Vision 312
User Manual
Product Version 00.09
Original Instructions
Document type:
Document number:
Document revision:
Document date:
Security:
Status:
TTControl GmbH
Schoenbrunner Str. 7, A-1040 Vienna, Austria,Tel. +43 1 585 34 34 – 0, Fax +43 1 585 34 34 – 90,
No part of the document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the
written permission of TTControl GmbH. Company or product names mentioned in this document may be trademarks or registered trademarks of their
respective holders. TTControl GmbH undertakes no further obligation or relation to this document.
© TTControl GmbH 2020. All rights reserved.
Confidential and Proprietary Information
User Manual
D-156-G-02-001
0.7.1
2020-03-16
Corporate confidential
Released
office@ttcontrol.com
Subject to changes and corrections.
Advertisement
Table of Contents
Related Manuals for TTControl Vision 312
Summary of Contents for TTControl Vision 312
- Page 1 No part of the document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the written permission of TTControl GmbH. Company or product names mentioned in this document may be trademarks or registered trademarks of their respective holders.
-
Page 2: Table Of Contents
........© TTControl GmbH 2020. All rights reserved. - Page 3 ......... . © TTControl GmbH 2020. All rights reserved.
- Page 4 ........12 Glossary © TTControl GmbH 2020. All rights reserved. Document Number:...
-
Page 5: Disclaimer
CLUDING BUT NOT LIMITED TO LOSS OF DATA, DATA BEING RENDERED INACCURATE, BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY OR OTHER LOSS WHATSOEVER) ARISING OUT OF THE USE OR INABILITY TO USE THE DOCUMENT EVEN IF TTCONTROL GMBH HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. -
Page 6: General Description
This User Manual is intended for qualified engineers. 1.2 Notation In the context of this document, the term Vision 312 (or Vision 312 family) refers to the family and all its products. The Vision 312 products of the Vision 312 family are referred to as Vision 312 products. -
Page 7: Features
1. GENERAL DESCRIPTION 1.4 Features The following tables compare the features of the Vision 312 family products: 1.4.1 System components Vision 312 Vision 312Plus i.MX 6Solo Processor 800 MHz – i.MX 6QuadPlus Processor 1 GHz ARM Cortex-A9 (single core) – ARM Cortex-A9 (quad core) -
Page 8: Physical Specifications
• Storage temperature: -30 to +85 • IP6K5 rated housing Other device dimensions, including tolerances, weight and other physical specifications for Vision 312 can be found in the Product Drawing (PD) [1]. Additional physical specifications, including thermal re- quirements, can be found in the Mounting Requirements Document (MRD) [2]. -
Page 9: Vision 312Plus
1. GENERAL DESCRIPTION 1.4.4.2 Vision 312Plus Figure 2: Block diagram for Vision 312Plus products © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 10: Instructions For Safe Operation
TTControl cannot be held liable for any personal injury or property damage re- sulting from improper installation or use of the device, non-compliance with the instructions in this document, or non-compliance with the intended field of operation. -
Page 11: Intended Use
2. INSTRUCTIONS FOR SAFE OPERATION 2.2 Intended use The Vision 312 family products are programmable and robust visualization and operator interaction units, to be used for parameter-setting and operation in vehicles and mobile machinery for construction, agricul- tural, forestry, and municipal applications. -
Page 12: Standards And Guidelines
3. STANDARDS AND GUIDELINES ≡ 3 Standards and guidelines Vision 312 was developed in compliance with the following international standards and guidelines: CE-Mark 2014/30/EU E-Mark ECE 10R-05 Title 47, Part 15B ISO 13766 EN 13309 ISO 7637-3 ISO 13766 ISO 10605... -
Page 13: Standard Compliance
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications made to this equipment not expressly approved by TTControl may void the NOTE FCC authorization to operate this equipment. -
Page 14: Connectors And Pins
≡ 5 Connectors and pins Vision 312 is equipped with a 34-pin main connector and up to 4 HSD connectors. The main connector is compatible with the TYCO Super Seal 1 mm series. This section defines the pinouts of the connectors, while section lists the mating connectors and their manufacturer part numbers. -
Page 15: Main Connector (C1)
Camera 2 GND Camera 2 GND Video 3 Signal Video 3 GND Camera 3 Supply Camera 3 GND Video 4 Signal Video 4 GND Camera 4 Supply © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 16: 100Base-T1 And 100Base-Tx Connector (A)
RS-232 GND RS-232 GND RS-232 RX RS-232 RX For more information on recommended connectors and wires to interface with a Vision 312 device, refer to section 10. 5.3 100BASE-T1 and 100BASE-TX connector (A) 100BASE-T1 is supported by the Vision 312 products. -
Page 17: Usb Otg Connector (B) And Usb Host Connector (D)
SHIELD 5.4 USB OTG connector (B) and USB HOST connector (D) The USB OTG is supported by all products of the Vision 312 family. The USB HOST is supported by Vision 312Plus products. The connectors B and D are color-coded brown. -
