Page 1 User Manual Installation Guide Industrial Ethernet Rack-mount Switch TNM4000-TP36FF4X16G24P Installation MRD TNM4000 Technical support Release 02 12/2020 http://en.mrdcom.net/...
Page 2 You can get the latest version of this manual on the Internet at MRDcom product site(http://en.mrdcom.net/). Printed in China Shanghai MRDcom Co., Ltd. No.123, Juli Road, Zhangjiang Hi-Tech Park, Shanghai, P.R.O.C Tel:86-21-58330762 Installation MRD TNM4000 Technical support Release 02 12/2020 http://en.mrdcom.net/...
Page 3: Table Of Contents
2.1.3 Connecting the power unit connections for supply voltage and alarm relay contact......................19 2.1.4 Grounding....................21 2.1.5 Installing the device................. 21 2.1.6 Startup procedure..................24 2.1.7 Connecting the data lines............... 25 Display elements....................28 Basic set-up......................30 Maintenance......................32 Disassembling the device...................33 Technical data....................34 Further Support.....................38 Installation MRD TNM4000 Release 02 12/2020...
Page 4: Safety Instructions
The cross-section of the protective conductor cable is the same size as or  bigger than the cross-section of the voltage supply cables. The connection cables used are permitted for the specified temperature  range. Installation MRD TNM4000 Release 02 12/2020...
Page 5 Note: The shielded ground wire of the twisted pairs lines is connected to the back panel as a conductor.  Beware of possible short circuits when connecting a cable section with conductive shield braiding. Installation MRD TNM4000 Release 02 12/2020...
Page 6 (approx. 5 cm) above the device, because heat is discharged via the housing of the device.  If you are operating the device in a 19" switch cabinet: install sliding/mounting rails for supporting the weight of the device. Installation MRD TNM4000 Release 02 12/2020...
Page 7 Extended: -40 °C ~ +70 °C List of standards: ISA 12.12.01, CSA C22.2 no. 213-M1987 Warning: Only disconnect devices when the system is voltage-free or is located in an area without inflammable concentrations or substances. Installation MRD TNM4000 Release 02 12/2020...
Page 8 This may limit their possible usage in the overall system. Note: LED or LASER components in compliance with IEC 60825-1 (2007): CLASS 1 LASER PRODUCT CLASS 1 LED PRODUCT Installation MRD TNM4000 Release 02 12/2020...
Page 9 Note: The assembly guidelines provided in these instructions must be strictly adhered to in order to observe the EMC threshold values. Installation MRD TNM4000 Release 02 12/2020...
Page 10 Recycling note  After usage, this device must be disposed of properly as electronic waste, in accordance with the current disposal regulations of your county, state, and country. Installation MRD TNM4000 Release 02 12/2020...
Page 11: About This Manual
Auto-topology discovery  Event log  Event handling  Browser/server structure  Browser interface  SNMP  Legend The symbols used in this manual have the following meanings: Listing  Work step   Subheading Installation MRD TNM4000 Release 02 12/2020...
Page 12: Device Description
Industrial Switch >TNM4000 Device description General device description TNM4000-TP36FF4X16G24P industrial switches are designed for the special requirements of industrial automation. They meet the relevant industry standards, provide very high operational reliability, even under extreme conditions, and also provide long-term reliability and flexibility.
Page 13: Description Of The Device Variants
Industrial Switch >TNM4000 Description of the device variants TNM4000-TP36FF4X16G24P industrial switches support 8 802.3af/at/bt PoE/PoE+/PoE++ 10/100/1000BaseT Ports, 12 802.3af/at PoE/PoE+ 10/100/1000BaseT Ports, 4 802.3af/at PoE/PoE+ 100/1000Base(X/T) COMBO Ports, 8 100/1000BaseX SFP Ports, and 4 100/1000/2500/10000BaseX SFP Ports. In these devices, all the cable outlet (except CLI port, MGT port)are at the back, i.e.
Page 14 The device allows you to connect a maximum of 36 service ports as well as additional CLI port and MGT port on the front of the device that you can use for diagnosis purposes. Installation MRD TNM4000 Release 02 12/2020...
Page 15: Connections For Voltage-Carrying Lines
5-pin Alarm relay contact ► European terminal ► 3-pin ► Type of the output load: general use & resistive Table 1: Connections for voltage-carrying lines: rear view of the device variants with plugged connections Installation MRD TNM4000 Release 02 12/2020...
Page 16: Poe Function
Industrial Switch >TNM4000 PoE function TNM4000-TP36FF4X16G24P industrial switches support Power over Ethernet (PoE) in accordance with 802.3af/at/bt. They allow the connection and remote supply of, for example, IP telephones (Voice over IP), webcams, sensors, printer servers and WLAN access points via 10/100/1000BASE-T. With PoE, these terminal devices are powered by the twisted-pair cable.
Page 17: Alarm Relay Contact
Industrial Switch >TNM4000 Alarm relay contact Each TNM4000-TP36FF4X16G24P device is equipped with 1 alarm relay contact. The alarm relay contact is a potential-free relay contact. The potential-free relay contact reports through a break in contact: The failure of at least one supply voltage.
Page 18: Assembly And Start-Up
 Before attaching an SFP transceiver, first remove the protective cap over the socket.  Push the SFP transceiver with the lock closed into the socket until you hear it latch in. Note: Only use MRD SFP transceivers (see page 37 “Accessories”). Installation MRD TNM4000 Release 02 12/2020...
Page 19: Connecting The Power Unit Connections For Supply Voltage And Alarm Relay Contact
Table 3: Pin assignment of terminal block for voltage supply For every supply voltage to be connected, perform the following steps:  Ensure the required conditions for connecting the supply voltage are observed (see page 4 “Supply voltage”). Installation MRD TNM4000 Release 02 12/2020...
