AQIRYS Taurus User Manual

Manual de utilizare
1. Continutul cutiei si conectorii
2x Banda LED
1x Adaptor SATA pentru sursa
1x Adaptor 3 pini pentru placa de baza
2x Adaptor 3 pini pentru hub ARGB
2. Modalitati de conectare
A - Conectare la sursa de alimentare a calculatorului prin intermediul mufei SATA livrata in pachet. Cele doua benzi cu LED-uri se pot conecta in serie.
RO
B - Conectare direct la un ventilator prevazut cu mufa RGB 4 pini (de exemplu: ventilatoarele AQIRYS
se pot conecta in serie.
C - Conectare la controller-ul ARGB folosind adaptorul ARGB 3 pini livrat in pachet. (compatibilitate perfecta cu hub-ul PWM+ARGB preinstalat in
carcasele AQIRYS )
®
D - Conectare la placa de baza folosind adaptorul ARGB 3 pini livrat in pachet (se conecteaza la header-ul VDG 3-pini al placii de baza). Cele doua
benz cu LED-uri se pot conecta in serie.
A - Connect to the computer's power supply via the SATA connector supplied in the package. The two LED strips can be serial connected.
EN
B - Connect to a PC fan equipped with a 4-pin RGB plug (such as the AQIRYS
C - Connect to the ARGB controller using the 3-pin ARGB adapter supplied in the package. (full compatibility with the PWM + ARGB hub pre-installed in the
AQIRYS cases)
®
D - Connect to the motherboard using the 3-pin ARGB adapter supplied in the package (plugs into the 3-pin VDG header of the motherboard). The two LED
strips can be serial connected.
www.aqirys.com
TAURUS
/User manual
1. Box content and connectors
LED Strip x2
PSU SATA adapter with control x1
3-pin ARGB Motherboard adapter x1
Small 3-pin ARGB Hub adapter x2
2. How to connnect
® Cetus din seria 4P). Cele doua benzi cu LED-uri
® Cetus 4P series fans). The two LED strips can be serial connected.
1
Manual de utilizare
/User manual
A - Conectarea la sursa de alimentare
B - Conectarea directa la ventilator
www.aqirys.com
TAURUS
A - Connecting to the PSU
B - Connecting to the FAN
2
