rectangular Bank Rectangular Bank Manual Height Adjuster Motorized Height Adjuster Fan Bank Fan Bank Manual Height Adjuster Motorized Height Adjuster (877) 413-0957 (877) 413-0957...
  • Page 15 4" tubing attaching T-Frame. C019.069 1/2"-13 x 4" Dia. U-Bolt 5 Tighten with impact tool. All Progressive Sports Construction Group Zinc Plated Gymnasium Equipment is supplied with Grade 5 hardware. Clamps are Split "A" Clamp designed to be installed with the nuts and bolts “tight.” Progressive "-13 x 2...
  • Page 16 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 16 of 37 Beam Cap Screw,* Cap Screw*, or Joist " Washer, " Washer, Beam Spacer Spacer Flange Lock Nut (2) Flange Lock Nut (2) or Joist Flat (2) Flat (2) 6"...
  • Page 17 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 17 of 37 Spacer Beam 6" 6" Flat (2) or Joist Spacer Beam Flat (2) or Joist "-11 x 2" A0739 Cap Screw,* Cap Screw, " Washer, Lock Washer, A0740 Flange Lock Nut (4)
  • Page 18 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 18 of 37 Wood Wall Pad Installation " (typ.) Caution: Progressive Sports Construction Group is not responsible for wall strength. Do not install wall pads if wall is not strong enough to bear stress loads required for backstop.
  • Page 19 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 19 of 37 Upper Back Brace and Jackknife Hangers/ Attachments. "-13 x 2 " Please Note: Install Jackknife Hangers so that Cable Sheaves are in line 4" Tubing Cap Screw, Flange with the center of the Winch Cable Spool.
  • Page 20 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 20 of 37 0030 4" Tubing "-13 x 2 " Cap Screw, Flange Lock Nut (4) 0030 "-13 x " Cap Screw, 4" Tubing Flange Lock Nut (4) A0317 A0334 Jackknife Jackknife "-13 x 2...
  • Page 21 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 21 of 37 Backstop Attachment (To be completed AFTER Backstop Assembly—See assembly details beginning on page 22) Please Note: When marking roof structure or truss for Backstop Hanger placement, remember to account for offset distances (center to edge of clamp).
  • Page 22 Ceiling Suspended Backstop Assembly The following instructions are for all Progressive Sports Construction Group Ceiling-Suspended Backstops. Diagrams of completed backstops, including guidelines on clamp placement, can be found immediately following this section. Skip steps that do not pertain to your backstop model.
  • Page 23 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 23 of 37 2 Fasten Cable Pull Clamps, Safety Belt Clamp, and Lower Jackknife, Lower Back Brace, Kickbrace and/or A-Frame Hangers to Main Stem. Cable Thimble "-13 x 2 " Main...
  • Page 24 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 24 of 37 0032 4" x 2" Half Clamp 4" Main Safety Stem Belt "-13 x 3" Cap Screw, A0554 Safety Nylon Lock Nut Belt Clamp "-13 x 2 " Cap Screw, (2) "...
  • Page 25 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 25 of 37 3 Bolt Bank Hanger to Main Stem. Please Note: If installing a Height Adjuster, skip this step and see sepa- rate assembly instructions. Please Note: Bolt Bank Hanger so that Bank will be installed 2"-3" above playing height.

  • Page 26: Set Screw

    Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 26 of 37 Bank Goal Main Stem "-13 x 2 " Cap Screws (4), Flange Lock Nuts (4) Half Clamp Bolts, Washers (4), Nylon Lock Nuts (4). On some banks, studs Goal Brace may be pre-attached.
  • Page 27 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 27 of 37 8 Assemble and attach Jackknife. For all other folding models: 1 Plumb backstop and measure “hole center-to-hole center” distance between Upper Jackknife Hanger and Middle-of-Stem. (Please Note: This measure- ment should equal the hole center-to-hole center distance between the T-Frame Hanger and the Lower Jackknife Hanger.) Consult project drawings.
  • Page 28 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 28 of 37 Set Screw 2 Adjust Jackknife halves to proper length by loosening Set Screws, sliding inner tube in or out, and re-tightening screws and nuts. Connect two Jack- knife halves using ½"-13 x 2½" Cap Screw and Flange Lock Nut.
  • Page 29 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 29 of 37 Part No. O.A. LG. 11 For all folding models, complete cable run and attach 0132 2'5" NOTE: Certain Kick Brace sizes also Safety Belt (see diagrams of finished backstops).
  • Page 30 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 30 of 37 817-FFRB-BT (877) 413-0957 (877) 413-0957...
  • Page 31 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 31 of 37 849-FFB-BT (877) 413-0957 (877) 413-0957...
  • Page 32 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 32 of 37 850-OSB-BT (877) 413-0957 (877) 413-0957...
  • Page 33 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 33 of 37 823-BF-BT (877) 413-0957 (877) 413-0957...
  • Page 34 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 34 of 37 852-OSB-BT (877) 413-0957 (877) 413-0957...
  • Page 35 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 35 of 37 855-SF-BT* *Front Brace shown; also available with Rear Brace. (877) 413-0957 (877) 413-0957...
  • Page 36 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 36 of 37 826-NF-BT (877) 413-0957 (877) 413-0957...
  • Page 37 Basketball Backstops by Progressive Sports Construction Group—Ceiling Suspended Page 37 of 37 818-WB-BT (877) 413-0957 (877) 413-0957...
