MAXONIX Walli Instructions

Thank you for your purchase of this Maxonix
enjoyment from it too. Also, check out our website www.maxonix.com from time to time for new & improved product info.
Benefits of Product Registration:
Want special offers, product upgrades, exclusives, & sneak previews of new products? Then simply register with us, by emailing your contact info, date of
purchase & location of purchase to support@maxonix.com with "my product registration" in the subject line.

Parts

The Walli Drumstick Holder Kit includes:
1 brushed aluminum plate
•
4 clips - off-white/natural (light wood) color
•
4 clips - black color
•
1 plastic dry-wall (sheet-rock) anchor
•
1 screw, size #6 x 1" long
•
Installation & Use
Before installation (hanging on the wall) read through the sections below to find out about all the position options you may want to consider.
Stick Position Angle & Adjustment Options:
Sticks can be displayed horizontally, vertically, diagonally or anything in between. The position or orientation of sticks can be adjusted in 3 ways:
1. Plate rotation - To rotate the plate, simply loosen the wall mounting screw a little bit, then turn the plate to where you want it & finally re-
tighten the screw. The combination of the screw tension & gel bumpers on the back of the plate will hold the plate at the desired angle.
2. Clip rotation - by turning the clips in their holes - simply twist so that 2 clips align either horizontally or vertically
3. Combination of methods 1 & 2.
Movable title/label area
- The Walli in omni-directional. You can rotate it so the open area for a title/label is at the bottom, top or either side.

Tools:

Small phillips head screwdriver
•
Drill (electric or manual)
•
Drill Bit size: 3/16"
•
Note:
the anchor is provided for use on dry-wall/sheet-rock walls, but the anchor is not necessary for mounting into a wooden wall material/surface.
Steps
for dry-wall/sheet-rock walls:
1. drill 3/16" hole, at least 7/8" deep
2. insert plastic anchor into hole until only the collar/ring edge part is still visible just above the surface.
3. thread the screw through the center hole of the Walli's aluminum plate
4. align the Walli and screw with the center hole of the anchor
5. gently screw the screw into the anchor

Changing Clip Color

- The clips can be removed just by squeezing the arrow-head at the back of the plate & pressing out (or pulling from the
front at the same time). When putting in, just make sure to push the clips in far enough so the little prongs of the arrow-head spread out a little on the
back of the plate to hold the clip in place.
Custom Design & Labeling
Paper/Card Holding
- Walli gives you the option of attaching a label without glue, using the clip base "wings". To insert item, either:
(a) Rotate clips, or
(b) Gently tilt up
Longer explanation: To insert something, like paper with info about the sticks or a logo, under the clip base "wings", simply rotate the clip base
to the side, place your paper (etc.) into position so that part of it will be covered by the base when it's rotated back. Then rotate the clip base
back over the item to hold it. Or, just press very gently to tilt the clip upward (just enough to release some tension on the "wing" base) as you
slide the paper/card into the gap. This can also be done with a sticker without removing the backing that covers the sticker's adhesive surface.
Walli™ Drumstick Wall Holder Instructions
™
Walli
Customizable Drumstick Wall Display
Instructions
® product! This guide will get you ready to use it & give you the info to help you get the best long-term use &
(if any parts are missing please contact us)
Copyright © 2011-2012 by Maxonix®
(v1)
page 1 of 2
