FIREGUARD GLOBAL FG-S01_AP Quick Start Manual

FG-S01_AP / FG-S02_AP / FG-SO3_AP
SMOKE DETECTORS
PRODUCT OVERVIEW
This alarm is a smoke detector of the photo cell
principle. This means that the alarm checks the air for
smoke resulting from fire. It does not detect heat, gas
or fire. If the smoke detector is properly mounted and
maintained it will sound an alarm in an early stage. In
the event of a fire this can give you those extra seconds
needed to vacate your home and call the fire brigade.
The alarm is designed to detect smoke. It cannot
prevent a fire. Read the instructions through carefully
before using the smoke detector.
FG-S01
Features
 Photoelectric sensing technology
 Easy installation and maintenance
 Battery case at the back of a sensor for easy
removal of a battery
 Sleek low-profile housing design
 Low battery warning
 Test button verifies battery and alarm
operation
 Sounding a loud alarm signal or exceeding
85db in alarm mode
MODEL
FG-S01_AP / FG-S02_AP /
FG-S03_AP
FIREGUARD GLOBAL LTD.
FG-S02
DESCRIPTION
Smoke Detectors
00-44-8450751042
IMPORTANT
Placing a smoke alarm is a part of your fire
protection, just as fire extinguishers, emergency
ladders, ropes, but also your choice in the use of
building materials for renovation. Always ensure
that there is an evacuation plan, discuss this with
your children. Ensure that each room can be left
without opening the door, e.g. by the window. If
there is any question as to the cause of an alarm,
it should be assumed that the alarm is due to an
actual fire and the dwelling evacuated immediately.
Technical Specification
Smoke Sensitivity :
Power Supply :
Battery Life :
Low Battery Life :
Alarm Indicator :
Alarm Sound Level :
Temperature :
Humidity :
Dimensions (LxWxH) : FG-S01/FG-S02: ø107x35mm
00-44-8459751043
FG-S03
0.086 dB/m to 0.14 dB/m
9V Carbon Zinc/Alkaline
Lithium Battery
>12 months
>30 days
Continuously emitting red
light and alarm sound
>85dB at 10 feet (3m)
0ºC - 50ºC
10%-90%RH, no
condensation or icing
FG-S03: ø130x40mm
