Summary of Contents for FYBIKON BS Series
- Page 1 FYBIKON ART. Nr: 10103, 10104 Series Biological Microscope Operation Instruction To ensure the safety and obtain satisfactory performance and to familiarize yourself with the use of this microscope, please study this instruction manual thoroughly before your operations.
-
Page 2: Table Of Contents
Contents 1 Purpose and components ························································ 2 2 Specifications ····································································· 3 3 Installation ········································································ 5 4 Operations ········································································· 6 5 Maintenance ······································································ 8 6 Trouble shootings ································································ 9 www.fybikon.no... -
Page 3: Purpose And Components
1 Purpose and components BS series of biological microscope have some great feature that includes built-in carrying handle that makes operations easy and convenient. The microscopes have LED illumination that provides white light with virtually no heat. With built-in mechanical stage and plan achromatic objectives this is a perfect solution for educational purposes in schools that appreciate quality. -
Page 4: Specifications
Focusing knobs can make a coarse stroke 20 mm and the fine movement 0.18 mm each circle rotation with a division 0.002 mm. www.fybikon.no... - Page 5 2.8 Diopter Located on the left eyepiece of the binocular head and is designed to help compensate the difference between the user’s eyes. Diopter adjustable range is ±5 diopter. 2.8 Electrical components The built-in light source which provides the optical system with light is an energy efficient 3W rechargeable LED. www.fybikon.no...
-
Page 6: Installation
3.5 Make sure that the voltage in you power grid meets instrument’s requirement and plug the power cord into the power outlet. If used cordless, first time fully charge for 8 hours. After the first time, 2 hours charge each time is ok. www.fybikon.no... -
Page 7: Operations
5. If the image of the specimen appears pale, the aperture of the iris diaphragm should be slowly closed until the details of the specimen are sharply defined. If the specimen appears dark, slightly open the diaphragm. www.fybikon.no... - Page 8 The center of condenser is accurately adjusted at factory. No further adjustments should be necessary. While exchanging objectives, adjust the lever lifter of condenser to make it suit for the numerical aperture of objective selected to be used, thereby gaining a bright and well-distributed luminance in the view field. www.fybikon.no...
-
Page 9: Maintenance
5.6 Please cut off the power supply and protect the instrument with dust cover after usage. www.fybikon.no... -
Page 10: Trouble Shootings
Image cannot be observed The interpupillary distance is out Adjust according to No.4.5 once more by two eyes at the same of place time Ved behov kontakt oss i Fybikon for. Tlf. + 47 38 01 21 66 E-post: postmaster@fybikon.no Web: www.fybikon.no www.fybikon.no...
