L-B-P-1T-151872

Instruction Manual

Single Tier Locker

Table of Contents

Need help?

Do you have a question about the YU LOCKERS L-B-P-1T-151872 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Architectural Millwork YU LOCKERS L-B-P-1T-151872

Page 1 L-B-P-1T-151872 Instruction Manual Single Tier Locker...
Page 2 Parts included: ClicFit Female Insert ClicFit Male Insert Smove Holder Base Plate x 60 x 30 Robe Hook Mechanical Lock Smove Adapter Strike Plate Hinge #6 Flathead Screw #6 Roundhead Screw #6 Ovalhead Screw x 16 Top Shelf Left Side Panel Back Panel Right Side Panel Door...
Page 3 Connect male connector B into side slot of female connector Step 1: A. Insert clip consisting of connector A and connector B into the side edge of panel # making for a solid fit. Once clips are inserted into panel they cannot be removed. Continue these steps when inserting all 30 Male and Female combined clips.
Page 4 Base plate (D.) placed over pre-drilled holes on right side Step 4: panel (O.). Once Base plate (D) is aligned to pre drilled holes, secure base plates to panel (O) using 7 #6 flathead screws (J) using philips head screwdriver. Continue these steps to install all 4 base plates (D), excluding bottom base plate.
Page 5 Atatching the hinges (G) to the inside of door panel (P). Step 7: Starting from the top of the inside door panel (P) align hinges (G) to pre milled cup holes and pre drilled screw holes on inside of door panel (P). After aligning hinge (G) holes to and cup to Door Panel (P) insert two #6 flathead screws (J) into predrilled holes on door panel (P) and secure hardware with philips screwdriver.
Page 6 Lay back panel (N) on a flat surface with the inserts Step 10: facing upwards. Important note: When fastening compontents (Q) (R) and (S) to panel (N) be certain that the smooth unmachined edges are all in the same plain. Be sure that the edge Attach top (Q) to panel (N) by pushing the male inserts in top (Q) into the female inserts in panel (N).
Page 7 (this limited warranty is conditioned on the toilet partitions being properly installed, used and serviced). American Architectural Millwork 2825 Commerce Parkway, 34289 North Port, Florida (844)-307-9571 www.millworkusa.com...
Page 8 Fully Assembled Single Tier Yu Locker...
