- Page 1 AS6031- Development Kit User Guide AS6031-DK User Guide Revision: Release Date: 2021-04-29 Document Status: Production...
-
Page 2: Table Of Contents
5) Reference Modules and Transducers ....................8 Modules ............................. 8 Water Meter Modules ........................8 Gas Meter Modules ........................9 Transducers ............................. 10 6) Copyrights & Disclaimer ........................13 3) Revision Information ........................13 AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... -
Page 3: Introduction
PUBLIC INFORMATION 1) Introduction The AS6031-DK development kit allows customers a quick and intuitive approach to using the AS6031 UFC in ultrasonic flow meter applications. Kit Content and Ordering Information Figure 1: Functional Blocks AS6031-Board V1.0 (Based on AS6031 in QFN48... -
Page 4: Quick Start Guide
A detailed description of the UFC Evaluation Software I given in a separate document: Clear the reset and error flags by pressing the buttons at the lower right. MCT Count Low and High should blink while the measurement is running. AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... -
Page 5: Hardware Description
“UNIPRO” in the device manager. For SPI communication only, PICOPROG version 2.0 is sufficient. The flat connector connecting the PICOPROG and the AS6031-DK_RB includes the power lines and the SPI communication lines. VCC_LEVEL is the voltage feedback for the PICOPROG level shifters. AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... -
Page 6: Schematics, Layers And Bom
PUBLIC INFORMATION 4) Schematics, Layers and BOM Figure 4: AS6031-DK_RB Schematics AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... - Page 7 0603 Chip resistor 560 kΩ 0603 Chip resistor 10 MΩ 0603 Chip resistor 7 x 1 x 2.54 180° 2 x 1 x 2.54 180° 2 x 1 x 90° 2.54 AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production...
-
Page 8: Reference Modules And Transducers
5) Reference Modules and Transducers Modules ScioSense has a close cooperation with Qingdao iESLab to support customers with complete ultrasonic flow modules for water and gas. For water, iESLab offers pipes made of brass and made of plastic and modules can be ordered un-calibrated or calibrated. The gas meter modules are made of plastic and come un-calibrated, because the final housing will have a major impact on the calibration. -
Page 9: Gas Meter Modules
Markup Information(1) Gas meter module residential IA-UGM-1 IA-UGM-1-YYYYMMDD-SSSSSS Gas meter module industrial IA-UGM-2 IA-UGM-2-YYYYMMDD-SSSSSS and commercial YYYY = year, MM = month, DD = day, SSSSSS = product serial number that day AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... -
Page 10: Transducers
For transducers we can recommend products from Zhejiang Jiakang Electronics Co., Ltd.: Figure 14: Zhejiang Jiakang Ultrasonic Transudcers Part number Frequency Part number Gas Meters PSC500K018060H2AD2-B1 500 ± 10 kHz 470 pF ± 10% -35 to 70 °C AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production... - Page 11 -40 to 85 °C >800mV 塑料外壳 (@ 2Vpp, 110mm) 1.0 ± 0.1 MHz R1MHz 500 to 1500 Ω 600 pF ± 20% PSC1.0M014083H2AD2-B0 -40 to 85 °C >450mV (@ 2Vpp, 110mm) 塑料外壳 AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production...
- Page 12 Tstrg = -40 to 85°C for all parts Contact data: Zhejiang Jiakang Electronics Co., Ltd. No.1188 Jiahang Road, Jiaxing City, Zhejiang Province, China http://www.jkelec.com/ dym@jkelec.com T. 13967380228 ayq@jkelec.com T. 13857347855 Overseas markets: sally.ma@jkelec.com M+15906738799 AS6031-DK User Guide / SC-000866-UG-4 / 2021-04-29 / Production...
-
Page 13: Copyrights & Disclaimer
ScioSense B.V. shall not be liable to recipient or any third party for any damages, including but not limited to personal injury, property damage, loss of profits, loss of use, interruption of business or indirect, special, incidental or consequential damages, of any kind, in connection with or arising out of the furnishing, performance or use of the technical data herein. - Page 14 ScioSense is a Joint Venture of ams AG Headquarters: ScioSense B.V. High Tech Campus 10 5656 AE Eindhoven The Netherlands Contact: www.sciosense.com info@sciosense.com Sensing tomorrow’s world...
