Summary of Contents for GENTIAN Vaultcase
- Page 1 GENTIAN Vaultcase Instructions Manual...
-
Page 3: Table Of Contents
CONTENTS Our history Page 4 The case Page 5 The dial Page 7 The leather strap Page 8 The lens Page 8 The movement Page 8 INSTRUCTIONS FOR USE Page 10 Manual winding Page 10 Automatic winding Page 11 Setting the time Page 11 Setting the date Page 11... -
Page 5: The Case
THE CASE The GENTIAN Vaultcase timepiece has a 40mm case of 316L polished stainless steel. The 316L stainless steel is highly resistant to corrosion and is hypoallergenic, making it ideal for prolonged contact with skin. The case is designed to be highly durable in it’s architecture using natural curvatures to ensure proper structure. - Page 6 normal conditions. In these circumstances your timepiece is therefore water-resistant to a depth of about 100 metres when the crown and case back are properly screwed in place. Lens Bezel Lug holes Screw-in Crown Diameter....................40.0mm Width (w/o crown)................40.0mm Width (w crown)..................42.8mm Lug-to-lug length................48.6mm Lug width....................20.0mm Thickness..................12.5mm...
-
Page 7: The Dial
THE DIAL GENTIAN dials are built from the same 316L steel that the case is, and finely brushed in a radial pattern to create the unique “sunburst” effect. The appled indicies and the date window are also manufactured with steel, and fitted to the dial surface by hand. -
Page 8: The Leather Strap
THE LEATHER STRAP The leather strap is hypo-allergenic. It is fitted with a stainless steel deployant butterfly buckle for greater fit and safety. Strap width is 20mm at its widest and 18mm at the buckle. THE LENS The top crystal is of sapphire, made of corundum, a very hard material (second only to diamond), free of impurities, transparent, resistant to abrasion and with anti-reflective treatment to prevent glare in certain lighting conditions. - Page 9 Date Wheel Decorated Rotor Screw-in Crown...
-
Page 10: Instructions For Use
Position 0 INSTRUCTIONS FOR USE MANUAL WINDING 1. Unscrew the winding crown to position 1 and without pulling it out, wind it clockwise until it feels tense. DO NOT OVERWIND, as this may damage the calibre. 2. Screw the winding crown back to position 0. -
Page 11: Automatic Winding
AUTOMATIC WINDING The timepiece will automatically self-wind through daily wear. The brushed gold rotor that keeps the caiblre wound can be seen through the display caseback. In the unlikely event that it should stop moving, please have your timepiece serviced immediately. SETTING THE TIME 1. -
Page 12: Replacing The Strap
3. Using the a push-pin tool, reinsert the alternate strap between lugs, until the spring-bar snaps into place. MAINTENANCE ADVICE GENTIAN timepieces are produced according to very high standards of quality. It is worth remembering that the mechanical parts run 24 hours a day when used, so the timepiece must undergo regular maintenance to ensure long life and good operation. -
Page 13: The Movement
involves replacing the seals so as to ensure the maximum water- resistance and security. Where the timepiece is used in extreme underwater sports, it is recommended that it should be checked every year before the season of underwater activities begins. THE MOVEMENT Have the movement of your timepiece checked periodically by a qualified watch service centre so as to maintain its perfect... -
Page 14: Cleaning The Exterior
After this operation, and also after bathing in the sea or a swimming pool, carefully rinse the timepiece with clean water. All GENTIAN timepieces can be cleaned with a soft, dry cloth. -
Page 15: After-Sales Services
INDICATED! GENTIAN AFTER-SALES SERVICES In order to maintain the superior quality of your timepiece throughout its life, GENTIAN WATCHES offers a warranty of two (2) years on the S24 Calibre movement, and recommends additional third party services such as: 1. Complete Service. -
Page 16: Technical Specifications
Technical Specification TECHNICAL SPECIFICATIONS Shape and Type Round caliber, mechanical lever movement, self - winding Frequency 28800 A/h Jewels Overall Diamater 26.00mm Case Fitting Diamater 25.60 mm Height 4.85 mm Display by means of hands - Hours, Minutes and Seconds. Function Date display in 3H/6H window Winding Stem... - Page 17 Gentian Watches Designed in Kuwait SWISS MADE www.gentianwatches.com...
- Page 18 www.gentianwatches.com...
