Ozwashroom AF106 Instruction Manual

AF106: Digital Automatic Fragrance Dispenser
NOTE:
Please read the manual carefully before you use the dispenser.

Button Functions

There are 9 Function buttons for the Fragrance Dispenser
1. RESET button: Use this button to remove previous set ups and
applications
2. SPRAY (manual button): After putting batteries and a fragrance can into the unit, the spray button
allows you to test that the unit is working correctly
3. MODE button: When pressing this button the LCD screen display will show the following options:
Mode, Start, Stop, Spray, Interval, Week, Clock
4. WEEK button: use this to specify which week you would like the dispenser to work, there are 2
options available, Mon-Fri or Mon-Sun
5. HOUR button: use this button to specify at which time (hours) you would like the dispenser to spray
6. MIN button: Use this button to specify the minutes you would like the dispenser to spray
7. ON/OFF button
8. LED light: Green = ON, Red = OFF/ Replace fragrance can
9. 9.LCD Screen displays battery life in left corner

Installation

For maximum efficiency install Fragrance Dispenser approx. 2 meters off the ground and sit it on a stable, flat
shelf or fix the dispenser to the wall.
Unit takes x2 D batteries
Avoid contact with eyes and Keep out of reach of children.

Set Up

1. Insert x2 D batteries. For the initial set up of your fragrance dispenser begin by pressing the MODE
button, the word "START" will appear on the screen
2. To set up the WORK CYCLE, press the MODE button until "WEEK" appears on the screen
3. There are 2 WEEK periods, which are from Mon – Fri or
Mon – Sun, select the most appropriate for your needs
4. Set the Hour and the Minute (using the buttons provided) that you would like the dispenser to begin
working (e.g. 9:23 or 16:45)
5. Press the MODE button again and the word "STOP" will appear on the screen
6. Set the Hour and the Minute (using buttons provided) that you would like the dispenser to cease
working (e.g. 11:24 or 22:58)