Page 20 “General technical data”). For every alarm relay contact to be connected, perform the following steps:  Connect the relay contact lines with the terminal block connections. Mount the terminal block on the device using screws. Installation MRD TNM4000 Release 02 12/2020...
Page 21: Grounding
Note: The shielding ground of the connectable twisted pairs lines is connected to the rear panel as a conductor. Figure 10: Grounding Installation MRD TNM4000 Release 02 12/2020...
Page 22: Installing The Device
Non-adherence to these instructions can lead to minor physical injury or material damage. Note: The shielding ground of the connectable industrial twisted pair lines is connected to the front panel as a conductor. Dimensions  Figure 6: dimensions Installation MRD TNM4000 Release 02 12/2020...
Page 23  Install the sliding/mounting rails in the 19" switch cabinet as instructed by the manufacturer, and make sure the device is resting on both rails. Figure 7: Installation in the switch cabinet with sliding/mounting rails 1 - TNM4000-TP36FF4X16G24P 2 - Sliding/mounting rail 3 - 19" cabinet On delivery, two brackets are offered to you.
Page 24: Startup Procedure
(see on page 37 “Accessories”), not included in the delivery. 2.1.6 Startup procedure When you connect the supply voltage, you start up the device. Installation MRD TNM4000 Release 02 12/2020...
Page 25: Connecting The Data Lines
(ISO/IEC 8802-3:2000) 1000BASE-TX standard. These ports support: Auto MDI/MDIX  Autonegotiation  Autopolarity  Autocrossing (if autonegotiation is activated)  1000 Mbit/s full duplex  100 Mbit/s half duplex, 100 Mbit/s full duplex,  Installation MRD TNM4000 Release 02 12/2020...
Page 26 100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode  10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode  Power over Ethernet (PoE)  Delivery state: autonegotiation activated The socket housing is electrically connected to the rear panel.The PoE voltage Installation MRD TNM4000 Release 02 12/2020...
Page 27 1 1000/2500/10000 Mbit/s F/O ports (SFP slot or SFP+ slot) enable the connection of terminal devices or independent network segments in compliance with the IEEE 802.3 10000BASE-X / 2500BASE-X / 1000BASE-X standards. These ports support: Autonegotiation  State on delivery: autonegotiation activated. Installation MRD TNM4000 Release 02 12/2020...
Page 28: Display Elements
PWR1/2 Power supply Lights up The related supply voltage is on. None The related supply voltage is too low. PoE status Lights up PoE function is available. None PoE function is not available. Installation MRD TNM4000 Release 02 12/2020...
Page 29 PoE status Lights up A PoE terminal device is connected and receiving -16) / power via PoE. POE+(17 None No PoE port available or Power over Ethernet -32) function is disabled. Table 6: port status Installation MRD TNM4000 Release 02 12/2020...
Page 30: Basic Set-Up
Handshake Parity none Table 7: default settings of CLI interface The socket housing is electrically connected to the front panel of the device. The CLI interface is not electrically isolated from the supply voltage. Installation MRD TNM4000 Release 02 12/2020...
Page 31 Note: On delivery, the terminal cable will be offered to you with the device. You will find more configuration command in the “CLI Manual” on the CD-ROM. MGT interface  The MGT interface is an RJ45 socket used for loading the configuration and the software. Installation MRD TNM4000 Release 02 12/2020...
Page 32: Maintenance
 Depending on the degree of pollution in the operating environment, check at regular intervals that the ventilation slots in the device are not obstructed. Installation MRD TNM4000 Release 02 12/2020...
Page 33: Disassembling The Device
Industrial Switch >TNM4000 Disassembling the device  To detach the device from the switch cabinet, remove the screws from the brackets on the device. Figure 16: Mounting in the switch cabinet Installation MRD TNM4000 Release 02 12/2020...
Page 34: Technical Data
Standard −40 °C ... +85 °C during storage Humidity 5% ~ 95% (non-condensing) Air pressure Up to 2000m, higher altitudes on request Degree of Class 1 according to EN 60825-1 protection IP40 Pollution degree Installation MRD TNM4000 Release 02 12/2020...
Page 35 100M 20km 1310TX/1550RX Single Fiber MRD-SFP-GLX-15 100M 20km 1550TX/1310RX Single Fiber MRD-SFP-GEX-13 100M 40km 1310TX/1550RX Single Fiber MRD-SFP-GEX-15 100M 40km 1550TX/1310RX Single Fiber Table 10: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver) Installation MRD TNM4000 Release 02 12/2020...
Page 36 Table 11: TP port 10BASE-T / 100BASE-TX / 1000BASE-T Power consumption/power output  Name Power consumption TNM4000-TP36FF4X16G24P Max. 35W Scope of delivery  Device Scope of delivery TNM4000-TP36FF4X16G24P TNM4000-TP36FF4X16G24P CD-ROM(including Installation guide, User manual reference manual) Installation MRD TNM4000 Release 02 12/2020...
Page 37 10000BaseX SFP+ Module, SM(1550), 80KM MRD-10GSS-LC-850 10000BaseX SFP+ Module, MM(850), 300M Other accessories Product code Description SRM1U-RM Rack Mount Package for 19-inch Product PCORDDC-CN-15 DC Power Cable, 200W, 1.5M Dust protection cap for SFP sockets Installation MRD TNM4000 Release 02 12/2020...
Page 38: A Further Support
You will find the addresses of our partners on the Internet at http://en.mrdcom.net/ Contact our support via the email support@mrdcom.net Support ranges from the first installation through the standby service to maintenance concepts. You can contact us Tel.: 86-21-58330762  E-mail: sales@mrdcom.net  Installation MRD TNM4000 Release 02 12/2020...
