Summary of Contents for Visi-Trak A49-1120P
- Page 2 0.025" (10 Pitch) respectively. Caution! The Visi-Trak® Transducer must be handled with care at all times. The transducer incorpo- rates a thin metallic face and permanent damage can result if this face is scratched, dented, or abused. Also, care must be taken when wiring the transducer since improper wiring or short circuits may destroy the device.
-
Page 3: Installation
Do not over tighten or damage may result. Continue to next page…. Visi-Trak® is a registered US trademark of Visi-Trak Worldwide, LLC. - Page 4 Sometimes better results are obtained when the transducer is allowed to “float” on the grooved rod. This will reduce wear on the transducer, and ensure that the transducer remains in contact with the rod. To “float” a transducer, simply loosen the set screws slightly.
- Page 5 Machine #3 TB1-16 TB1-15 TB1-57 Machine #4 TB1-14 TB1-13 TB1-58 Machine #5 TB5-35 TB5-36 TB5-101 Machine #6 TB5-37 TB5-38 TB5-102 Machine #7 TB5-39 TB5-40 TB5-103 Machine #8 TB5-41 TB5-42 TB5-104 Visi-Trak® is a registered US trademark of Visi-Trak Worldwide, LLC.
- Page 6 Transducers. The presence of continuous high or low voltages at the external electronics' input ter- minals doesn't rule out improper mounting, or defective cabling as possible problems. Visi-Trak® is a registered US trademark of Visi-Trak Worldwide, LLC.
-
Page 7: Using An Oscilloscope
Using an Oscilloscope: It is best to inspect the transducer outputs using a two channel oscilloscope so that both digital outputs can be viewed simultaneously. Set the scaling on 5 volts per divi- sion vertical and approximately 2 milliseconds per division horizontal. The horizontal scale may need adjustment based on the speed of rod motion. - Page 8 Special note for True-Trak 2020™ Monitoring and Sure-Trak™ Control System Users: A “Transducer Test” program is built in the True-Trak 2020™ system. You can invoke the program from main menu “Monitor” select “FasTrak Board Monitor” to start FasTrak Board Monitor program. From FasTrak Board Monitor program select “View” then select submenu “FasTrak Board Interface”...
- Page 9 Visi-Trak Worldwide's shipping dock. Prices, specifications, and decisions are subject to change without notice. Visi-Trak Worldwide, LLC. shall not be liable for any loss or damage, and the Purchaser assumes and agrees to indemnify, and save harmless, Visi-Trak Worldwide, LLC.