Page 18: Specification Of Inputs And Outputs
Pulse 5, Level IV (superimposed 174 V, R = 2 Ω ) Note 1 The control unit is protected by an active load dump protection circuit Note 2 Without external loads © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 19: Characteristics
< 8 V BAT+ Note 3 The time it takes for V to get higher than 8 V BAT+ 6.1.4.1 Vision 312 Supply current characteristics for the Vision 312 device. Symbol Parameter Note Unit Supply current at V = 8 V... -
Page 20: Negative Power Supply (Bat-)
Pin no. Function Terminal 15 Input 6.3.2 Functional description Terminal 15 switches the power supply of the Vision 312 device. 6.3.3 Power on/off sequence The device boots if • Terminal 15 is powered (typically BAT+) or • Wake-up input is powered (typically BAT+) Once the device has started, the application software is responsible for saving all data to flash memory before it powers down the device. -
Page 21: Characteristics
Connector Pin no. Function External Wake-up 6.4.2 Functional description External Wake-up provides the possibility to wake up the Vision 312 device from the Suspend mode or Power-off mode by an external event (see figure 10). 6.4.3 Maximum ratings Symbol Parameter... -
Page 22: Functional Description
In this case, the connector’s shield must be connected to the shield of the Ethernet cable. 6.6.3 Maximum ratings Symbol Parameter Unit Input common mode range DC or AC-peak with line frequency in-CMM (max 60 Hz) © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 23: 100Base-T1 Interface
6.7.3 Maximum ratings Symbol Parameter Unit Bus voltage under overload conditions (short circuit to supply voltages) 6.8 USB OTG interface Supported by all Vision 312 family products. 6.8.1 Pinout Connector Pin no./Shield Function USB D+ USB V USB D-... -
Page 24: Maximum Ratings
6.9 USB Host interface Supported by Vision 312Plus products. 6.9.1 Pinout Connector Pin no./Shield Function USB D+ USB V USB D- USB GND Shield USB SHIELD © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 25: Functional Description
6.10 RS-232 interface 6.10.1 Pinout Connector Pin no. Function RS-232 TX – serial interface output RS-232 RX – serial interface input RS-232 GND – serial interface ground signal © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 26: Functional Description
Input voltage for low level +0.8 Input voltage for high level +2.7 Input resistor (to GND) kΩ Output voltage for low level Output voltage for high level Data rate © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 27: Can Interface
CAN implements a bidirectional twisted pair bus for high speed serial data transfer up to 1 Mbit/s. The bus must be terminated with 120 Ω at each end to prevent wave reflection. If the Vision 312 device is connected at the end of a CAN bus, it is necessary to use external termination resistors as the device is not equipped with internal termination. - Page 28 6. SPECIFICATION OF INPUTS AND OUTPUTS Figure 8: CAN interface wiring Figure 9: CAN termination © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001...
-
Page 29: Maximum Ratings
(less than 10 m) between only two nodes can be operated at 1 Mbit/s. Note 3 For typical network size and topology (network with stub wires) and more than two nodes the practical limit is 500 kbit/s. © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 30: Analog Video Input
Only for Vision 312Plus products. 6.12.2 Functional description The Vision 312 is compatible with PAL B/G/H/I/D (standard PAL) and NTSC-M (standard NTSC) composite video signals (CVBS). The standard for use with the device can be selected in the application configuration. -
Page 31: Camera Supply
7.5 V ≤ V ≤ 13.3 V Note 2 BAT+ Note 3 > 13.3 V BAT+ Note 4 For Vision 312 Note 5 For Vision 312Plus © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 32: Internal Structure
7.3 Real-time clock (RTC) The Vision 312 device includes a real-time clock with a backup power system. When the device is con- nected to the vehicle’s battery via the main connector’s (C1) BAT+ pin, the real-time clock is supplied by the vehicle’s battery regardless of whether the device is operational or not. -
Page 33: Characteristics
If the super-capacitor has been charged for at least 5 hours with V > 9 V. BAT+ 7.4 Memory The Vision 312 device provides the following storage memory types: • eMMC NAND-flash storage (large and fast memory array) • EEPROM storage 7.4.1 Characteristics... -
Page 34: Power Modes
8 Power modes Figure 10: Power modes The Vision 312 device has four power modes: • In Disconnected Mode, Terminal 30 is disconnected from the power supply. Only the real-time clock is powered (until the internal energy buffer is drained). - Page 35 Users are advised to power-off by setting Terminal 15 to low, and waiting until the application performs a controlled shut down of the device. © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information...
