- Page 1 Updated 02/10/17 for the new 2018 model Coin Sorter CS209 Guide An electronic version of this document can be downloaded from the CS209 product page at www.shopstuff.co.uk...
- Page 2 Contents Page Page 3-4 ………………...Why Buy Guide Page 5……..………Warranty Information Pages 6-7………Completed Test Results Pages 8-12……………..…….Instructions Pages 13-15………………...Maintenance...
- Page 3 Allowing the operator to check warranty conditions. 5. Does the CS209 being offered have white coin pots and not white. 6. Does the CS209 have an off white thumb screw on the top of the sorting disk and does not have screws around the outer edge.
- Page 4 Searching www.youtube.com for CS209 coin sorter will also bring up a basic video showing the machine in operation and how to spot a genuine CS209 coin sorter.
- Page 5 CS209 Coin Sorter Warranty Information We offer the CS209 coin sorter and counter with a 300,000 coin or twelve month warranty (whichever comes first) with an expected average monthly usage of up to 25,000 coins. The warranty is offered on a fair usage policy meaning we would not expect to receive a CS209 back that has counted 100,000 coins after just one month of ownership;...
- Page 6 Test Results for Coin Sorter CS209 carried out 01/10/2015 by CR. Reason for testing: To test and find any weakness present in new 2016 model CS209 coin sorter with the new modification design and implemented exclusively for us. Test coins: UK sterling pre-checked for damaged or foreign coins.
- Page 7 As with any coin sorter, regardless of cost, miss-counts and jams are always going to occur due to the thickness and shape of UK sterling coins. In our test the CS209 miscounted just 2 coins out of 11840, we noted that the coins miss-counted were all of the larger type coins. We then discovered than when we reduced the amount of 2p’s being counted from 80 to the...
- Page 8 Instructions.
-
Page 9: Specification
Specification Ambient Temperature -0˚C - 40˚C Ambient Humidity- 30 - 80% Hopper Capacity - 900 Coins Max Individual Tray capacity 1 - 100 coins Batch Preset -3 Digits LCD Counting Number Display -7 Digits LCD Power Source –AC220V/50HZ or AC110V/60HZ Power Consumption-50W Maximum Dimensions-330mm x 330mm x 255mm Net Weight - 4.6KG... - Page 10 4. Batching To set up batch mode firstly press the “SET” key. Then press the relevant number from 1-8—each number represents a denomination 1 is equal to 5ps 2 is equal to 1ps and so on in coin size order £2 being number 8. Then to preset the denomination 1-8 you wish to batch—key in the number you wish the machine to stop at IE 20 x £1.00 or 20 denomination number 4.
- Page 11 5. Memories To memorize a count either during a count or after a count press the “SAVE” key and then 1, 2, 3 or 4 (each number representing a memory) To view a saved count press the “SAVE” key once more then press number 5, 6, 7 or 8 to view the saved count or counts.
- Page 12 When counting if the letter “E” appears on the left hand side of the LCD display and a loud buzzing sound occurs, there is machine error — this is usually caused by damaged or foreign coins or objects other than coins jamming the machine that may have entered the machine mixed with the coins.
- Page 13 Coin Sorter CS209 Routine Maintenance All coin counting and sorting machines need routine cleaning due to deposits and dirt bought in to the machine by the coins it is counting. You only have to look at your hands after handling coins to realise how dirty coins actually are.
- Page 14 Full Maintenance and manually clearing a coin jam. 1. Complete basic maintenance. 2. Open lid and remove consumable sorting disk by removing the centre thumb screw. 3. Brush metal sorting disk and gently vacuum foam underside of plastic disk, checking for holes or damage to the underside of the disc at the same time.
- Page 15 All maintenance must be carried out with the machine switched off and unplugged from the wall. All pictures and text in this document are property of Shopstuff Ltd and should not be copied or duplicated without the express permission of...