-
Page 36: Device Front
Figure 11: Front view of the Vision 312 device 9.1 Display The Vision 312 device is equipped with a 12.1 inch TFT LCD module with a resolution of 1280 x 800 pixels (WXGA) and a LED backlight unit. 9.1.1 Characteristics... -
Page 37: Ambient Light Sensor
9.4 Touchscreen The Vision 312 device is equipped with a projective capacitive touchscreen designed to be used as an input device for the application running on the device. It can be operated with bare fingers and gloves. The touchscreen supports multi-touch gestures with two fingers. -
Page 38: Optical Bonding
W ≤ 0.05, L ≤ 10 ≤ 5 0.05 < W ≤ 0.1, L ≤ 10, distance > 5 ≤ 5 W > 0.1 or L > 10 Examples: © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001... -
Page 39: Acceptance Criteria For Lcd Pixel Errors
Use of inappropriate cleaners or cleaning methods can result in optical degradation of the touchscreen/pro- tection glass and/or affect its functionality. © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information... -
Page 40: Connectors And Cable Specifications
This section lists recommended plug housings for mating connectors, cables, receptable contacts, cavity plugs, and blind plugs. For specifications of the Vision 312 device connectors, see section 5. For detailed specifications, please contact the supplier or refer to the supplier’s website. -
Page 41: Receptacle Contacts
Note 1 TTControl recommends the instruction sheet 411-78017 from TE Connectivity. Note 2 TTControl recommends ordering the cable harnesses for connectors A, B, C, and D from a professional cable harness manufacturer. © TTControl GmbH 2020. All rights reserved. Document Number:... -
Page 42: Cables
10. CONNECTORS AND CABLE SPECIFICATIONS 10.5 Cables TTControl recommends the following cables for mating connectors: Connector Function Article description Type Recommendation designation Single twisted pair, FLRY 2x35-A Automotive standard 120 Ω, 2x0.35 mm H=20 GE/GR Video Shielded video Lapp 2170010,... -
Page 43: References
11. REFERENCES ≡ 11 References Vision 312 Product Drawing, D-156-C-20-003. TTControl GmbH. Vision 312 Mounting Requirements Document, D-156-G-20-010. TTControl GmbH. ISO. ISO 11783-2:2012(E) (see section 11.1). 11.1 Referenced norms and standards Documement Rev. Document title ISO 16750-1 2006 Road vehicles — Environmental conditions and testing for electrical and electronic equipment —... - Page 44 Part 2: Additional EMC requirements for functional safety ISO 4892-3 2016 Part 3: Fluorescent UV lamps ISO 14982 2009 Agricultural and forestry machines — Electromagnetic compatibility — Test methods and acceptance criteria © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001...
-
Page 45: Glossary
Printed Circuit Board Assembly Product Drawing Random Access Memory Radio Frequency Real-Time Clock Reception Software Developement Environment Software Thin-Film Transistor Transmission Universal Serial Bus WXGA Wide Extended Graphics Array © TTControl GmbH 2020. All rights reserved. Document Number: Confidential and Proprietary Information D-156-G-02-001...
Need help?
Do you have a question about the Vision 312 and is the answer not in the manual?
Questions and answers
how can i connect Camera,& i want electrical diagramm. Thanks
To connect the TTControl Vision 312 camera, use the designated video and power supply pins as listed in the manual:
- Video Signal Inputs:
- Video1Signal (Pin 8)
- Video2Signal (Pin 6)
- Video3Signal (Pin 29)
- Video4Signal (Pin 21)
- Video Ground:
- Video1GND (Pin 16)
- Video2GND (Pin 14)
- Video3GND (Pin 31)
- Video4GND (Pin 22)
- Camera Power Supply Outputs:
- Camera1Supply (Pin 9)
- Camera2Supply (Pin 7)
- Camera3Supply (Pin 28)
- Camera4Supply (Pin 20)
- Camera Ground:
- Camera1GND (Pin 17)
- Camera2GND (Pin 15)
- Camera3GND (Pin 23)
- Camera4GND (Pin 19)
For the electrical diagram, refer to the section on connectors and pins in the manual. If more details are required, check section 10 for recommended connectors and wiring.
This answer is automatically generated
